Parts for Lg LMXC23746D: Freezer Parts

The Water Filter LT800P is an OEM part for LG refrigerators. This filter is designed to remove contaminants from the water supply, ensuring clean and fresh-tasting water and ice.

Causes of a bad water filter can include extended use beyond its recommended lifespan, exposure to high levels of contaminants, or damage to the filter itself.

Symptoms of a bad Water Filter LT800P include:

• Unpleasant taste or odor in the water or ice
• Reduced water flow from the dispenser
• Indicator light signaling the need for replacement
• Visible sediment or particles in the water

This OEM LG part is also compatible with Sears/Kenmore.

This replacement tray assembly restores the drawer's support and containment so stored items sit level and the drawer operates as intended. Designed to replace a cracked, warped, or damaged drawer tray. What it does:

• Provides a stable, molded surface for items stored inside the drawer
• Supports the drawer floor to help maintain proper alignment and seating
• Helps contain spills and direct moisture away from drawer slides
• Replaces trays with visible cracks, breaks, warping, or failed mounting tabs

• One tray assembly

• Remove contents and slide the drawer out before replacing the tray
• Inspect mounting tabs and rails for damage; replace any additional broken hardware as needed
• Use basic hand tools only; follow OEM instructions for proper seating and alignment
• Disconnect power only if required by your appliance model's service instructions

A small protective cap that covers and protects a component connection or opening from dirt and moisture, helping maintain proper function and prolong component life. Simple replacement when the original cap is cracked, missing, or worn. What it does:

• Covers exposed fittings, terminals, or openings to keep out debris and moisture
• Helps prevent leaks or contamination at the sealed connection
• Restores a secure fit when the original cap is cracked, split, or degraded
• Commonly used where a small, removable protective seal is required

• Inspect mating surface and surrounding gasket/seal before installing; replace other damaged parts as needed
• Press the cap firmly into place until fully seated; no special tools usually required
• Wear gloves and disconnect power or water supply if working near energized or pressurized components

This door stopper replaces the small hinge stop that limits door swing and helps the door close and latch properly. It restores correct door alignment and prevents the door from swinging past its intended range. What it does:

• Acts as a mechanical stop on the door hinge to control opening angle and reduce stress on the hinge
• Helps the door close smoothly and remain properly aligned
• Commonly replaces a cracked, worn, or missing stopper that allows over-rotation or uneven closing
• Can reduce noise and wear caused by a loose or shifting door

• Disconnect power to the appliance before servicing to avoid injury
• Replace like-for-like; removal may require removing the hinge trim or screws—keep fasteners organized
• Inspect adjacent hinge components and seals for wear while the door is removed

The Shelf Assembly is an OEM replacement part for LG refrigerators. It provides a movable shelf surface for organizing and storing items in the refrigerator or freezer compartment.

Symptoms of a bad shelf assembly include:

• Sagging or bowing of the shelf surface
• Difficulty in moving or removing the shelf
• Damage or cracks in the frame or wire grid
•  Inability to bear weight as intended

Causes of failure can be repeated overloading, accidental impacts, or normal wear and tear over time.

This authentic LG shelf assembly is also compatible with refrigerators by Kenmore models.

This rail guide assembly helps support and guide a sliding rack/drawer so it opens and closes smoothly and stays aligned. It replaces worn or broken guides to restore consistent rack movement and prevent binding or dropping. What it does:

• Guides the rack/drawer along its track for smooth operation
• Keeps the rack aligned to prevent tipping or falling out
• Replaces cracked, worn, or missing plastic guide components
• Helps eliminate sticking, grinding, or uneven sliding during use

• Disconnect power (and water if applicable) before beginning any repair
• Remove the rack/drawer and inspect mounting points before installing the new guide
• Use basic hand tools; avoid forcing parts to prevent damage
• Test the rack for smooth travel after installation

This rail guide assembly keeps a sliding component aligned and moving smoothly, restoring stable, low-friction travel for drawers or rails. It helps reduce noise, prevent binding, and maintain proper operation of the slide mechanism. What it does:

