Parts for Frigidaire WL24F2WWMA: 07 - Transmission Parts

This tub seal kit replaces a worn or damaged tub gasket to restore the appliance's watertight seal and reduce leaks. It's a direct-replacement style kit used during tub or pump repairs to help maintain proper sealing. What it does:

• Replaces the tub sealing components that prevent water from escaping the tub area
• Helps stop common leak symptoms like puddling or water on the floor near the appliance
• Restores a secure seal after tub or pump disassembly to reduce moisture-related damage
• Useful when service shows visible gasket wear, cracks, or hardening

• Disconnect power and water supply before starting any repair
• Drain the appliance and remove any obstructing panels to access the tub area
• Follow the OEM service manual for disassembly and correct seal orientation

This door gasket creates a tight seal around the refrigerator door to help maintain proper cooling and reduce energy loss. Replacing a worn gasket restores a full seal for better temperature control and food preservation. What it does:

• Seals the door to prevent warm, humid air from entering the refrigerated compartment
• Helps reduce frost buildup and keeps interior temperatures stable
• Improves cooling efficiency and can lower energy use caused by a leaking seal
• Stops odors and moisture transfer between the fridge interior and kitchen

• Unplug the refrigerator before starting and remove any food or shelves blocking the seal.
• Work slowly to avoid stretching or creasing the gasket; follow door-hinge or trim removal steps if needed.
• Inspect the door flange for damage and clean the mating surface before installing the new gasket.
• After installation, allow the gasket to seat fully and check for uniform contact around the door; warm-up or seating time may be needed.

This transmission assembly drives the agitation and spin cycles by transferring motor power to the tub. Replacing a worn transmission helps restore proper wash action and spin performance.

• Converts motor rotation into the geared motion needed for wash (agitate) and spin
• Shifts between agitation and spin modes during the cycle
• Common failure signs: no or weak agitation; no spin or slow spin
• Other symptoms include loud grinding/rumbling, oil leaking from the center area, or the motor running while the tub doesn't move

• Disconnect power and water; move the appliance to a stable work area and use proper lifting support
• Access the drive assembly from below; support the tub/frame to prevent tipping
• Mark component orientation, remove fasteners and drive components as needed, and transfer any reusable parts from the original unit
• Tighten mounting hardware evenly, then run a test cycle and check for leaks
