Parts for Maytag 61004755: 01 - Fountain Bracket Kit (230V-50 / 60Hz) Parts

(SOLENOID NOT AVAILABLE MUST ORDER ICE DOOR KIT 12001991)

This knurled pin secures the juicer cone and helps transmit torque for proper juicing action. It replaces a worn or damaged roll pin to restore stable cone alignment and smooth operation. What it does:

• Secures the juicer cone or attachment to the drive shaft to prevent slipping
• Transfers rotational force from the motor to the juicer cone
• Helps stop wobble, misalignment, or intermittent engagement of the juicer cone
• Commonly replaced when the pin is bent, worn, or broken

• One knurled pin

• Turn off and unplug the appliance before servicing to avoid shock or injury
• Remove the juicer cone and any retaining parts per the service diagram before replacing the pin
• Use appropriate hand tools; avoid excessive force which can damage the shaft or housing

This ice door spring restores the closing tension on the dispenser chute door. Replacing a fatigued spring helps the flap seal properly after dispensing, reducing warm-air leaks that cause frost buildup and ice clumping around the chute. What it does:

• Provides return tension so the ice chute door closes after dispensing
• Helps maintain a tight seal to limit frost, condensation, and air leaks
• Can resolve a chute door that sticks open/closed or won't fully close
• Reduce rattling or poor ice flow caused by a loose flapper

• 1 spring

• Disconnect power to the refrigerator before servicing
• Remove dispenser trim/control panel to access the ice door assembly
• Note spring orientation on the flapper; transfer/install carefully without over-bending
• Smooth flap movement and a proper seal before reassembly

• Dispenser door spring
• Flapper spring
• Ice chute door spring

2 terminal interlock switch.

(SOLENOID NOT AVAILABLE MUST ORDER ICE DOOR KIT 12001991)

Size: 8-32 x 1/4 inch.

Size: 8-32 x .312 inch.

Compression nut for 5/16" plastic water line.

Size: 1/4 inch. Nut for plastic water line.
