Parts for Ge ZISW480DXA: 07 - Fresh Food Section Parts

This HMI assembly is the user interface/control panel that operates the dispenser and display functions on compatible refrigerators. Replaces a worn or non-working control/display assembly to restore input and visual feedback. What it does:

• Provides the front-facing display and touch/press controls for dispenser and temperature settings
• Sends user commands to the refrigerator's main control board for functions like dispensing and settings changes
• Commonly replaces assemblies when the display is blank, unresponsive buttons, or incorrect/disappearing indicators
• Restores normal control and feedback when original panel is cracked, worn, or electrically failed

• One HMI assembly (control panel/display)

• Disconnect power before starting to avoid shock or damage
• Handle ribbon cables and connectors gently; ensure connectors are fully seated during reassembly

The Air Damper Foam Assembly is an OEM part specifically designed for GE refrigerators. It attaches inside the refrigerator door and plays a vital insulating role.

The foam assembly features a retractable damper gasket surrounded by mounting foam. When the door closes, this forms a critical barrier that reduces air exchange between the refrigerator's interior and exterior environments. Proper insulation helps maintain consistent temperatures and minimize condensation.

Symptoms of a failing assembly include:

• Inability to retain optimal interior temperature levels
• Visible gaps or tears in the damper sealing foam
• Foam detachment from supporting door panels

This occurs from normal compression during regular door use. Replacing with a new OEM GE foam assembly restores dependable insulation and seals out temperature variances. Compatible with brands such as Hotpoint, RCA, or Kenmore side-by-side models as well.


The air damper monogram kit is used in refrigerators that include freezers. The main purpose of this component is to balance the way air flows when it leaves the evaporator fan housing. The device will often control how much cold air is moved into the fresh air compartment. It can also be used to move cold air from the refrigerator into the freezer. If this part is damaged, cold air may not go where it should and some parts of the refrigerator may become too warm.If this part is damaged or not working, it should be replaced. Disconnect the refrigerator from power and open the door to find the air damper monogram. It is located where the cold air enters the fresh food area. Access the housing and inspect it for damage. It can be removed to get to the damper components. Check the sensing bulb for issues before removal. Install all parts of the kit or only the ones that are damaged before reassembling the appliance.This is a genuine OEM air damper monogram kit for use with General Electric refrigerators. It is priced individually and sourced straight from the manufacturer.

The Temperature Sensor is an OEM replacement part for GE refrigerators, designed to accurately monitor and relay the temperature inside the refrigerator and freezer compartments to the electronic control board. By detecting the slightest changes in internal temperature, the sensor allows the control board to make real-time adjustments to the cooling system, activating the compressor and fans as needed to maintain optimal conditions for food preservation.

Over time, the temperature sensor can fail due to electrical issues, exposure to moisture, or general wear and tear. A malfunctioning sensor can lead to improper temperature regulation, affecting the efficiency of the refrigerator and the freshness of stored food.

Symptoms of a bad Temperature Sensor include:

• The refrigerator or freezer not maintaining the set temperature
• The appliance running continuously or more frequently than normal
• Inaccurate temperature readings displayed

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This Top LED board is the interior illumination module that provides the fridge's top-area lighting, restoring clear, even light for food visibility and convenience. What it does:

• Replaces a failed or dim top-area LED lighting assembly
• Restores even, bright interior illumination when lights flicker, are dim, or won't turn on
• Connects to the refrigerator's existing wiring harness and mounts under the top interior panel
• Works with the refrigerator's door/light switch to turn lights on and off as designed

• Disconnect power to the appliance before starting any repair
• Remove interior top trim/panel to access the board; handle the PCB and LEDs by the edges
• Unplug the wiring connector before removing the fasteners; install the new board in reverse order

This halogen light bulb installs in the refrigerator's vertical light column to restore bright, even interior illumination. Replace a failed bulb to keep shelves and drawers clearly visible whenever you open the door. What it does:

• Provides interior lighting as part of the column assembly when the door opens
• Common symptoms: interior light is out, flickers, or appears noticeably dim
• Bulb may show darkening or a broken filament
• Replacing the bulb restores normal brightness inside the compartment

• 1 halogen light bulb

• Unplug the refrigerator or switch off power at the breaker before service
• Allow the old bulb and surrounding area to cool completely
• Handle halogen bulbs with clean gloves or tissue; avoid touching the glass
• Align with the socket like the original and do not force; reinstall any cover or lens

The Temperature Sensor Grille is an OEM part for GE refrigerators. This grille covers and protects the temperature sensor, ensuring it accurately measures the internal temperature of the refrigerator.

Causes of a bad grille can include physical damage from impacts, regular wear and tear, or the buildup of dust and debris that can obstruct airflow.

Symptoms of a bad temperature sensor grille include:

• Inaccurate temperature readings
• The refrigerator running continuously or not cooling properly
• Visible damage or obstruction on the grille
• The sensor becoming loose or dislodged

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.
