Parts for Frigidaire 72-2547-23-02: 09 - Lower Body Parts

The Oven Light Socket is an OEM replacement part for Frigidaire electric ranges and wall ovens. It houses the bulb that illuminates the interior of the oven cavity.

Causes of a bad light socket can include a loose or broken connection due to regular use, scorched or burnt terminals from overheating, or damage from moisture.

Symptoms of a bad light socket include:

• The oven light not turning on when activated
• Flickering or intermittent bulb operation
• Signs of corrosion or oxidation around the bulb base
• Excessive heat emission from the light area

This OEM Frigidaire replacement part is also compatible with ranges and wall ovens from Electrolux, Gibson, and Kelvinator.

The Light Bulb (40W) is an OEM part for Frigidaire appliances. Specifically designed to fit and function with Frigidaire models, this 40-watt bulb illuminates the interior of your oven, making it easier to check on the progress of your baking or roasting without opening the oven door.

Over time, oven light bulbs can burn out or be damaged from high temperatures or accidental bumps during cleaning or cooking. A functioning light bulb is crucial for the optimal operation of your oven, enhancing visibility and improving your cooking experience.

Symptoms of a bad Light Bulb include:

• The oven interior remains dark when the light switch is engaged.
• Flickering light, indicating a loose connection or nearing the end of the bulb's lifespan.
• Completely non-functional light, which can hinder your ability to monitor cooking progress.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

This replacement power cord restores electrical connection to the appliance so it can receive mains power safely. Use it when the original cord is frayed, damaged, or no longer providing a reliable connection. What it does:

• Replaces a damaged or worn appliance power cord to restore reliable power
• Resolves intermittent power, sparking at the plug, or visible cord damage
• Provides the necessary insulated conductors for safe appliance operation
• Works as a direct cord-replacement when the original cord is defective

• Always disconnect power at the breaker or unplug the appliance before installing
• Route the cord and secure strain relief per the appliance's original routing to prevent pinching
• Ensure the cord's connector and grounding match the appliance's inlet before connecting

This replacement wire clip secures refrigerator wiring to the cabinet side to keep harnesses organized and protected from abrasion. It helps prevent loose or pinched wires that can cause noise or intermittent electrical issues. What it does:

• Holds wiring harnesses against the refrigerator bodyside to prevent movement and wear
• Reduces rattling or vibration caused by loose wires
• Helps prevent chafing or pinching that can lead to intermittent connections or shorts
• Keeps wires routed away from moving parts and sharp edges

• One wire clip

• Disconnect power to the appliance before servicing to avoid shock
• Access may require removing an interior panel or trim; keep fasteners organized
• Clip typically snaps into a matching slot or fastener point; align wiring and press clip into place

This flue directs exhaust and heat away from the oven cavity to the range vent path, helping maintain proper ventilation and combustion airflow. It replaces damaged or corroded flue components to restore safe venting and oven performance. What it does:

• Channels heat, smoke and combustion exhaust from the oven cavity toward the vent path
• Helps prevent heat buildup behind the oven control area and adjacent panels
• Can reduce visible soot, odors or poor venting caused by a cracked or bent flue
• Supports proper burner combustion airflow in gas models when correctly installed

• One replacement flue

• Disconnect the appliance from power (and gas supply on gas models) before starting work
• Access typically requires removing the oven back panel or drop-in cooktop; keep track of mounting screws and gaskets
• Wear gloves to protect from sharp sheet-metal edges and use caution aligning the flue to vent openings
• After installation, restore power/gas and verify normal oven operation and proper venting; check for signs of leaks or loose fasteners

This part has been discontinued by the manufacturer and is no longer available.

This part has been discontinued by the manufacturer and is no longer available.

The Oven Rack is an OEM part for Frigidaire ovens, designed to provide a stable and durable surface for baking and roasting inside the appliance. This rack is essential for facilitating proper air circulation around food, ensuring even cooking and optimal baking results. The rack measures about 23 inches wide by 16 inches deep.

The primary reasons for replacing an Oven Rack usually involve normal wear and tear from regular use, including the effects of high heat, spills, and the burden of heavy pots and pans.

Symptoms of a needing replacement Oven Rack include:

• Warping or bending from heat exposure or the weight of heavy cookware, which can affect cooking results
• Rust or corrosion that might not only compromise the integrity of the rack but also pose a risk of contaminating food
• Difficulty in sliding the rack in and out smoothly, which could indicate a misshapen rack or damage to its guides

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

This replacement clip secures components within your appliance. Replacing a broken, bent, or missing clip restores a firm hold on panels or assemblies to prevent shifting and reduce vibration noise.

• Holds specified parts or panels in place where a clip is called out in the assembly
• Helps maintain proper alignment and minimizes rattles/vibration
• Direct replacement for a damaged or missing clip
• Common symptoms: loose or misaligned parts, rattling during operation, clip visibly broken or missing

• Disconnect power before service; also shut off gas/water supplies
• Note the original clip orientation and placement; take a photo for reference
• Use needle-nose pliers for removal/installation; avoid overbending or deforming the clip
• Inspect mating parts for wear or damage and ensure the clip seats fully

This part has been discontinued by the manufacturer and is no longer available.

This part has been discontinued by the manufacturer and is no longer available.

Note: ONE screw only, order as needed.

Note: ONE screw only, order as needed.