• Guides and supports the sliding rail to ensure straight, reliable travel
• Helps prevent sticking, misalignment, and uneven wear on the slide
• Reduces noise and vibration during operation
• Restores proper engagement of the rail with mating parts

• One guide assembly

• Disconnect power or unplug the appliance before starting any repair
• Use basic hand tools; follow OEM service manual or instructions for correct removal and alignment
• Inspect mating rails and fasteners for wear or damage and replace if needed
• Wear safety gloves and eye protection; test operation after installation

This rail connector secures a slide rail to its mounting point, keeping the rail aligned and stable so the assembly moves smoothly. Replace a cracked, worn, or missing connector to restore proper tracking and support.

• Joins the slide rail to its bracket or panel to maintain alignment and support
• Helps the rail travel smoothly without binding or coming off track
• Replaces broken, warped, or missing connectors that allow rails to loosen
• Typical signs of failure: rail separates, wobbles, sags, or won't stay engaged

• Disconnect power to the appliance; remove items to access the rail safely
• Remove the drawer/shelf and rail as needed to reach the connector
• Release locking tabs or fasteners, transfer the rail to the new connector, and seat it fully
• Reinstall components and test for smooth travel; wear gloves to protect hands from sharp edges

This connector joins two sections of the refrigerator's water tubing to create a secure, leak-resistant seal. Replace a cracked or loose connector to restore proper water flow to the dispenser and ice maker.

• Provides a sealed union between two water tubes in the appliance's water system
• Helps prevent air and water leaks that can impact dispenser and ice maker performance
• Typical failure signs include drips or puddles near the connection, visible seepage, or moisture alerts
• Also causes low/no dispenser flow or small or hollow ice cubes

• Disconnect power and shut off the water supply; dispense water to relieve line pressure
• Prepare tubing with a clean, square cut; insert each tube fully into the connector until seated, then pull-test to retention
• Restore water and check all joints for leaks; purge air by dispensing water before normal use

This slide rail supports and guides a refrigerator drawer so it opens and closes smoothly. Replacing a worn or cracked rail restores proper alignment and glide to prevent bins from binding, tilting, or popping out of the track.

• Provides the track the drawer/bin slides on
• Maintains drawer alignment and supports the bin during use
• Helps ensure smooth, even travel in and out
• Common failure signs: drawer hard to open/close, crooked or sagging bin, drawer comes off track, visible cracks or damage to the rail

• Disconnect power and remove the affected drawer/bin before starting.
• Remove screws securing the old rail; install the new rail in the same position and orientation.
• Transfer any reusable stops/caps from the original rail if applicable.
• Reinstall the drawer and verify smooth operation before reloading.

This slide rail supports and guides a refrigerator drawer so it opens and closes smoothly. Replacing a worn or cracked rail restores proper alignment and glide to prevent bins from binding, tilting, or popping out of the track.

• Provides the track the drawer/bin slides on
• Maintains drawer alignment and supports the bin during use
• Helps ensure smooth, even travel in and out
• Common failure signs: drawer hard to open/close, crooked or sagging bin, drawer comes off track, visible cracks or damage to the rail

• Disconnect power and remove the affected drawer/bin before starting.
• Remove screws securing the old rail; install the new rail in the same position and orientation.
• Transfer any reusable stops/caps from the original rail if applicable.
• Reinstall the drawer and verify smooth operation before reloading.

This replacement drawer guide helps the freezer/refrigerator drawer slide smoothly and stay aligned for reliable opening and closing. It restores stable support and reduces sticking or noisy movement. What it does:

• Guides the drawer along its track so it opens and closes smoothly
• Supports the drawer weight to prevent sagging or misalignment
• Helps eliminate binding, catching, or uneven movement
• Reduces scraping or rattling noises caused by a worn guide

• Disconnect power to the appliance or unplug before beginning any work
• Remove the drawer and any contents to access the guide mounting points
• Align the guide with the existing track and secure using the original screws or fasteners
• If mounting hardware is damaged or missing, replace with OEM-specified fasteners; do not force parts into place
