Parts for Bosch HMB5050/02: Door Assembly Parts

This black dishwasher door liner restores the appliance's interior door surface and appearance after damage or wear. It provides a clean, finished look and supports the door's inner components for reliable operation. What it does:

• Replaces a cracked, dented, or discolored inner door panel to restore appearance
• Supports interior components and helps maintain proper door closure
• Reduces the chance of steam or water contacting insulation or electronics behind the liner
• Helps eliminate rattles or noise caused by a damaged liner

• Disconnect power and water supply before starting any repair
• Handle the door and any glass carefully; wear gloves and eye protection
• Removal typically requires loosening door screws and separating inner panels—follow the service manual

This door latch assembly secures the door closed and signals the control that it's safely shut, allowing cycles to start and run. Replacing a worn latch restores a reliable safety interlock and consistent operation.

• Secures the door and engages the safety interlock so the appliance can operate
• Sends a "door closed" signal to the control
• Common symptoms: door won't latch or stay closed; unit won't start or pauses as if the door is open; intermittent operation when the door is bumped; visible wear or damage to the latch
• Helps prevent nuisance "door open" indications

• Disconnect power before servicing
• Access the latch from the door area; remove inner panel or trim as required by your model
• Note wire positions, transfer connectors, and mount the new latch in the same orientation
• Test door closure before reassembly

This door latch assembly secures the door closed and signals the control that it's safely shut, allowing cycles to start and run. Replacing a worn latch restores a reliable safety interlock and consistent operation.

• Secures the door and engages the safety interlock so the appliance can operate
• Sends a "door closed" signal to the control
• Common symptoms: door won't latch or stay closed; unit won't start or pauses as if the door is open; intermittent operation when the door is bumped; visible wear or damage to the latch
• Helps prevent nuisance "door open" indications

• Disconnect power before servicing
• Access the latch from the door area; remove inner panel or trim as required by your model
• Note wire positions, transfer connectors, and mount the new latch in the same orientation
• Test door closure before reassembly

A replacement door screen that restores the barrier at the appliance door opening and helps keep debris out of the door cavity. Fits into the door assembly to maintain proper airflow path and appearance. What it does:

• Provides a protective mesh/cover at the door to help block lint, crumbs and other debris from entering the door cavity
• Helps maintain the designed airflow path through the door opening for proper appliance operation
• Replaces torn, clogged or damaged screens that cause visible debris buildup at the door
• Reduces risk of small objects getting stuck in the door area and contacting internal components

• Disconnect power to the appliance before beginning any service
• Remove the door or inner door panel per the appliance service instructions to access the screen
• Handle the screen gently to avoid bending or damaging mounting tabs; use approved fasteners if required

This outer door panel replaces a damaged or worn front door panel to restore appearance and protection for the appliance. It provides the visible exterior surface and helps the door close and align properly. What it does:

• Replaces a dented, scratched or corroded outer door surface to improve appearance
• Protects internal door components and insulation from damage
• Helps the door sit flush and align with the cabinet to reduce gaps
• Restores a clean, finished look after collision or wear

• One outer door panel

• Turn off power to the appliance before starting any repair
• Remove inner door components and fasteners as required to access and swap the outer panel
• Keep screws and small parts organized; some trims or handles may need separate removal
