Parts for GC912: Hob Top Parts

This is a stainless-steel M3 x 7 mm countersunk Phillips screw packaged as a set of 10 — a common fastener for securing trim, brackets, and small components in appliances. It provides a flush finish when installed. What it does:

• Secures panels, brackets, and small component assemblies using a countersunk head for a flush fit
• Phillips drive allows standard screwdriver or bit installation
• Stainless finish resists corrosion in typical household appliance environments
• Used where an M3 x 7 mm machine screw is specified

• One packet containing 10 screws (M3 x 7 mm, countersunk Phillips, stainless)

• Use the correctly sized Phillips bit to avoid cam-out and striping
• Tighten until snug; avoid over-torquing which can strip threads or damage components
• If replacing a screw, confirm thread size and head style match the original
• Follow all appliance safety guidance: disconnect power and water before servicing

Cold control that regulates cooling cycles to maintain set temperatures in the fresh-food section. Replacing a failed control restores more consistent temperature control and helps prevent food spoilage. What it does:

• Controls compressor/cooling cycles based on the selected temperature setting to maintain cabinet temperature.
• Common symptoms: refrigerator running constantly, not cooling, or temperature cycling irregularly.
• Interfaces with the fridge control housing and wiring to open/close the cooling circuit as needed.

• Disconnect power to the appliance before starting any repair.
• Access the control housing/panel to remove the old control; note wire locations or take a photo for correct reinstallation.
• Handle any attached sensor or capillary tube gently to avoid kinks or damage.
• After installation, restore power and the refrigerator reaches and holds the desired temperature.

This cast burner spreader fits the wok burner assembly and helps direct gas flames for even heat under wok-style cookware. Replaces a damaged or warped spreader to restore stable, concentrated heating for high-heat cooking. What it does:

• Directs and shapes burner flames for wok cooking and high-heat searing
• Helps maintain an even flame pattern across the wok bottom
• Replaces cracked, warped, or corroded spreaders that cause uneven heating
• Contributes to safer, more predictable burner performance

• Turn off gas supply and power to the appliance before servicing
• Allow all components to cool completely before handling
• Remove grates and burner caps to access and replace the spreader; reassemble in reverse order

This replacement auxiliary low burner ring supports the small/low-output gas burner and helps restore correct flame shape and heat distribution for simmering tasks. Designed to fit the matching burner cap and base. What it does:

• Positions and supports the auxiliary (low) burner cap for stable, even flames
• Restores proper flame pattern for low-heat cooking and simmering
• Helps prevent uneven heating or partial flame lift caused by a damaged ring
• Works with the burner assembly to maintain safe combustion when parts are intact

• Turn off gas supply and power to the appliance before servicing
• Remove burner cap and existing ring; seat the new ring so it sits flat and centered on the burner base
• Do not force or bend the ring; replace if warped or damaged
• If you smell gas or the burner fails to light properly after installation, stop.

This is a replacement rapid burner cap in a black matte finish for gas cooktops. It restores proper flame distribution and the cooktop's appearance after a damaged or missing cap. What it does:

• Covers the rapid (high-output) burner to direct gas flames for even heating
• Helps maintain correct burner flame pattern and cooking performance
• Replaces chipped, cracked, or worn caps that can affect ignition or heat spread
• Restores the cooktop's finished look and protects the burner head

• Turn off the appliance and gas supply and ensure all parts are cool before servicing
• Remove the old cap and set the new cap in place; no tools typically required
• Align the cap over the burner head so it sits flat and centered before use
