Parts for Kenmore 795.51319013 (79551319013, 795 51319013): Ice And Water Parts

This guide is the replacement drawer slide guide that supports and aligns a refrigerator drawer for smooth, stable opening and closing. Restore proper drawer travel and help prevent binding, sagging, or uneven movement. What it does:

• Supports the drawer on its track and keeps it aligned.
• Guides the drawer during opening and closing for smooth travel.
• Prevents the drawer from binding, sagging, or coming off the track.
• Reduces noise and wobble caused by worn or broken guides.

• Always unplug the appliance or turn off power at the breaker before starting repairs.
• Remove the drawer to access the guide.
• Inspect the mating track and adjacent guides; replace any damaged parts to ensure proper fit.
• Tighten fasteners securely but avoid over-tightening to prevent damage.

The Ice Bucket Assembly stores the ice produced by your refrigerator and feeds it to the dispenser. Replace a cracked or worn bucket to restore reliable ice storage and smooth, consistent dispensing.

• Holds and organizes ice in the freezer/ice compartment for dispensing
• Interfaces with the dispenser drive to move ice toward the chute
• Guides cubes during dispense to help minimize jams
• Damage may cause no or slow ice dispensing, loud grinding during dispense, or a cracked/broken bin or tabs

• Disconnect power to the refrigerator before servicing
• Open the ice compartment/freezer door and pull the existing bucket straight out; empty any remaining ice
• Align the drive connection and slide the new bucket fully into place until it seats
• Discard old ice, allow fresh ice to form, and test dispensing (cube/crush if available)

This harness joint is a wiring connector that links two sections of an appliance wiring harness, restoring electrical continuity and reliable signal/power transfer. Use it to replace a damaged, loose, or corroded harness connection. What it does:

• Joins wiring harnesses so power and control signals pass between components
• Restores intermittent or lost electrical connections caused by broken or corroded terminals
• Helps eliminate symptoms like no power to a module, intermittent operation, or communication failures
• Maintains proper routing and strain relief where harness sections meet

• Disconnect power (unplug or shut off breaker) before inspecting or replacing wiring
• Match connector shape and terminal arrangement before installation; secure firmly until it clicks or seats
• Avoid forcing pins; inspect adjacent wires and insulation for damage and replace if needed

The Ice Maker Assembly Kit is an OEM part for LG refrigerators. This kit includes the components necessary to produce and store ice, ensuring a steady supply of ice for your household needs.

Common causes of a bad ice maker include wear and tear from regular use, clogging or blockage in the water supply line, or failure of the mechanical or electronic components that control the ice-making process.

Symptoms of a bad Ice Maker Assembly Kit include:

• No ice production
• Smaller than usual ice cubes
• Leaks around the ice maker
• Unusual noises during the ice-making cycle

This OEM LG part is also compatible with Sears/Kenmore.

This drive motor powers the appliance's rotating drum or tub, restoring proper rotation so loads tumble or agitate as intended. Replaces a worn or failed motor to stop humming, no-rotation, or intermittent spinning problems. What it does

• Spins the drum/tub so laundry or items tumble and clean/dry evenly.
• Accepts the drive belt (where applicable) and transmits torque to rotate the load.
• Stops operation when internal thermal or electrical faults occur, which can cause humming or no-spin symptoms.
• Commonly replaced when the unit fails to start, stalls under load, or makes unusual noises.

• One drive motor (single motor assembly)

• Disconnect power before beginning any repair to avoid shock or injury.
• Access typically requires removing the cabinet or rear panel and supporting the drum/tub while unbolting the motor.
• Note belt routing and electrical connector positions during removal to ensure correct reassembly.

This guide rail is the replacement drawer slide that helps appliance drawers open and close smoothly, restoring proper alignment and reliable movement. Replaces worn or damaged rails to reduce sticking, wobbling, or uneven travel. What it does

• Guides the drawer along its track for smooth, controlled sliding motion
• Restores correct drawer alignment to prevent binding or uneven gaps
• Reduces noise and vibration caused by worn or bent rails
• Helps stabilize drawer loads for consistent opening and closing

• One guide rail

• Recommend matching left/right placement and rail orientation before fastening
• Use basic hand tools; avoid overtightening fasteners to prevent binding
• Inspect mating slides, rollers, and mounting points and replace if worn
• Disconnect power and follow appliance-specific service manual instructions for safe access

