Parts for Thermador PRD486GDHC/08: Main Assy Parts

This is the dishwasher back panel that covers and protects the appliance's rear components while providing service access. It keeps wiring and mechanical parts enclosed for safer operation and easier repairs. What it does:

• Shields internal components from debris and accidental contact
• Provides an access point for servicing rear-mounted parts
• Helps maintain proper airflow and component placement at the rear of the unit
• Visible damage, holes, or loose mounting can cause rattling or expose components

• One back panel

• Disconnect power before removing or installing the panel
• Turn off water supply and allow the appliance to sit before servicing
• Keep screws and fasteners organized; compatible mounting hardware is available
• Wear gloves to protect against sharp sheet-metal edges and follow all safety guidance in the appliance manual

This cable harness routes power and signals between key components to restore reliable electrical connections and normal appliance operation. Replace a damaged harness to fix intermittent power, control failures, or non-responsive functions. What it does:

• Provides the multi-conductor wiring path that links control boards, sensors, and motors
• Carries low-voltage signals and/or line power needed for normal appliance functions
• Commonly replaced when wires or connectors are damaged, burned, or corroded
• Can resolve symptoms such as intermittent operation, no power to components, or control errors

• Disconnect all power before accessing wiring or controls to avoid shock
• Route harness along original clips and channels to prevent pinching or chafing
• Inspect connectors for damage and replace if terminals are loose or burned

This ignition cable connects the stove's spark electrode to the ignition system so burners ignite reliably. It replaces a damaged or degraded lead to restore spark delivery and consistent lighting. What it does:

• Transfers ignition voltage from the module to the burner electrode so sparks form at the burner
• Helps stop intermittent or no-spark symptoms when the wire is cracked or corroded
• Prevents arcing caused by insulation damage or improper routing
• Restores normal ignition behavior when the original cable is worn or burned

• One ignition cable

• Disconnect power and turn off gas supply before starting any service
• Inspect routing and connectors; replace only if the wire or insulation is damaged
• Keep the cable away from high-heat areas and sharp edges to prevent future damage
