Parts for Whirlpool WUB50X24EM00: 05 - Unit Parts

This drain tray collects and channels wastewater below the dishwasher tub to help keep the cabinet floor dry and prevent water from pooling under the appliance. Replaces a worn or damaged tray to restore proper drainage path. What it does:

• Captures and routes discharged water away from the cabinet base to the dishwasher drain system
• Helps reduce leaks and pooling that can occur from cracks or holes in the original tray
• Works with the dishwasher drain/sump area to maintain proper water flow during cycles
• Can prevent damage to flooring and cabinetry when functioning correctly

• One drain tray

• Disconnect power to the appliance before starting any repair; shut off water if required
• Access typically requires removing the toe kick or lower access panel and tilting or supporting the dishwasher
• Inspect surrounding seals, hose connections and mounting points; replace any damaged parts to prevent future leaks

This Defrost Timer cycles the unit between cooling and automatic defrost. Replace it if your appliance won't defrost or stays stuck in defrost, causing frost buildup, warm temperatures, or intermittent/no cooling.

• Controls automatic defrost intervals by switching from cooling to defrost and back
• Supplies power to the defrost circuit/heater during the defrost portion of the cycle
• Common failure symptoms: heavy frost on the evaporator/back wall, warm fresh-food section, runs constantly with no defrost, or no cooling if stuck in defrost
• Stop advancing through cycles or advance intermittently

• Disconnect power before servicing; electrical components can hold live voltage
• Location varies by model: typically in the control housing inside the refrigerator or behind a rear/service panel
• Photograph/label wire positions and transfer connectors one at a time to the new timer
• Mount securely, restore power, and verify normal cooling/defrost operation

This sealer is a flexible sealing strip used to restore a tight fit where panels or doors meet, helping reduce leaks, drafts and moisture transfer. It replaces worn or damaged seals to help appliances run as intended. What it does:

• Creates a compression seal along a door or panel to prevent air and moisture leakage
• Helps maintain proper temperature control and reduces unwanted drafts
• Stops visible gaps caused by cracked, torn or flattened seal material
• Can reduce short-cycling related to poor sealing by improving the enclosure fit

• Disconnect power and water before starting any repair
• Remove the old seal carefully to avoid damaging surrounding trim or clips
• Clean mating surfaces thoroughly before installing the new sealer for best adhesion and fit
• Some installations require adhesive, retainer clips, or light trimming for a correct fit

This thermostat is the temperature control that helps maintain consistent cooling in your refrigerator. Replacing a worn or faulty thermostat restores stable interior temperatures and prevents food spoilage from fluctuating temps. What it does:

• Senses cabinet temperature and cycles the compressor or cooling system to maintain the set temperature
• Prevents the refrigerator from running constantly or failing to run when temperature rises
• Common symptom of failure: interior too warm or too cold despite correct settings
• Can cause excessive compressor cycling or inconsistent cooling when defective

• One thermostat

• Disconnect power before accessing the control area to avoid electrical shock
• Remove any trim or access panels to reach the thermostat; note or photograph wire connections before disconnecting
• Reconnect wires to the matching terminals and secure mounting; avoid pinching or bending sensing elements if present
• After installation, restore power and monitor temperatures for a full day to ensure normal cycling.

This genuine replacement power cord restores safe, reliable electrical connection for compatible ranges and ovens. It replaces a damaged or frayed cord so the appliance can receive mains power without safety hazards. What it does

• Delivers AC mains power to the appliance via the factory connector and terminal block
• Replaces cords with exposed wires, scorch marks, melting, or broken insulation
• Stops intermittent power loss caused by damaged or loose cord connections
• Prevents arcing and reduces fire risk from compromised power leads

• One replacement power cord

• Always disconnect household power at the breaker before servicing the appliance
• Verify the cord matches your appliance's terminal block and local electrical code; a licensed electrician may be required
• Inspect and reuse or replace the strain relief and terminal block screws as needed for a safe connection
• Do not attempt repairs if wiring or terminals are corroded—replace damaged components

This replacement transformer supplies the correct low-voltage power to the appliance's control and ignition circuits, restoring reliable operation of the control board and related systems. It's a direct-fit electrical component used in select Whirlpool appliances. What it does:

• Steps down household voltage to the low-voltage level used by the control board and ignition/system sensors
• Helps restore control panel function when the board is not receiving proper voltage
• Can allow the ignition/relief system to operate when a failed transformer caused no spark or no heat
• Prevents intermittent resets or erratic control behavior caused by voltage faults

• Disconnect power to the appliance before inspecting or replacing the transformer
• Handle electrical components carefully and avoid contact with terminals; use insulated tools
• Verify electrical compatibility and connector orientation with your appliance before installation

This replacement dryer tube channels heated air from the dryer cabinet to the lint filter/blower and exhaust path, restoring proper airflow and helping the cycle dry clothes efficiently. Use it when the original tube is cracked, crushed, or blocked. What it does

• Directs dryer airflow from the drum/blower chamber to the lint trap and exhaust.
• Helps maintain proper venting to prevent overheating and inefficient drying.
• Reduces air leaks that can cause longer dry times or hot spots.
• Minimizes lint buildup in the cabinet by providing a smooth, routed path for debris to the lint filter.

• One dryer tube

• Disconnect power (and gas supply if applicable) before servicing; ensure the dryer is completely powered off.
• Remove front or rear access panel as required to reach and replace the tube; keep fasteners for reassembly.
• Inspect adjacent seals and clamps; replace any damaged gaskets or worn clamps for a secure fit.
• Use gloves to avoid sharp sheet-metal edges and run a short test cycle to ensure proper airflow and quiet operation.

The Screw is an OEM part for Whirlpool microwaves. It is responsible for securing various parts of the microwave together. This screw ensures a tight and secure fit for parts and helps maintain the structural integrity of the microwave, preventing any loose or rattling parts.

A bad microwave screw can occur due to wear and tear, accidental damage, or misplacement during maintenance or repairs. If you notice symptoms such as loose or wobbly components, difficulty in opening or closing the microwave door, or abnormal noises while the microwave is in use, it may be time to replace this part.

Symptoms of a bad microwave screw include:

• Loose or wobbly components
• Difficulty in opening or closing the microwave door
• Abnormal noises during operation

Restore your Whirlpool microwave by replacing the faulty or missing microwave screw with this genuine OEM part.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.


This fan blade is the replacement blower blade that moves air through the appliance to help maintain proper cooling and circulation. Replacing a damaged blade restores airflow and helps the unit run more quietly and efficiently. What it does

• Spins on the fan motor to circulate air across coils and through the cabinet
• Worn, cracked, or missing blades can reduce airflow and cause warm spots
• A broken or unbalanced blade may make a loud noise or vibrate during operation
• Restoring a properly shaped blade helps the compressor and evaporator work as intended

• One replacement fan blade

• Disconnect power to the appliance before beginning any repair
• Remove access panels and mounting hardware as needed to reach the fan assembly
• Handle the blade carefully to avoid bending or cracking; ensure correct orientation on the motor shaft
