Parts for Thermador PRG366JG/03: Oven Assy Parts

This surface burner replaces a damaged or worn cooktop burner to restore even, reliable heating for gas ranges and cooktops. It fits into the burner base and provides the proper flame pattern for cooking performance. What it does:

• Directs gas to the cooktop slot so the burner produces a controlled flame for cooking
• Restores even heating when an old burner causes uneven cooking or hot spots
• Helps eliminate weak or irregular flames caused by dents, warping, or corrosion
• Works with the existing burner base and ignition system when correctly matched

• One surface burner

• Turn off the appliance's gas and power before removing or installing the burner
• Remove grate and any clips or screws holding the old burner; seat the new burner securely in the burner base
• Clean surrounding surfaces and ports of debris before installation to ensure proper flame pattern

The Bake Igniter is an OEM part for Bosch wall ovens and ranges. Located at the bottom of the oven cavity, it generates the radiant heat needed to initiate the bake burners.

Causes of a bad bake igniter can include failure of the delicate calrod-style heating element from prolonged high-temperature exposure over time.

Symptoms of a bad bake igniter include:

• Inability to ignite or maintain ignition of the bake burners
• Improperly or unevenly heated oven cavity
• Cool or cold spots appearing on bake results
• Igniter glows, but fails to ignite

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The Lamp is an OEM part for Bosch ranges and ovens. The range lamp provides visibility when viewing food through the oven window or checking on items cooking on the stove.

Causes of a bad range lamp can include normal wear and tear over time, as well as accidental damage from impact or handle mishandling.

Symptoms of a bad range lamp include:

• Diminished light that does not adequately illuminate the cooking space
• Flickering or unstable illumination
• A burned out or broken bulb

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The temperature sensor is an electronic probe that monitors internal appliance temperature and reports it to the control so it can regulate operation. Replacing a failed sensor restores more accurate temperatures and can clear temperature-related error codes. What it does:

• Senses internal temperature via resistance changes and sends the signal to the electronic control
• Helps the control reach and maintain the set temperature during operation
• Common failure symptoms: too hot/cold, won't reach set temp, long/short cycles, temperature error codes
• Can cause preheat to stall or the unit to shut off early (model dependent)

• Includes: 1 temperature sensor

• Disconnect power at the breaker before servicing
• Location and access vary by model; typically mounts with screws or a clip and connects to a 2-wire harness
• Handle the connector and wiring carefully; route and secure away from hot or moving parts
• After installation, clear stored errors and run a test cycle to proper readings

This socket is an electrical connector used to join wiring or plug-in components, restoring a secure connection for reliable appliance operation. It replaces a worn or damaged socket to help prevent intermittent power or component failure. What it does:

• Provides a secure electrical connection between wiring and the appliance component
• Restores proper contact when a loose, corroded, or broken socket causes intermittent operation
• Helps prevent arcing or poor connections that can lead to component failure
• Used where a plug-in or push-fit electrical connection is required

• One socket

• Disconnect power to the appliance before inspecting or replacing the socket
• Replace only with the exact socket type specified for your appliance

This bottom cavity cover replaces the removable floor panel under the oven cavity to protect internal components and help contain spills for easier clean-up. It restores the oven's lower interior surface for safe, tidy operation. What it does:

• Covers and protects the oven cavity floor and components from drips, crumbs, and direct heat exposure
• Helps keep the lower oven area clean and makes wiping up spills simpler
• Supports proper airflow path and component protection when installed
• Commonly replaced when the original cover is dented, warped, or damaged

• One bottom cavity cover

• Turn off and disconnect power to the appliance before starting any repair
• Allow the oven to cool completely; use gloves to handle sharp edges
• Installation typically requires removing the oven racks and sliding the cover into position; keep fasteners if present

This orifice is the small, calibrated gas jet used in the oven burner to control natural gas flow for proper combustion and consistent heat. It replaces a worn or clogged orifice to help restore reliable oven ignition and baking performance. What it does:

• Directs and meters natural gas to the oven burner for correct flame size and stability
• Helps resolve symptoms like weak or uneven burners, weak ignition, or yellow/sooting flames when caused by a restricted orifice
• Used on the oven top/burner assembly where a #38 sized jet is specified
• Fits into the burner orifice holder and works with the existing regulator and valve

• Install only after shutting off the gas supply and following all safety procedures; check for leaks with a soapy water solution or approved leak detector
• Use correct tools and avoid damaging the orifice tip; thread carefully to prevent cross-threading
• Do not modify the orifice; replace with the exact specified size to maintain safe operation

This OEM replacement part is a motor assembly for ovens. The motor assembly is the main motor that powers the oven fan which is responsible for maintaining and adjusting the temperature in an oven. If the oven is no longer heating properly, turning on, or maintaining temperature, then the motor assembly will need to be replaced.To replace this part, make sure that the oven is unplugged. After it has been powered off, proceed to pull the oven out and away from the wall. Once moved, uninstall the back panel of the oven by removing the panel's mounting screws. After detaching the back panel, locate the motor housing on the back of the oven. Unthread the screws that hold the housing in place. Once removed, locate the mounting brackets that hold the motor in place and remove the screws that attach to the motor. Pull the old motor out of its place and install the new motor. Reinstall the back panel and restore power to the appliance.This genuine replacement part is sold individually and is compatible with Bosch, Gaggenau, and Thermador brand ovens.

This replacement screw fastens appliance components to restore secure assembly and stable operation. It's a direct-fit fastener used where the original screw has stripped, corroded, or been lost. What it does:

• Secures panels, brackets, or small assemblies to prevent vibration and misalignment
• Restores proper fit where a damaged or missing screw causes rattling or loose parts
• Provides the correct fastening point for unchanged OEM mounting locations
• Works as a like-for-like replacement when the original screw is worn or missing

• Screw

• Turn off and unplug the appliance before beginning any repair
• Use the matched screwdriver or driver bit to avoid stripping the head
• Replace with the same thread engagement depth; do not force or overtighten
• Repair with the appropriate method before installing