This guide rail supports and stabilizes the dryer drum, helping it rotate smoothly and reducing wobble or noise. Replaces a worn or broken rail to restore quieter, more reliable drum movement and proper drum alignment. What it does:

• Provides a smooth, low-friction surface for the drum to ride on during operation
• Prevents drum wobble and rubbing that can cause noise, uneven wear, or belt strain
• Helps maintain proper drum alignment for effective tumbling and airflow
• Useful when the original rail is cracked, worn, or missing mounting surfaces

• One guide rail

• Turn power and gas off before beginning service; disconnect the appliance
• Basic disassembly of the dryer front or cabinet may be required; follow OEM instructions
• Inspect adjacent rollers, glides, and mounting brackets for wear and replace as needed
• Use proper tools and reference the dryer's service manual

Changes between cubed or crushed ice.

The Water Tank is an OEM part for LG refrigerators. This tank stores and supplies water to the refrigerator's ice maker and water dispenser, ensuring a consistent supply of fresh, filtered water. It is designed to fit securely within the refrigerator, maintaining hygiene and preventing leaks.

Over time, the water tank can become worn out, cracked, or contaminated. Common causes of a bad water tank include regular wear and tear, exposure to extreme temperatures, or damage from mishandling or improper installation.

Symptoms of a bad water tank include:

• Leaking water inside the refrigerator
• Low water flow to the dispenser or ice maker
• Unusual tastes or odors in the water
• Visible cracks or damage to the tank

This OEM LG part is also compatible with Sears/Kenmore.

The Connector (Mech), Tube is an OEM part for LG refrigerators. It is used to securely connect water tubing within the refrigerator, ensuring a reliable flow of water to components such as the ice maker and water dispenser.

Causes of a bad connector can include wear and tear over time, physical damage from improper installation or handling, or degradation due to exposure to varying temperatures and water pressure.

Symptoms of a bad connector include:

• Leaks or drips around the connector area
• Reduced water flow to the ice maker or water dispenser
• Water pooling inside or around the refrigerator
• The ice maker or water dispenser not functioning properly

This OEM LG part is also compatible with Sears/Kenmore models.

This cover tube is a molded protective housing that shields internal components and wiring from wear, heat, and debris. It helps maintain safe operation and prevents rubbing or chafing that can lead to damage. What it does:

• Covers and protects internal wiring, hoses or assemblies from contact and abrasion
• Helps direct airflow and keeps debris away from sensitive parts
• Reduces noise caused by rubbing or loose components
• Preserves component alignment and prevents premature wear

• Disconnect power to the appliance before beginning any repair.
• Installation requires partial disassembly of the appliance; keep track of screws and clips.
• Use OEM replacement and follow the service manual for correct orientation and torque of fasteners.
• If you see damaged wiring or other compromised parts, replace or repair those items before reinstalling the cover tube.

This pipe holder is a small plastic clip that secures tubing and small pipes inside the appliance, helping keep lines organized and preventing rubbing or disconnection. It restores proper routing and reduces vibration-related noises. What it does:

• Holds and secures water, drain, or refrigerant tubing to prevent sagging and chafing
• Keeps lines routed away from moving parts to reduce wear and noise
• Helps maintain proper tube alignment to avoid strain on fittings
• Commonly replaced when the original clip is cracked, broken, or missing

• Disconnect power and water before working on the appliance
• Inspect surrounding tubing and fittings for damage when replacing the clip
• Typically installs as a push-fit or snap-on clip; use gentle pressure and avoid forcing
• Replace broken or brittle clips to prevent tubing damage or leaks

This holder is a small mounting bracket that secures a mating component in place inside the appliance. Replacing a cracked or missing holder restores a firm, rattle-free fit and proper alignment.

• Provides a stable mount for the designated part
• Prevents shifting and vibration that can cause noise or premature wear
• Common signs of failure: broken tabs, stress cracks, or the attached part sagging or falling out
• When damaged, the connected component may be loose, noisy, or misaligned

• Disconnect power; if working near water tubing, also shut off the water supply
• Note the original orientation and mounting points; take a photo before removal
• Reuse existing fasteners and avoid overtightening to prevent cracking the plastic
• Ensure the attached component is secure and clears any moving parts before restoring power
