Parts for ESA3109L: Room Air Conditioner Parts

This motor run capacitor helps your appliance's compressor or fan motor start and keep running for consistent cooling and operation. Replacing a failed capacitor restores normal motor performance and can stop intermittent operation. What it does:

• Provides the electrical phase shift needed for compressor/fan motors to start and run
• Commonly associated with symptoms like hard-starting or non-starting compressor, humming motors, or intermittent cooling
• Helps stabilize motor operation to prevent frequent cycling and reduced efficiency
• Works as the replaceable electrical component that interfaces with the motor start circuit

• Disconnect power at the breaker before accessing electrical components
• Discharge the capacitor before handling to avoid shock; use insulated tools and confirmed procedures
• Verify terminal fit and orientation; match voltage and microfarad ratings from the existing capacitor

Accordion screen for the appliance ventilation path that traps lint, dust and debris to protect the blower and help maintain proper airflow—replacing a torn or clogged screen can restore performance and reduce odors. What it does:

• Traps lint, dust and debris before they reach the blower and internal components; common signs of a failing screen include visible buildup and reduced airflow.
• Protects the fan and motor from larger particles that can cause noise or premature wear.
• Helps maintain efficient ventilation and can reduce lingering odors caused by trapped debris.
• Flexible accordion design fits into the filter housing; inspect for tears, holes, or heavy buildup.

• Disconnect power (unplug or shut off breaker) before accessing the filter area.
• Locate the filter/vent housing; remove the access grille or cover to remove the old screen and install the new one.
• Ensure the replacement screen seats fully with no gaps before restoring power.
• Do not operate the appliance with a damaged or improperly seated screen.
