Ron S Massapequa , NY September 06, 2016 Appliance: General Electric Refrigerator GSS23SGSBSS Ice maker door door solenoid rusted out changed all parks in there including ingredients flapper hinge and spring I used the video posted on site...note on my model trim bezel did not have to be removed! Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Keith P Morganton , NC September 19, 2014 Frost build up in ice chute and inside of freezer door Installed new ice door assembly and crank. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Screwdrivers
Joseph P Severna Park , MD November 15, 2019 Appliance: General Electric Refrigerator GSS23SGSBSS Ice dispenser door would not close causing ice in chute Harry Homeowner, not a professional, but the consensus seemed to be that the solenoid is responsible for closing the flap after the ice is dispensed. I could close manually, but it would not close on its own. The bracket that holds the solenoid in place is completely rusted, and some of the rust made its way into the piston/cylinder and must have worn itself out. Cleaning and oiling the existing did not work. New solenoid fixed the problem but made sense to replace the springs, flap, etc since they were only a few bucks while I was in there. It seems like a stupid design to have a metal bracket holding the solenoid in place. This thing should really be plastic or different materials that won't rust. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Alfred M Saint Simons Island , GA August 21, 2015 Ice cube dispenser door would not close Watched a video on line from Applinance Parts Pro. Seemed simple enough so I ordered the parts necessary. And after arriving the door was working within 20 minutes. It really was that easy. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
John C J Newland , NC September 27, 2020 Appliance: General Electric Refrigerator GSS22WGMCWW Frost buildup ice chute. Replaced most of the internal parts including solenoid, control arm flapper, and the springs. The solenoid was the main problem. It had corroded so bad would not move up and down freely. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Pliers, Screwdrivers
