Parts for Ge AEM08LVW1: Room Air Conditioner Parts

This filter sub-assembly is the refrigerator water-filter housing that holds and secures the replaceable cartridge, ensuring proper water flow to the dispenser and ice maker. Replaces a worn or damaged housing to restore reliable water delivery. What it does:

• Houses and seals the inline/replacement water filter cartridge so water is routed through the filter media
• Prevents leaks by providing a secure connection between the filter cartridge and refrigerator plumbing
• Restores normal water flow when a cracked or broken housing was restricting or leaking water
• Helps eliminate taste and odor issues when used with the correct, compatible filter cartridge

• One filter sub-assembly

• Turn off water supply and unplug the refrigerator before servicing
• Depressurize the line by dispensing water after the supply is off, then remove old housing and filter per your model's instructions
• Hand-tighten fittings; inspect O-rings and replace if damaged to prevent leaks
• After installation, turn on water, check for leaks, and run/flush water through the new filter housing per refrigerator instructions

This 8 mm diameter gasket creates a tight seal where a small round-profile seal is required, helping prevent water or air leaks and keeping the appliance operating properly. It's a direct-fit replacement when the original seal is worn or damaged. What it does:

• Replaces a worn or torn round-profile gasket to restore proper sealing
• Helps prevent leaks of water, steam, or conditioned air in sealed connections
• Reduces drafts and moisture intrusion that can affect appliance performance
• Restores the original interface between mating parts for reliable operation

• One 8 mm diameter gasket

• Turn off power and water to the appliance before beginning work
• Clean the sealing surfaces and remove old gasket material before installing the new gasket
• Seat the gasket evenly around the mating surface; avoid stretching or twisting the seal

This flat washer provides a secure, even load distribution for a fastener on the appliance, helping maintain proper assembly and reduce loosening or wear. Use it to replace a damaged or missing washer during repairs. What it does:

• Sits under a nut or bolt to spread load and protect the appliance surface
• Helps prevent fasteners from loosening due to vibration
• Restores proper spacing and alignment for connected parts
• Commonly replaced when you see corrosion, cracking, or a loose connection

• One flat washer

• Disconnect power and turn off water supply before starting any repair
• Tighten fasteners to a snug fit—avoid over-tightening which can crush the washer
• If adjacent parts show damage or corrosion, inspect and replace as needed

This nut with attached washer is a small securing fastener used to clamp appliance parts and prevent loosening. It provides a low-profile, integrated washer bearing surface for a reliable hold. What it does:

• Secures panels, brackets, or components to prevent movement and rattling
• Maintains clamping force where an integrated washer is needed
• Helps keep electrical and mechanical connections stable
• Common symptom: loose or vibrating parts, squeaks, or components that shift during use

• One nut with attached washer

• Disconnect power and water before servicing
• Use the correct socket or wrench to avoid rounding the nut
• Tighten to snug fit — avoid overtightening which can strip threads or damage parts
• If replacing a rusted or damaged fastener, inspect mating threads and replace as needed

This connection bar is a cabinet-mounting support piece that secures panels or components to the appliance cabinet for stable alignment and reduced vibration. It restores proper fit and helps maintain door/panel positioning. What it does:

• Provides a secure attachment point between an internal component or panel and the appliance cabinet
• Helps eliminate panel rattling, vibration, or minor misalignment
• Maintains correct spacing and support for fitted panels or assemblies
• Supports long-term stability of the mounted component

• One connection bar to cabinet

• Disconnect power to the appliance before beginning any repair
• Remove any panels or trim that block access to the mounting location; keep fasteners organized
• Use appropriate hand tools and avoid over-tightening fasteners to prevent damage

This curtain assembly is the extendable side panel for a window air conditioner. It fills the gap between the A/C cabinet and window frame to restore a secure fit and help block drafts, moisture, and debris.

• Extends to close the side opening between the unit and the window jamb
• Helps reduce unwanted airflow, dust, moisture, and insects around the A/C
• Aids in maintaining a stable, properly aligned window installation
• Common symptoms: cracked or torn panel, brittleness, missing panel, visible light or air leaks at the sides

• Disconnect power and support the A/C so it cannot shift or fall while servicing
• Remove the damaged panel and retain any screws or mounting clips for reuse
• Slide the new curtain into the cabinet tracks and secure it to the window frame per your model's instructions
• Match orientation to the original panel and ensure smooth extension and an even seal before use

This door gasket seal replaces a worn or damaged refrigerator or freezer door seal to restore a tight closure and help maintain proper temperature. It helps stop air leaks that can cause frost build-up and higher energy use. What it does:

• Forms a replacement seal around the appliance door to maintain an airtight closure
• Helps reduce interior temperature fluctuations that can lead to frost or spoiled food
• Restores proper door alignment and sealing where old gasket is cracked, torn, or compressed
• Commonly used when you see visible gaps, drafts, or persistent moisture at the door edge

• Designed for a direct OEM-fit; inspect the door channel and mounting surface before installing
• Clean the gasket channel and door edge to remove debris for best sealing contact
• Warm the gasket slightly (per OEM guidance) if needed for easier fitting; avoid open flames

This accordion panel seal replaces the flexible gasket that seals the appliance cabinet panel, helping keep the cabinet closed and reducing drafts, dust, and vibration noise around the panel area. What it does

• Replaces worn or torn accordion-style gasket on the cabinet/panel edge
• Restores a snug seal to reduce drafts and prevent dust or lint from escaping
• Reduces panel vibration and rattling caused by loose or damaged seals
• Helps maintain proper airflow routing by sealing the cabinet opening

• Disconnect power to the appliance before beginning any repair
• Removal of the front or cabinet panel is typically required; keep fasteners organized
• Handle edges and clips carefully—use proper tools to avoid damaging the seal or cabinet
• Follow OEM disassembly/reassembly instructions

This thermostat is the temperature control for room air conditioners. It senses temperature and cycles the compressor to maintain your set comfort level, helping restore consistent cooling when the original control becomes inaccurate or fails. What it does:

• Monitors temperature and opens/closes contacts to start and stop the compressor
• Helps the unit reach and maintain the temperature you select
• Helps resolve symptoms such as: AC won't turn on/off at the dial setting, runs continuously, short-cycles, or temperature adjustments have little effect
• Direct-fit replacement designed for the original mounting location

• 1 thermostat

• Disconnect power before servicing to avoid electrical shock
• Access the control panel; note wire locations and transfer any mounting hardware from the old part
• If your model uses a capillary sensing tube, route it exactly as original and secure in clips; do not kink or sharply bend it
• Reassemble, align the control knob, and test operation across several temperature settings

The Display Circuit Board is an OEM part for GE window air conditioners. Mounted at the front of the unit, it operates the LED lighting and screen for indicating settings.

Causes of a faulty display board can include damage from moisture intrusion over time compromising sensitive onboard electronics. Condensation and dust particles get trapped inside sealed front panels adding stress.

Symptoms of a bad display board involve:

• Random shutoffs or failure to latch on temperature settings
• Inability to maintain cooling or fans at set levels
• Refusal to power on without control response
• Noisy buzzing or humming coming from electrical areas

This genuine GE replacement preserves convenient readout and control options. Compatible with some Frigidaire, Midea, and EdgeStar units, proper functioning maximizes user-friendly operation. Compatibility with wireless remote devices is also maintained for distance control of indoor comfort.
