Parts for Kitchenaid KFDC500JAV01: Burner Box Parts

This replacement manifold assembly routes water through the appliance to maintain proper operation and consistent performance. It restores correct fluid distribution for cleaning and rinsing so cycles run as expected. What it does:

• Directs water to internal spray ports and chambers for normal cycle operation
• Ensures even water flow to improve cleaning and rinsing performance
• Stops leaks or flow loss when a cracked or damaged manifold is replaced
• Resolves symptoms like uneven cleaning, water pooling, or error codes related to water distribution

• One manifold assembly as shown

• Disconnect power and shut off water supply before starting repair
• Inspect and replace any worn gaskets, seals, or mounting hardware as needed
• Tighten fittings to OEM torque; avoid overtightening plastic fittings
• Run a test cycle and check thoroughly for leaks after installation

This wire harness is the appliance's pre-assembled electrical connector assembly that routes power and signals between controls and components, restoring reliable electrical connections and component operation. What it does:

• Routes power and control signals between the control board, motors, sensors and other components
• Replaces damaged, frayed or corroded wiring that can cause intermittent operation or component failure
• Restores proper connector fit and secure electrical contact to prevent arcing or loss of function
• Helps resolve symptoms such as no power to a circuit, intermittent operation, or components that won't respond

• One wire harness assembly as shown

• Disconnect power (unplug or switch off breaker) before beginning any work
• Compare the replacement harness to the original to ensure connector types and lengths before installation
• Route and secure wires following original clips and fasteners; avoid pinching or sharp bends

This speaker module provides audible tones and chimes used by the appliance to signal cycle progress and user alerts. It restores clear sound feedback so you can hear cycle completion, alerts, and error tones. What it does:

• Produces the appliance's audible chimes, beeps, and alert tones
• Signals cycle completion and user prompts with clear sound
• Helps indicate error codes and status changes through audible alerts
• Interfaces with the main control to provide user feedback

• Disconnect power to the appliance before servicing to avoid electrical shock
• Handle the module and wiring harness carefully; avoid static discharge and bent pins
• Reconnect the wiring harness fully and secure the module in its mounting location
• Test the appliance after installation to ensure audible tones function correctly

This 1/2" female adapter is a threaded plumbing connector that lets a 1/2" male water line or fitting join the appliance inlet safely and securely. It provides a simple, durable connection to restore proper water flow. What it does:

• Adapts a 1/2" male threaded water supply to the appliance's inlet fitting
• Restores a secure, leak-free connection when the original fitting is damaged or missing
• Commonly used where a reliable, compact threaded coupling is needed
• Can help stop drips or leaks caused by worn or corroded connectors

• One 1/2" female adapter

• Turn off the water supply and unplug the appliance before installing
• Use plumber's tape on threads for a reliable seal unless the OEM instructions specify otherwise
• Hand-start threads to avoid cross-threading, then tighten with an appropriate wrench; avoid over-tightening
• Check connections for leaks after restoring water and operation

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

The range conversion kit is an OEM component specifically designed for Whirlpool ranges. This kit contains all the necessary parts to convert a range from natural gas to propane gas or vice versa.

Symptoms of an incompatible or incorrectly installed conversion kit include:

• Incomplete or unstable burning of the gas
• Yellow burner flame tips instead of blue
• Higher than normal gas usage
• Issues with ignition or flammability

Causes of a bad conversion kit could be improper installation, damaged or missing components, or using a kit not designed for the specific range model.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Screws for range anti tip bracket: WP3801F656-51. Includes 2 screws.
