Parts for Ge JVM3162RJ1SS: Control Parts

This electronic control board—also called the smart board—is the microwave's main circuit board. It manages the display, keypad input, and power to key components so the unit responds to commands and operates as designed.

• Coordinates timing and power to cooking components via onboard relays
• Interfaces with the touchpad and front display
• Works with door/safety interlocks to prevent unsafe operation
• Failure symptoms include a blank or flickering display, unresponsive buttons, failure to start, or intermittent power loss

• Disconnect power before service; microwaves contain high-voltage components that can retain a dangerous charge even when unplugged
• Handle the board by the edges and use ESD protection to avoid damage
• Photograph wiring and move connectors one at a time, matching orientation and latch positions

This control panel bracket supports and secures the user interface assembly to the appliance frame. Replacing a damaged bracket restores a solid, correctly aligned panel so buttons and display sit properly without flex, gaps, or rattles.

• Provides the structural mount for the control panel assembly
• Maintains proper alignment of keypad/display and surrounding trim
• Helps correct a loose, wobbly, or misaligned control panel
• Replaces brackets that are cracked, bent, or stripped at mounting points
• Reduces vibration or rattling noises from the panel area

• Disconnect power at the breaker or unplug before servicing; if working on a microwave, high-voltage components can retain a charge.
• Support the control panel when removing fasteners to avoid straining wire harnesses.
• Transfer any reusable clips, insulation, or screws from the original bracket.
• Avoid pinching harnesses.

This control panel assembly replaces a damaged or unresponsive user interface so you can reliably select settings and operate the appliance. It restores a clean, factory fit when the original panel becomes cracked, sticky, or worn.

• Provides the front user interface housing and keypad/touchpad area
• Sends key-press signals to the control system via the ribbon connector
• Replaces broken, faded, or physically damaged panels
• Helps resolve unresponsive or intermittent keys, stuck buttons, or keypad-related error beeps/codes

• Disconnect power at the breaker before servicing
• On microwave models, internal high-voltage components can retain a charge even when unplugged—use extreme caution
• Support the panel while removing screws; don't stress the wiring or ribbon cable
• If applicable, transfer any reusable boards, clips, or light pipes from the old panel; seat the ribbon connector straight and fully
