Parts for Lg LDE4415BD/00: Lower Cavity Parts

This flat hardware washer helps secure bolts and fasteners in the washer assembly to keep panels and components seated and stable. Simple replacement can restore proper clamping and reduce movement around joints. What it does:

• Provides a smooth bearing surface under nuts or bolt heads to distribute load
• Prevents fasteners from loosening due to vibration or movement
• Helps maintain proper alignment of panels and small components
• Worn, corroded, or missing washers can cause loose panels, increased noise, or premature fastener wear

• Replace with the same type and size washer removed from the appliance
• Use basic hand tools; support the assembly to avoid stress on other components
• If corrosion or thread damage is present, replace the bolt/nut as well
• Disconnect power and follow manufacturer safety guidance before servicing

The Common Nut is an OEM part for LG ranges. It secures the fan blade to the motor shaft. This nut maintains the fan's stability and preventing it from becoming dislodged during use.

Causes of a bad common nut can include loosening over time due to vibration, improper installation, or damage from impact or mishandling.

Symptoms of a bad common nut include:

• Excessive noise or vibration from the fan assembly
• The fan blade becoming loose or detached, causing poor air circulation
• Potential risk of the fan blade becoming a projectile if completely detached

This OEM LG part is also compatible with some Kenmore models.a

This customized screw secures appliance components where a standard fastener won't fit, helping keep panels, brackets and small assemblies stable. It's a direct-fit replacement when the original specialized screw is missing or damaged. What it does:

• Fastens and holds appliance panels, brackets or small parts in place
• Prevents rattling, loose trim or misaligned components caused by a missing or stripped screw
• Matches the OEM fit and thread pattern for proper engagement and alignment
• Used in locations that require a non-standard or customized fastener

• Disconnect power and water before servicing the appliance
• Use the correct screwdriver or driver bit to avoid stripping the head
• Tighten securely but do not overtighten; overtightening can strip threads or crack parts
• Keep removed hardware organized so you can reinstall in the original location

This hardware washer helps distribute fastener load and maintain proper spacing in your LG appliance. Replacing a missing or worn washer restores secure mounting and alignment, reducing vibration and rattling from loose assemblies.

• Distributes the load of a screw or bolt and protects mating surfaces to maintain alignment
• Helps keep components secure and at the correct spacing
• A damaged or missing washer can lead to loosening, vibration, or rattling during operation
• Ensures correct hardware stack-up during reassembly after service

• Disconnect power and shut off water or gas before servicing
• Note the order and orientation of any washers/spacers; take a reference photo
• Use the correct driver or wrench and tighten snugly—do not overtighten
• Replace companion hardware if corroded, stripped, or damaged

The Common Nut is an OEM part for LG ranges. It secures the fan blade to the motor shaft. This nut maintains the fan's stability and preventing it from becoming dislodged during use.

Causes of a bad common nut can include loosening over time due to vibration, improper installation, or damage from impact or mishandling.

Symptoms of a bad common nut include:

• Excessive noise or vibration from the fan assembly
• The fan blade becoming loose or detached, causing poor air circulation
• Potential risk of the fan blade becoming a projectile if completely detached

This OEM LG part is also compatible with some Kenmore models.a

This factory-specified fastener secures designated panels and components, restoring a precise fit and helping keep your appliance solid and quiet. Replace a missing, stripped, or rusted original with the correct OEM match for the specified locations.

• Secures brackets, panels, and internal parts where this part number is called out
• Replaces damaged, stripped, corroded, or lost screws
• Helps reduce looseness and vibration that can cause rattling noises
• Exact OEM replacement for positions requiring this specific screw

• Disconnect power and shut off water/gas before servicing
• Match to the removed screw and install only in the locations specified for this part number
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening, especially into plastic
• If multiple screws are involved, start all fasteners before final tightening to ensure alignment

The Oven Rack is an OEM part for LG ranges. This part provides a stable surface for placing cookware during baking, roasting, and broiling.

Causes of a bad oven rack can include exposure to high temperatures over time, which can weaken the metal, or accidental damage that causes bending or warping.

Symptoms of a bad oven rack include:

• Warping or bending of the rack
• Difficulty sliding the rack in and out of the oven
• The rack not sitting level within the oven

This OEM LG part is also compatible with some Kenmore models.

This single-wire harness routes power and signals between components, restoring reliable electrical connections on compatible LG appliances. It replaces a damaged or worn wiring link to help resolve power and control issues. What it does:

• Provides a direct wiring connection between appliance components so signals and power travel reliably.
• Replaces brittle, frayed, or corroded wiring that can cause intermittent operation or failure to start.
• Helps restore proper control-board communication when a damaged harness is the source of faults.
• Reduces risk of short circuits caused by exposed or broken wires when installed correctly.

• Disconnect power before starting any repair.
• Photograph or label wire locations before removing the old harness to ensure correct reassembly.
• Route harness away from sharp edges and heat sources; secure with clips or ties as needed.
• If connectors are tight or corroded, inspect mating terminals and replace damaged terminals rather than forcing connections.

The Motor, AC Fan is an OEM part for LG ovens. This fan motor is responsible for circulating air within the oven cavity, ensuring even heat distribution for consistent cooking and baking results. It helps maintain the oven’s temperature by moving hot air around, which is especially important for convection ovens.

