Parts for Bosch HUI56551UC/01: Hood Asy Parts

This electronic control module manages a dishwasher's wash cycles, timers and user inputs so the appliance runs the selected program reliably. Replaces a failed or unresponsive main control to restore normal operation. What it does:

• Controls cycle timing, pumps/heaters and valve actuation via onboard relays
• Receives input from the control panel and sensors to start and advance programs
• Common symptom: dishwasher won't start or respond to touchpad commands
• Common symptom: cycles stop mid-cycle, or unit shows control-related error codes

• Disconnect power to the appliance before servicing to avoid shock or damage
• Handle board by edges and avoid static discharge; use ESD precautions if available
• Refer to the appliance service manual for model-specific wiring and mounting steps

This support mounting bracket secures internal components in their correct position to reduce movement and wear. It restores proper alignment and helps prevent vibration, noise, or intermittent operation caused by a loose or broken support. What it does:

• Holds a dishwasher assembly or internal panel in place to maintain alignment
• Reduces vibration and rattling from loose components
• Prevents wear or wiring strain caused by shifting parts
• Common symptom: noise, misalignment, or parts that shift during a cycle

• One support

• Disconnect power and water supply before beginning any repair
• Use basic hand tools; replace only the damaged support with the same orientation
• If fasteners are corroded or damaged, replace them with OEM-equivalent hardware

This terminal is an electrical connector used to restore a secure wiring connection in compatible Bosch appliances. Replacing a damaged or loose terminal helps prevent intermittent power, arcing, or loss of function at the connection point. What it does

• Provides a secure point to attach appliance wiring and maintain electrical continuity.
• Replaces corroded, bent, or burned terminals that can cause poor connections.
• Helps stop intermittent power, sparking at the connection, or components failing to receive power.
• Restores a reliable contact between wiring and the appliance control or component.

• Disconnect power at the breaker or unplug the appliance before attempting service.
• Verify correct terminal orientation and secure the wire firmly; avoid loose or exposed conductors.
• Use proper tools and ensure the replacement part matches the original; do not force or modify.

The Lamp Halogen is an OEM component specifically designed for Bosch range hood lighting. As the primary light source, it illuminates the cooking surfaces below. Working seamlessly with the lamp housing and electrical system, the halogen lamp provides consistent task lighting.

Causes of failure can relate to bulb burnout from continuous usage, damage from power surges or fluctuations, as well as accidental breakage.

Symptoms of a bad halogen lamp include:

• Dim or unresponsive lighting when turned on
• Visual defects like hot spots or flickering
• Complete lack of illumination from one or both bulbs
• Premature bulb burnout quickly after replacement

This OEM Bosch halogen lamp restores crucial lighting functionality. It is compatible with Thermador, Gaggenau, and some Broan-NuTone range hood models.

This stress relief secures and protects appliance wiring where it passes through a panel or housing, reducing wear and preventing cable chafing for safer, longer-lasting electrical connections. What it does:

• Holds and guides a power or signal cable to prevent pulling and abrasion
• Protects wiring insulation at entry/exit points to reduce short or grounding risk
• Helps prevent intermittent electrical faults caused by loose or damaged wires
• Commonly used where cords pass through housings, brackets, or terminals

• One stress relief part (single piece)

• Disconnect all power before accessing wiring or electrical components
• Replace only if original shows cracks, deformation, or loose fit; ensure proper seating
• Basic hand tools may be required; route wires to avoid sharp edges and secure firmly
