Parts for Ge JGAS02SEN1SS: 04 - Door & Drawer Parts

This oven rack is a replacement wire shelf that supports cookware and bakeware for standard ranges and ovens. It restores proper cooking clearance and helps maintain even heat circulation inside the oven. What it does:

• Provides a stable shelf for pots, pans and baking sheets during cooking or baking.
• Restores correct rack positioning when the original rack is missing, bent, or worn.
• Helps maintain proper airflow and even heat distribution by holding items off the oven floor.
• Fits into existing left/right rack supports and slides into place on oven rack guides.

• Remove power to the appliance before accessing the oven interior for safety.
• Install by sliding the rack into the oven's existing rack guides until fully seated.
• Handle with care; edges can be sharp and the rack will be hot after use.

This broiler pan grid is the oven rack insert that holds food above the broil pan to promote even browning and let drippings fall away. It restores broiling performance for ovens using a two-piece broil pan set. What it does:

• Supports meats and vegetables during broiling so heat circulates around food for better sear and browning
• Allows drippings to fall into the lower broil pan to reduce smoke and flare-ups
• Replaces a missing, warped, or damaged grid that can cause uneven cooking or food slipping through
• Fits into the matching broil pan to restore original broiling configuration

• Ensure oven is off and grid has cooled before handling or installing
• Place grid into the broil pan with grid edges seated securely in the pan
• Clean after use with warm, soapy water; avoid harsh abrasives that can damage the finish

This broil pan is the oven tray designed to catch drippings and hold food while broiling, making cleanup easier and helping food brown under high heat. Fits compatible GE ovens that use this factory broil pan. What it does:

• Holds food close to the broiler element for searing and browning.
• Collects grease and drippings to reduce smoke and make cleanup faster.
• Supports broiling racks or grids (when used with compatible inserts).
• Helps maintain consistent broil performance when the correct pan is in place.

• One broil pan (1 piece)

• Allow the oven to cool and disconnect power before handling or installing parts.
• Slide the pan onto the oven broil supports or into the broiler compartment until seated.
• Use oven mitts when removing after use; clean per manufacturer recommendations.

This oven door gasket assembly seals the door to the oven frame to keep heat in and prevent hot air leaks. Replacing a worn seal restores proper preheat times, temperature stability, and more consistent baking performance.

• Forms a heat-resistant seal between the oven door and front frame
• Helps reduce heat loss and maintain set oven temperatures
• Common fix for heat leaking around the door, long preheat times, and uneven baking/roasting
• Replace if the gasket is torn, frayed, flattened, brittle, or missing retainer ends

• Disconnect power at the breaker and allow the oven to cool completely
• Open the door and remove the old gasket from its retainers; note clip/hook locations and orientation
• Clean the sealing surface/channel before installing
• Install the new gasket without stretching; fully seat all retainers and verify the door closes evenly

This replacement screw secures appliance components and panels. Use it to replace a missing, stripped, or rusty fastener to restore a tight, rattle-free fit and keep assemblies properly aligned.

• Fastens brackets, trim, and panels securely to the appliance frame
• Replaces lost, worn, or corroded hardware
• Helps correct loose or wobbly parts and misalignment
• Reduces vibration or rattling caused by loose fasteners

• Disconnect power (and gas, if applicable) before servicing
• Match to the original and replace one-for-one to ensure correct length/thread
• Start by hand to avoid cross-threading; tighten snugly—do not overtighten
• If multiple screws secure a part, loosen/tighten evenly to maintain alignment

This extruded refrigerator door handle provides a durable, easy-grip replacement that restores a secure, finished pull on compatible GE refrigerators. Ideal when the existing handle is cracked, loose, or cosmetically worn. What it does:

• Replaces a damaged or broken refrigerator door handle to restore safe opening and closing
• Provides a full-length, extruded grip for comfortable handling
• Matches original mounting points for a direct-fit swap on compatible doors
• Improves appearance by replacing a scratched, faded, or cracked handle

• Typically installs with screws or clips at the door; refer to your model's service manual for exact fasteners
• Power/appliance disconnect not required for handle replacement, but remove contents and support the door to prevent slippage
• Handle surface may have protective film—remove before use

This handle base is the mounting support that secures an appliance door handle to the door, restoring proper fit and stable grip so the handle stops wobbling and operates reliably. What it does:

• Secures the door handle to the door frame so the handle stays tight and aligned
• Replaces worn, cracked, or broken mounting support that causes a loose or wobbly handle
• Helps restore safe, consistent opening and closing of the appliance door
• Matches OEM fit where the original handle base has failed

• One handle base

• Disconnect power (or unplug) and follow appliance safety procedures before starting
• Remove the door or access panel as required to reach handle mounting screws; retain original hardware unless replacement hardware is provided
• Use basic hand tools; avoid overtightening screws to prevent cracking the new base

The Bumper is an OEM part for GE ranges. It is located on the sides of the oven drawer and serves as a cushion to prevent noise, vibration, and wear. As time goes on, regular use of the appliance can cause it to become damaged or worn out.

Causes of a bad bumper can include wear and tear from regular use, deterioration of the material over time, or damage from excessive force when closing the door.

Symptoms of a bad Bumper include:

• Excessive noise
• Difficulty in sliding the drawer
• Misalignment
• Wear, and increased friction

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

A lower oven kick panel and cover assembly that restores the range's front appearance and protects internal components at the base. Replaces a cracked, bent, or missing lower trim to keep the cabinet area neat and safe. What it does:

• Covers and protects the oven's lower access area and wiring from debris and impact
• Restores finished look to the appliance front after damage or removal
• Helps reduce drafts from the appliance base and prevents access to moving parts
• Stops rattles or vibration caused by a loose or damaged lower trim

• Disconnect power (and gas if applicable) before starting any work
• Remove lower drawer or toe-kick fasteners to access mounting points; installation uses existing screws/clips
• Handle edges carefully and align tabs before tightening to avoid damage

This aluminum foil panel is a thin interior liner used inside the freezer/refrigerator compartment to protect internal components and provide a smooth reflective surface. It restores the cabinet interior and helps maintain proper airflow and defrost performance. What it does:

• Covers and protects the cabinet back/evaporator area from direct contact and debris
• Provides a smooth, reflective surface that assists with even cold distribution
• Helps prevent direct frost buildup on the cabinet back when installed correctly
• Common symptoms: torn, dented, or missing foil; visible corrosion or gaps behind the evaporator; increased frost or poor temperature stability

• One aluminum foil panel

• Install with the refrigerator unplugged and after removing stored food; follow OEM instructions for panel removal and reattachment
• Handle carefully to avoid sharp edges and bending the foil; wear gloves if needed
• Ensure proper alignment and secure all fasteners to restore original fit and seal
