Parts for Whirlpool WRB543CMJV00: Shelf Parts

Body control is the appliance's main console control board that interprets user inputs and directs functions; replacing this board restores reliable control when the console is unresponsive, erratic, or fails to start selected cycles. What it does:

• Interprets button and touchpad commands and sends control signals to appliance components.
• Starts and stops cycles by signaling motors, heaters, valves, or other subsystems.
• Can cause unresponsive controls, no-start conditions, or erratic cycle behavior when failing.
• May result in blank or intermittent display and unexpected shutdowns.

• Disconnect power to the appliance before servicing to avoid shock or damage.
• Handle the board by its edges and use electrostatic discharge (ESD) precautions when possible.
• Confirm wiring harness connectors are fully seated and match the board before powering up.

This replacement access cover protects internal components and wiring while providing a finished appearance for the appliance. It helps keep parts secure and prevents debris from entering while the appliance is in use. What it does:

• Covers and shields control or component areas to prevent contact with wiring and moving parts
• Prevents debris buildup and reduces exposure to dust and moisture
• Stops rattling or vibration caused by a loose or damaged cover
• Restores a clean, finished look after damage or removal

• One replacement access cover

• Disconnect power (and gas if applicable) before servicing the appliance
• Remove fasteners that secure the old cover and transfer any retained clips or brackets to the new cover if required
• Handle edges carefully — use gloves to avoid cuts from sheet metal
• Reassemble panels and verify the cover sits flush and fasteners are secure before restoring power

This utility pan is a replacement drip tray that collects spills and runoff to protect the appliance cabinet and flooring. It restores proper containment to help prevent water damage and simplify cleanup. What it does:

• Replaces a worn, cracked, or missing utility/drip pan to restore containment
• Catches water, detergent, or other liquids that escape during normal use
• Helps reduce the chance of leaks reaching the cabinet or floor below the appliance
• Fits into the appliance's lower compartment to provide a stable, form-fit tray

• Turn off and unplug the appliance before removing panels or replacing the pan
• Remove any racks or components blocking access, then lift out the old pan and set the new pan in place
• Inspect surrounding seals and fasteners while installing; replace any damaged items separately
• If you smell gas, see liquid pooling, or detect electrical issues, stop.

This hot foil assembly supplies the heating element used in the refrigerator's bottom drawer area to maintain proper operation of drawer components. It replaces a worn or damaged foil heater to restore original function. What it does:

• Provides localized heat where the bottom drawer assembly requires it for proper operation
• Restores heating function lost from a damaged or open foil strip
• Helps reduce malfunctions caused by broken or burned foil traces
• Compatible as a direct replacement for the listed OEM assembly

• One bottom drawer hot foil assembly

• Disconnect power to the appliance before attempting any repairs
• Access may require removing drawer trim and interior panels—refer to the service manual
• Handle the foil element and connectors carefully to avoid damage

This icemaker is the replaceable ice-making assembly for compatible refrigerators, restoring ice production when the original unit fails. It installs in the freezer and cycles to form and harvest ice automatically. What it does:

• Replaces the refrigerator's failed icemaker to resume regular ice production
• Houses the mold and harvest mechanism that forms and ejects ice cubes
• Works with the freezer's fill and water system to allow normal ice fills
• Commonly used when the icemaker stops making ice, only makes partial batches, or stops cycling

• Disconnect power and shut off the water supply before starting any repair
• Handle wiring and the fill tube carefully; match connectors to avoid wiring errors
• Follow OEM instructions for mounting location, alignment, and test cycles after installation
• If water or leak issues are present, check the fill line and valve separately before replacing the icemaker