Over time, the fan motor can wear out or become faulty due to continuous use, exposure to high temperatures, or electrical issues. When the fan motor fails, it can lead to uneven cooking and potential overheating of the oven.

Symptoms of a bad oven motor, AC fan include:

• Uneven cooking or baking results
• Unusual noises coming from the oven during operation
• The oven taking longer to preheat
• The fan not spinning or running intermittently
• Error codes related to fan or airflow issues

This OEM LG part is also compatible with Sears/Kenmore models.

This replacement ring secures or positions a nearby appliance component to restore proper alignment and stable operation. It's a small but important part that helps reduce excess movement and related wear. What it does:

• Holds or locates a mating component to prevent unwanted movement or misalignment
• Helps reduce vibration and knocking noises caused by loose parts
• Restores correct spacing that maintains smooth mechanical operation
• Can prevent accelerated wear on adjacent parts when functioning properly

• Disconnect power (and water supply if applicable) before beginning any repair
• Access location may require removing panels or trim; keep fasteners organized
• Inspect surrounding parts for wear or damage and replace if needed

The Convection Fan Blade is an OEM replacement part for LG ovens. It works by circulating hot air throughout the oven, reducing cold spots and promoting consistent temperatures.

Causes of a malfunctioning Convection Fan Blade can be wear and tear from regular use, the accumulation of debris hindering the blade’s rotation, or mechanical issues impacting the fan motor or blade alignment.

Symptoms of a bad Convection Fan Blade include:

• Uneven cooking or baking, leading to partially cooked food
• Noises emanating from the oven during operation, indicating possible damage or obstruction
• The fan not rotating or moving irregularly, signaling mechanical issues

This OEM LG part is also compatible with Sears/Kenmore oven models.

This Fan Blade is an OEM part for LG microwaves. It is a critical component designed to circulate air within the microwave, aiding in heat dissipation and ensuring even cooking.

Fan blades in microwaves can suffer from wear, imbalance, or damage due to regular use or accumulation of debris. A malfunctioning fan blade can lead to inadequate ventilation, affecting the microwave's cooking efficiency and potentially causing overheating.

Symptoms of a bad fan blade include:

• Unusual noises during operation, such as rattling or buzzing, indicate a loose or damaged blade.
• The microwave overheating or shutting off prematurely.
• Inconsistent cooking or hot spots in food suggest poor air circulation.
• The fan not starting, or stopping unexpectedly during use.
• Visible signs of damage or wear on the blade.

This OEM LG part is also compatible with some Sears/Kenmore models.


This sheath heater is the protective sleeve that surrounds a dryer's heating element, helping keep the element secured and directing heat where needed for efficient drying. Replaces a worn or damaged sheath to restore proper heater alignment and airflow. What it does:

• Protects and supports the heating element assembly to prevent contact with other components.
• Helps direct heat and airflow through the dryer drum for consistent drying performance.
• Commonly replaced when a cracked or melted sheath is found during heater repairs.
• Installed alongside a heating element or thermal fuse when troubleshooting no-heat conditions.

• Disconnect power before servicing; electric dryers present shock and burn hazards.
• Access may require removing the dryer drum and control panels—follow the factory service manual.
• Inspect the heating element and wiring while replacing the sheath; replace damaged components as needed.

The Heating Element is an OEM part for LG electric ranges. It serves a critical cooking function by using electric current to generate heat energy that cooks food inside the oven cavity. The heating element is constructed from flame-resistant and durable materials precisely designed to withstand high temperatures in a clean efficient manner.

Causes of a bad heating element can include mineral deposits on coils, cracks from overheating, or general wear over extended use.

Replacing a faulty element restores dependable oven performance.

Symptoms of a bad element include:

• Inefficient or uneven cooking temperatures
• Longer baking and cooking times
• Cracking or sagging coils affecting heat output
• Potential safety issues if damage exposes live wires

This element also fits the heating designs used in Jenn-Air and Frigidaire electric ovens.

This idler bracket mounts the idler pulley or roller in your appliance's tensioning system, keeping a belt or cable aligned and properly tensioned for consistent operation. A bent or worn bracket can cause noise, slippage, or loss of motion.

• Secures the idler pulley/roller in the correct position
• Maintains proper belt/cable tension and alignment
• Helps reduce squealing or squeaking from friction/misalignment
• Can address belts/cables coming off or intermittent movement in the drive mechanism

• Disconnect power; also shut off gas or water before servicing
• Access the tensioner area and note the belt/cable routing and spring orientation
• Relieve tension, remove the old bracket, and transfer the pulley/roller and any spring or hardware as required
• Reinstall the bracket, ensure smooth free movement, route belt/cable correctly, and test operation

This foot is a small rubber base pad that supports and stabilizes the appliance on the countertop or cabinet surface. Replacing a worn or missing foot helps keep the unit level and reduces vibration and slipping.

• Provides stable, non-slip support on flat surfaces
• Helps keep the appliance level for proper operation
• Replaces missing, cracked, or flattened feet
• Can reduce vibration, rattling, or shifting during use

• Unplug the appliance before servicing
• Turn the unit on its side/back for access to the base
• Pull off the old foot and press the new one firmly into place (some models may use adhesive or a tab fit)
• Verify the unit sits level; replace additional feet as needed
