Parts for Ge GFQ14ESSN1WW: Controls & Dispenser Parts

This ground screw secures an appliance's chassis grounding connection to ensure a reliable electrical ground and help reduce the risk of shock or electrical faults. Simple replacement when the original screw is missing, damaged, or corroded. What it does:

• Fastens the appliance ground wire or grounding strap to the metal chassis for a secure electrical ground.
• Restores a proper grounding point when the original screw is loose, stripped, corroded, or missing.
• Helps address symptoms related to poor grounding, such as intermittent power, electrical noise, or tripped breakers (as reported).
• Provides a direct, stable connection that supports safe appliance operation.

• One ground screw

• Disconnect power to the appliance before attempting any repairs to avoid electrical shock.
• Tighten to snug contact with the chassis; avoid overtightening which can strip threads or damage the metal.
• If ground wire or chassis threads are damaged, inspect for necessary additional parts or repair.

This dispenser housing valve and hose assembly replaces the dispenser water/valve module to restore proper water dispensing and prevent leaks. It's a complete drop-in assembly that simplifies repair and reduces troubleshooting time. What it does:

• Houses the dispenser valve that controls water flow to the dispenser
• Routes incoming water through attached hoses to the valve and dispenser outlet
• Stops leaks caused by cracked housing or failed valve connections
• Restores normal or steady water dispensing when the dispenser is not delivering water or flow is intermittent

• Turn off water supply and unplug the appliance before starting work
• Tighten hose connections securely but avoid overtightening plastic fittings
• After installation, turn on water and check all connections for leaks; run the dispenser to confirm proper flow

This hot water valve controls the flow of hot water into the appliance, restoring proper hot-fill performance and preventing unwanted leaks or drips. Use it to replace a worn, leaking, or non-operating inlet valve. What it does:

• Regulates hot water entering the appliance during fill cycles.
• Stops leaks and drips caused by failed or worn valve seals.
• Helps restore normal water temperature and cycle performance when hot water isn't flowing.
• Fits where the OEM hot water inlet valve is required for proper operation.

• Disconnect power to the appliance and shut off the water supply before starting any work.
• Relieve water pressure and have a towel or tray ready to catch residual water when removing hoses.
• Verify the replacement matches the original valve's inlet/outlet configuration and hose connections before final installation.
• After installation, restore power and water, then run a test cycle and check all connections for leaks.

This cold-water inlet valve controls the flow of cold water into your washing machine during fill. Replacing a sticking or leaking valve restores proper fill performance, temperature selection, and helps prevent unwanted water flow. What it does:

• Opens and closes to regulate cold-water flow during fill and rinse cycles
• Works with the control to deliver correct temperature and water level
• Common symptoms of a failing valve: no/slow cold fill, temperature errors, water trickling or not shutting off, or leaks from the valve body
• May trigger fill-related error codes when restricted or stuck

• 1 cold-water inlet valve

• Unplug the washer and turn off both water supply valves before starting
• Place a towel or pan to catch residual water; relieve hose pressure slowly
• Note hose and wire orientations; transfer any reusable mounting hardware from the original part
• After installation, restore water and power, then check all connections for leaks and run a test fill

This water inlet tube clamp secures the refrigerator/ice maker water inlet tube to the housing, helping prevent leaks and tube movement. Designed to keep the fill line stable for reliable water and ice delivery. What it does:

• Holds the water inlet tube in place to reduce stress and movement at the connection
• Helps prevent chafing or kinking that can lead to leaks or flow restriction
• Maintains proper alignment of the fill line during normal use and servicing
• Fits where the inlet tube passes through or attaches to the fridge housing

• Turn off power and water supply before servicing the appliance
• Accessible from inside the refrigerator or behind the toe grille depending on model; remove panels as needed
• Inspect tubing and fittings; replace clamp only if it matches OEM fit and function

This user interface board and bracket replace the oven/range control panel assembly for models that use a separate control board and mounting bracket. Restores responsive touch controls, display feedback, and selector operation when the original panel fails. What it does:

• Replaces the front control board that registers touchpad or button inputs and drives the display.
• Restores visible display and status indicators if the original panel is dim, blank, or intermittent.
• Resolves symptoms like unresponsive touchpads/buttons, incorrect oven settings, or missing display readouts.
• Interfaces with the main control so the range/oven accepts user commands through the front panel.

• One user interface board and one mounting bracket as shown

• Disconnect power at the breaker or unplug the appliance before starting; verify power is off.
• Handle the board by the edges and avoid static discharge; use an anti-static wrist strap if available.
• Follow console disassembly steps for your model—retain all screws and note wire connector locations for correct reassembly.
• Test the new board for correct function before reassembling the console completely.

A small replacement plug that fills a vacant drawer opening to restore a finished appearance and help block debris. Simple, low-profile part that snaps into the drawer frame for a clean, unobstructed look. What it does:

• Covers an open drawer slot or unused opening to restore the cabinet's appearance
• Helps keep crumbs, dust and small debris out of the drawer cavity
• Prevents loose items from falling into the opening and reduces drafts around the drawer area
• Replacement for a cracked, missing or worn drawer plug that causes visible gaps or rattling

• No special tools typically required; press the plug into place until it snaps or seats flush
• Work carefully to avoid damaging surrounding trim; do not force if fit is tight
• Inspect mating surfaces for broken clips or debris and clean before installing
