Parts for Kitchenaid KUBR314KBS00: Unit Parts

This electronic control box is the main control assembly that manages cycle selection, timing and electronic functions for the appliance. Replacing a faulty control box restores normal control responsiveness and cycle operation. What it does:

• Receives user inputs and runs selected cycles by sending signals to motors, valves and switches
• Controls timing, cycle progression and display/indicator functions
• Commonly replaced when the appliance is unresponsive, shows control errors, or cycles stop unexpectedly
• Helps resolve intermittent operation, unresponsive buttons, or random shutdowns when identified as the fault

• One control box (electronic control assembly)

• Disconnect power to the appliance before servicing to avoid shock or damage
• Handle the board carefully; avoid touching contacts and use anti-static precautions if possible
• Verify connections and wiring harness orientation before reinstalling panels

This replacement dryer tube channels heated air from the dryer cabinet to the lint filter/blower and exhaust path, restoring proper airflow and helping the cycle dry clothes efficiently. Use it when the original tube is cracked, crushed, or blocked. What it does

• Directs dryer airflow from the drum/blower chamber to the lint trap and exhaust.
• Helps maintain proper venting to prevent overheating and inefficient drying.
• Reduces air leaks that can cause longer dry times or hot spots.
• Minimizes lint buildup in the cabinet by providing a smooth, routed path for debris to the lint filter.

• One dryer tube

• Disconnect power (and gas supply if applicable) before servicing; ensure the dryer is completely powered off.
• Remove front or rear access panel as required to reach and replace the tube; keep fasteners for reassembly.
• Inspect adjacent seals and clamps; replace any damaged gaskets or worn clamps for a secure fit.
• Use gloves to avoid sharp sheet-metal edges and run a short test cycle to ensure proper airflow and quiet operation.
