Parts for Jenn-Air JS48PPDUDB20: Freezer Shelf Parts

The Whirlpool Everydrop Water Filter 3 is a genuine OEM replacement part designed to improve the quality and taste of water while filtering out impurities. This filter is specifically designed for side-by-side refrigerators that accept Filter 3. Contains the ability to reduce 66 contaminants including lead, mercury, asbestos, and industrial chemicals. It helps to provide clean, fresh-tasting water. The filter needs to be changed every 6 months or 200 gallons for optimal performance. The fast and easy filter change requires no special tools. Simply push until you hear the receiver click into place. This NSF-certified filter is a reliable and affordable way to ensure that your family is drinking clean, refreshing water. SOLD INDIVIDUALLY

Specs:

• Filter Media: Carbon Block
• Operating Pressure: 30-120 psi
• Operating Temperature: 33-100 °F
• Flow rate: 0.5 gpm
• Material: Plastic
• Color: White
• Approximate Dimensions: 12 inches long, 2 inches in diameter

This basket front replaces the plastic panel on the front of a freezer wire basket. It restores a solid barrier so food stays contained and helps the basket slide in and out smoothly.

• Attaches to the front of the freezer wire basket to create a secure face
• Helps prevent items from falling out of the basket
• Replaces cracked, warped, or missing fronts
• Can improve basket handling and alignment when opening/closing

• Unplug the refrigerator before servicing
• Remove the basket from the freezer and place on a flat surface
• Release the damaged front and align the new front with the basket wires; press until fully seated
• Reinstall the basket and verify smooth operation

Left hand side

This machine screw secures components in place to maintain proper alignment and stability during appliance operation. Replacing a worn or missing screw restores a tight fit and helps prevent vibration, noise, or loosening parts.

• Provides a secure mechanical fasten for panels, brackets, or internal assemblies
• Helps correct rattling, vibration, or loose-fitting parts
• Useful when an original screw is stripped, corroded, or lost
• Sized to match 8-18 thread applications in compatible units

• Disconnect power and shut off water or gas before servicing
• Note original screw location and orientation for correct reassembly
• Start threads by hand to avoid cross-threading; do not overtighten
• Replace any damaged clips or mounts the screw engages

Replaces the ice maker door/cover to protect the ice compartment and keep ice contained. Restores a secure door fit to reduce ice spillage and help the ice maker operate without loose or fallen ice. What it does:

• Covers and seals the ice maker area to keep ice contained and reduce mess.
• Replaces cracked, broken, warped, or missing doors that allow ice to spill.
• Helps restore proper door fit so ice dispenses more reliably and is less likely to jam.
• Mounts in place of the original door to return the ice compartment to its intended condition.

• Disconnect power to the appliance before beginning any repairs.
• Remove the ice bin and clear surrounding area to access the door safely.
• Handle edges carefully and follow the appliance's service instructions; basic hand tools may be required.

This bracket secures the ice maker's front cover in place. It supports and positions the cover so it stays attached to the ice maker head, protecting internal components and maintaining a clean, finished appearance inside the freezer. What it does:

• Holds the ice maker cover securely against the ice maker assembly
• Maintains proper alignment and a finished look
• Helps reduce vibration and rattling from a loose cover
• Common signs of failure: cracked/missing bracket, cover won't stay on, visible sagging or gaps

• One ice maker cover bracket

• Disconnect power to the refrigerator and turn off the water supply before servicing
• Remove the ice bin and the ice maker cover; retain any screws/fasteners
• Replace the bracket and reuse existing hardware; avoid overtightening into plastic
• Ensure the cover seats fully and moves/operates without interference
