Parts for Kitchenaid KBSD602ESS01: 09 - Refrigerator Door Parts

The Whirlpool Everydrop Water Filter 3 is a genuine OEM replacement part designed to improve the quality and taste of water while filtering out impurities. This filter is specifically designed for side-by-side refrigerators that accept Filter 3. Contains the ability to reduce 66 contaminants including lead, mercury, asbestos, and industrial chemicals. It helps to provide clean, fresh-tasting water. The filter needs to be changed every 6 months or 200 gallons for optimal performance. The fast and easy filter change requires no special tools. Simply push until you hear the receiver click into place. This NSF-certified filter is a reliable and affordable way to ensure that your family is drinking clean, refreshing water. SOLD INDIVIDUALLY

Specs:

• Filter Media: Carbon Block
• Operating Pressure: 30-120 psi
• Operating Temperature: 33-100 °F
• Flow rate: 0.5 gpm
• Material: Plastic
• Color: White
• Approximate Dimensions: 12 inches long, 2 inches in diameter

This door bearing fits the washer door assembly to restore smooth opening and closing and reduce noise, wobble, or binding. Replacing a worn bearing helps maintain proper door alignment for reliable operation. What it does:

• Supports the door hinge so the door pivots smoothly without sagging or sticking
• Reduces squeaks, grinding, or rough movement when opening or closing the door
• Helps keep the door aligned to reduce stress on the latch and door seal
• Addresses symptoms like door wobble, uneven closing, or noisy operation

• Disconnect power (and water if accessing near waterlines) before starting any repair
• Removing the door panel or inner door trim may be required; retain all fasteners and document their locations
• Inspect surrounding parts (hinge, seal, latch) and replace if damaged; improper alignment can cause premature wear

This door hinge restores smooth, aligned door operation. Replacing a worn hinge ensures the door opens and closes properly, supports the door's weight, and helps the gasket seal evenly to reduce air or heat loss.

• Provides the pivot point that lets the door open and close smoothly
• Maintains door alignment so the seal sits flush against the cabinet
• Helps prevent sagging, rubbing, or binding at the door edge
• Common symptoms: door drops or won't close flush, squeaks/pops, visible play or hinge damage

• Disconnect power; turn off water supply if applicable
• Support the door before removing hinge fasteners to prevent strain or damage
• Transfer any spacers/bushings from the old hinge to the new hinge if present
• Reinstall and verify door alignment and seal contact; adjust as needed

This door hinge restores smooth, aligned door operation. Replacing a worn hinge ensures the door opens and closes properly, supports the door's weight, and helps the gasket seal evenly to reduce air or heat loss.

• Provides the pivot point that lets the door open and close smoothly
• Maintains door alignment so the seal sits flush against the cabinet
• Helps prevent sagging, rubbing, or binding at the door edge
• Common symptoms: door drops or won't close flush, squeaks/pops, visible play or hinge damage

• Disconnect power; turn off water supply if applicable
• Support the door before removing hinge fasteners to prevent strain or damage
• Transfer any spacers/bushings from the old hinge to the new hinge if present
• Reinstall and verify door alignment and seal contact; adjust as needed

The Screw is an OEM part for Whirlpool refrigerators. This screw plays a small but important structural role, securely fastening the refrigerator door hinges in place.

Causes of a bad screw include normal wear and tear, repeated door opening/closing stress, or accidental damage during cleaning or servicing of the hinge area.

Symptoms of a bad hinge screw include:

• Loose or sagging door that does not close or seal properly
• Increased vibration or noise from the hinge area
• Difficulty opening/closing the door smoothly

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This is a direct replacement kit sold as a single pack to restore the original function of the listed Whirlpool assembly. It provides a like-for-like part so your appliance can operate as intended. What it does

• Replaces the failed factory component referenced by Use 2256389 / 2302878
• Restores the specific mechanical/electrical function of the original assembly
• Helps address common symptoms such as failure of the related cycle, intermittent operation, or no response from the affected subsystem
• Provides a one-for-one swap when the original part is damaged or worn

• One replacement kit

• Disconnect power and water before beginning any service
• Follow the original equipment manufacturer's instructions and use proper tools
• Handle electrical connectors and small parts carefully to avoid damage

The Storage Bin is an OEM part for Whirlpool refrigerators. It provides organized, adjustable storage space in the refrigerator door. The bin has been designed to hold condiments, beverages, snacks, and other small refrigerator items.

