Parts for Frigidaire GF780KXD2: 02 - Backguard Parts

This part has been discontinued by the manufacturer and is no longer available.

This part has been discontinued by the manufacturer and is no longer available.

This pilot surface light is the small indicator lamp that shows when a surface burner or cooktop control is active, helping you see burner status at a glance. It replaces a worn or burned-out indicator lamp to restore visible status feedback. What it does:

• Provides visible indication that a surface burner/control is on or in standby
• Replaces a cracked, dim, or non-working pilot/indicator lamp
• Helps prevent accidental burner use by restoring clear visual feedback
• Designed to match the original fit and mounting on compatible cooktops

• Turn off power to the appliance at the breaker and verify the appliance is de-energized before starting.
• Handle the lamp assembly carefully to avoid damage; wear gloves if needed to keep oils off the lamp.
• Follow the appliance manufacturer's service instructions for accessing and securing the lamp assembly.

This terminal block secures and connects incoming power wires to the appliance's internal wiring, restoring a reliable electrical connection for safe operation. Fits applications that use a 3-terminal power connection. What it does:

• Provides a durable connection point for incoming line, neutral and ground conductors
• Replaces damaged, cracked or loose terminal points that can cause intermittent power or burning smell
• Secures wiring to the heating element or control harness to maintain consistent power delivery
• Helps prevent arcing or poor contact from worn terminals when installed correctly

• One terminal block

• Always disconnect power at the breaker or unplug the appliance before servicing
• Verify wiring colors and terminal positions before removal; take a photo for reference
• Use appropriate insulated tools; tighten terminal screws securely but avoid over-torquing
• If corrosion or damaged wiring is present, replace affected wires or connectors as needed

This snap bushing is a push-in panel grommet that protects and secures wiring where harnesses pass through metal or plastic panels. It prevents chafing and helps keep wire routing neat for safer operation. What it does:

• Cushions and shields wires from sharp panel edges to reduce abrasion and shorts
• Secures wiring harnesses in place to prevent unwanted movement or snagging
• Provides a finished, vibration-resistant pass-through for electrical leads
• Commonly replaced when the original bushing is cracked, broken, or missing

• One snap bushing

• Disconnect power before servicing electrical components
• Press-fit into the panel hole until the bushing snaps into place; confirm a secure fit
• Replace if brittle, torn, or deformed; do not use a damaged bushing
• Use pliers for removal if needed; avoid forcing or enlarging the hole

This part has been discontinued by the manufacturer and is no longer available.

This part has been discontinued by the manufacturer and is no longer available.
