Parts for Whirlpool WRB329DFBB02: Refrigerator Liner Parts

This control panel overlay replaces the printed cover that surrounds the appliance's buttons and display, restoring clear labels and a finished appearance. It protects controls from spills and wear while keeping the console readable. What it does:

• Restores faded, worn, or damaged button labels and graphics
• Protects the underlying control surface from spills, grease, and abrasion
• Improves console appearance by covering scratches, peeling, or discoloration
• Helps ensure button legends remain visible for accurate operation

• Disconnect power to the appliance before starting any work
• Remove the console or control housing per your model's service instructions to access the existing overlay
• Peel off the old overlay and any adhesive residue; align the new overlay carefully before securing
• Use caution with sharp edges and avoid forcing components; test the controls after reassembly

This control module housing protects and secures the refrigerator's electronic control board, helping keep the board stable and shielded from damage and moisture. Replacing a damaged housing restores proper support and connector alignment for the control module. What it does:

• Provides a mounting enclosure and protective cover for the refrigerator control module
• Keeps wiring harnesses and connectors properly routed and secured
• Helps prevent moisture and debris from contacting the control board
• A damaged or cracked housing can lead to loose connections, intermittent operation, or control/display issues

• Disconnect power to the appliance before starting any repair
• Handle the control board and electronics with care; avoid static discharge
• Ensure all connectors are fully seated and routed the same way as the original housing
• Reuse factory mounting hardware unless replacement fasteners are specified

The Electronic Control Board is an OEM replacement part for Whirlpool refrigerators. This Electronic (JAZZ) Control Board manages various functions of your refrigerator, ensuring proper temperature control and operation. After installation, the board will need to be programmed. An instruction sheet is included.

Causes of a bad Electronic Control Board can include electrical surges, which can damage components on the board, age-related wear and tear affecting its functionality, and exposure to moisture or extreme temperature fluctuations. These factors can lead to a malfunctioning fridge with erratic behaviors.

Symptoms of a bad Electronic Control Board include:

• The refrigerator not cooling properly
• Irregular defrost cycles leading to frost buildup or thawing issues
• Unresponsive controls or display issues
• The ice maker or water dispenser not working as expected

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

The Refrigerator Door Switch is an OEM part for Whirlpool refrigerators. This switch monitors the opening and closing of the refrigerator door, activating lights and functions as needed while also keeping track of door activity for diagnostics purposes.

Causes of failure may be from normal wear and tear over time, moisture damage, or impact if the door is accidentally slammed.

Symptoms of a bad door switch include:

• Lights not turning on/off with door movement
• Dispensers or ice/water not working properly
• Cooling and freezing performance affected
• Error codes related to door operation

This OEM replacement part is compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models as well.

This replacement cover restores a finished look and protects underlying components on your appliance. Replacing a cracked or missing cover helps keep out debris and moisture while maintaining proper function and appearance. What it does:

• Shields internal parts from dust, splashes, and accidental contact
• Helps maintain intended airflow/water routing depending on location
• Secures the opening or mechanism for a snug, rattle-free fit
• Typical symptoms: cracked, warped, loose, or missing cover; exposed components; new rattling or vibration noises

• Disconnect power; shut off water supply before servicing
• Note orientation and any clips/gaskets before removal; transfer reusable hardware
• Reinstall with original screws/clips; do not overtighten to avoid cracking
• Restore power and test; check for proper fit and any leaks or vibration

This replacement housing is the outer cabinet component that supports and protects internal appliance parts, restoring proper alignment and preventing debris intrusion. It's a direct-fit service piece when the original housing is cracked, bent, or damaged. What it does:

• Replaces a damaged or cracked outer housing to restore structural support
• Protects internal components from dirt, moisture, and impact
• Reduces vibration and rattling caused by warped or broken housing
• Helps maintain correct alignment of internal assemblies for reliable operation

• One replacement housing

• Disconnect power (and water if applicable) before starting any repair
• Handle edges carefully — use gloves to protect against sharp metal or plastic
• Follow OEM instructions for removal and reassembly; fasteners and trim may be required

The LED Light Module is an OEM replacement part for Whirlpool refrigerators. This lighting module is responsible for providing illumination inside the refrigerator and freezer compartments. It contains energy-efficient LEDs that produce a bright, consistent light.

Causes of a bad LED Light Module can include failing or damaged LEDs due to age or accidental impact. Sensor or electrical issues within the module itself could also cause lighting problems.

Symptoms of a bad LED Light Module include:

• Dim, flickering, or non-functioning lights
• Parts of the lighting not working properly
• Premature burning out of LEDs
• Electrical humming or buzzing from the lighting area

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This electronic control board is the brain of the appliance, directing power and timing to components so cycles run as designed. Replacing a failed board restores proper operation and consistent, reliable performance. What it does:

• Controls cycle timing and sends power to motors, valves, heaters, and other loads
• Processes inputs from sensors and switches to start and advance cycles
• Resolve a unit that won't start or appears dead/unresponsive
• Correct erratic operation, stuck cycles, or recurring error codes

• 1 electronic control board

• Disconnect power before servicing; turn off water or gas if applicable
• Use ESD precautions and handle the board by its edges only
• Document wire locations or take photos; move connectors one at a time and reuse mounting hardware
• Some models require calibration or programming after installation—follow the tech sheet/service manual

The Thermistor Kit is an OEM part for Whirlpool refrigerators and freezers. This component plays a role in monitoring and controlling the temperature within your appliance. A thermistor is a type of resistor whose resistance changes with temperature changes, allowing the refrigerator's control system to accurately maintain the desired cooling levels based on the readings it provides.

Causes of a bad thermistor can include wear and tear from constant use, exposure to extreme temperatures that can damage the component, or electrical issues such as short circuits.

Symptoms of a bad Thermistor Kit include:

• The refrigerator or freezer is too cold or not cold enough
• The appliance cycles on and off more frequently or for longer periods than normal
• Unexplained changes in temperature settings

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This wire harness assembly routes electrical power and signals between the appliance control and components so the unit operates reliably. It replaces damaged or worn wiring to restore proper electrical connections and reduce intermittent faults. What it does

• Delivers power and control signals between control board and components.
• Replaces frayed, burned, or disconnected wiring that can cause intermittent operation.
• Helps resolve failures where components do not receive power or controls are unresponsive.
• Prevents shorts and arcing when damaged insulation or connectors are present.

• Disconnect power (unplug or shut off breaker) before starting any repair.
• Photograph existing routing and connector positions to ensure correct reinstallation.
• Handle connectors carefully; do not force pins or terminals. Match connector shapes and colors.
• Inspect nearby wiring and terminals for heat or corrosion; replace if damaged.
