Parts for Thermador PRL484ECG02: Outside Cabinet Parts

This base panel replaces the lower kickplate on compatible Bosch dishwashers to restore a finished appearance and protect internal components at the machine's base. Durable stamped metal fits the cabinet opening and hides wiring and mounting hardware. What it does

• Covers and protects the dishwasher's lower cavity, shielding wiring, motors, and valves from debris.
• Restores the appliance's finished look when an old panel is dented, bent, or missing.
• Stops drafts and reduces light coming from under the unit that can indicate a missing panel.
• Helps prevent small objects from falling into the service area and causing noise or damage.

• Disconnect power to the appliance before starting any work; follow all safety instructions for your model.
• Removal typically requires removing the toe-kick or lower screws and then fastening the new panel with existing clips/screws.
• Handle edges carefully; wear gloves to avoid cuts on sheet metal.
• Replace only with manufacturer-specified fasteners.

This cable harness routes power and signals between key components to restore reliable electrical connections and normal appliance operation. Replace a damaged harness to fix intermittent power, control failures, or non-responsive functions. What it does:

• Provides the multi-conductor wiring path that links control boards, sensors, and motors
• Carries low-voltage signals and/or line power needed for normal appliance functions
• Commonly replaced when wires or connectors are damaged, burned, or corroded
• Can resolve symptoms such as intermittent operation, no power to components, or control errors

• Disconnect all power before accessing wiring or controls to avoid shock
• Route harness along original clips and channels to prevent pinching or chafing
• Inspect connectors for damage and replace if terminals are loose or burned

This cable harness connects a dishwasher's electrical components to the control board, restoring reliable signal and power routing for proper operation. Designed as a direct-fit replacement to replace damaged or worn wiring. What it does:

• Routes power and control signals between the control board and components such as pumps, valves, or sensors
• Restores intermittent or failed electrical connections caused by frayed wires or broken terminals
• Helps stop issues like controls not responding, lights not working, or certain cycles not starting when the harness is faulty
• Maintains factory routing and connector fit for correct plug-in installation

• One replacement cable harness as shown

• Disconnect power and water before beginning any repair
• Verify connectors match and route wiring according to original harness path; secure with clips or ties as needed
• Handle connectors carefully to avoid bending pins; replace if terminals are corroded or damaged