Causes of a bad storage bin can include broken hinges or mounting clips, cracks or holes in the plastic material, or a bent or warped bin that no longer sits securely or organizes items well.

Symptoms of a bad storage bin include:

• Items falling out of the bin
• Bin not sitting flush or securely in the door
• Difficulty removing or replacing the bin
• Cracked or damaged plastic that affects functionality

This OEM replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore refrigerator models.

This is a fastener screw used to secure appliance panels and components where a 10-24 thread is required. It provides a reliable hold for reattaching parts during repairs and maintenance. What it does:

• Fastens panels, brackets, or components with a 10-24 threaded hole
• Restores original attachment points that have missing or damaged screws
• Helps reduce vibration and rattling when properly tightened
• Works with metal or reinforced plastic mating components designed for 10-24 hardware

• One screw (quantity: 1)

• Use the matching 10-24 driver/socket and turn until snug; avoid over-tightening
• Verify mating threads and alignment before driving to prevent cross-threading
• Disconnect power and follow appliance safety procedures before servicing
• Check for proper washer or spacer if originally present

The Screw is an OEM part compatible with Whirlpool dryers. This screw connects the back panel to the side panel, ensuring the dryer cabinet is securely assembled. It plays an integral role in maintaining the structural integrity of the dryer housing.

Symptoms of a bad screw can include loosening, corrosion, or breakage over time and use. This can compromise the bond between panels and weaken the overall dryer frame.

Causes of a bad screw include:

• Repeated expansion and contraction from heat cycles
• Vibrations loosening the connection point
• Stress or cracks developing at the screw head or threads

These issues can lead to:

• Gaps appearing between panels
• Components like controls detaching from the housing
• Cabinet unable to withstand pressure changes

This OEM Whirlpool replacement screw is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The GAP-HINGE is an OEM component for Whirlpool brand refrigerators. It is designed to fill the space between the refrigerator door and cabinetry, creating a flush fit. The hinge allows the door to open and close smoothly while preventing air and moisture leaks around the door frame.

Symptoms of a bad gap hinge include:

• Gaps around the refrigerator door letting hot or humid air enter the refrigerator interior
• Increased energy costs from lack of insulation due to air gaps
• Buildup of moisture on internal surfaces from improper sealing
• Difficulty opening or closing the refrigerator door smoothly

Causes can include normal wear over time, or damage from repeated opening and closing of the door putting stress on the hinge.

This OEM Whirlpool replacement part is compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore brands.

This bin control lever secures and releases the refrigerator door shelf/bin so it stays in place during normal use and allows easy removal when needed. It restores proper bin latching for safe storage. What it does:

• Replaces a worn or broken lever that locks the door shelf/bin in position.
• Helps prevent the bin from slipping or falling when opening or closing the door.
• Restores smooth release action so the bin can be removed for cleaning or reconfiguration.
• Useful when the shelf/bin won't lock, is loose, or detaches unexpectedly.

• Disconnect power to the appliance or open door and work carefully to avoid contact with electrical components where applicable.
• Remove the door bin/shelf per your model's service instructions before replacing the lever.
• Inspect mating pins and mounting posts and replace if damaged; do not force parts into position.

This bin control lever secures the refrigerator door shelf/bin to the door, restoring a stable hold and preventing the bin from sliding or falling. Ideal for replacing a cracked, loose, or broken lever to regain full door storage function. What it does:

• Locks or supports the door shelf/bin so it stays seated during normal use
• Stops the bin from tipping or sliding out when the door is opened or closed
• Common symptoms: cracked or loose lever, bin won't stay in place, rattling or shifting of door bin
• Matches OEM mounting points to restore original fit and operation

• Remove all items from the door shelf/bin before beginning; support the bin while you work
• Typically installs by aligning with the mounting posts and snapping into place; minimal tools required
• If mounting posts or the bin are damaged, those components may need replacement for a secure fit
