Parts for DD24DCTX7-84679-B: Tub & Components Parts

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

This drain filter assembly captures food and debris from the dishwasher sump to help prevent clogs and protect the pump. Replaces a worn or damaged sump filter to restore proper draining and reduce leftover particles on dishes. What it does

• Screens out food scraps and larger debris before water reaches the drain pump.
• Helps prevent pump blockages that can cause poor draining or standing water.
• Can reduce odors caused by trapped food in the sump area.
• Useful when the existing filter is cracked, broken, or missing pieces.

• One drain filter assembly

• Disconnect power and water supply before beginning any service.
• Remove lower rack and access the sump area; confirm seating and orientation before final reassembly.
• Inspect surrounding seals and the pump inlet; clear any additional debris.
• Run a short drain/rinse cycle after installation to confirm proper fit and function.

The Filter Plate Kit is an OEM part for Fisher & Paykel dishwashers. The filter plate is an important component that traps food particles and debris from circulating throughout the dishwasher during the wash cycle. It acts as a barrier, preventing larger food bits from potentially clogging other areas or damaging components.

A worn or damaged filter plate may not adequately filter out particles, allowing food to pass through and potentially cause issues. Signs of a filter plate needing replacement include tears, cracks, or holes in the mesh/screen.

Symptoms of a bad filter plate include:

• Dirty or soiled dishes even after a full cycle
• Buildup of debris or clogs in other areas
• Muddied or dirty wash water being drained
• Food particles detected in areas they shouldn't be

This motor rotor assembly is the magnetic rotor used in SmartDrive-style direct-drive top-load washers. It works with the stator to turn the wash basket for wash and spin. Replacing a worn rotor restores smooth, reliable motor performance.

• Provides the rotating component of the direct-drive motor; interacts with the stator to drive agitation and spin
• Common symptoms of failure: no spin or agitation, humming with little movement, loud knocking/grinding from the base, or cycles stopping with a motor fault
• Visible cracks in the magnet ring or stripped internal splines indicate the rotor should be replaced
• Restores proper torque transfer and reduces vibration/noise when the original rotor is worn or damaged

• Disconnect power and water; tilt the washer back to access the underside
• Remove the bottom cover, hold the tub, remove the center bolt, and pull the rotor straight off the shaft
• Strong magnets—keep fingers and tools clear; inspect/clean the shaft and splines before installing the new rotor
• Align the rotor on the splines, reinstall and tighten the center bolt per service guidance, refit the cover, and run a test cycle

The Rinse Aid Dispenser Cap is an OEM part for Fisher & Paykel dishwashers. It fits on top of the rinse aid dispenser compartment located inside the dishwasher. The cap plays an important role in regulating the flow of rinse aid during cycles to ensure glasses and dishes dry spot-free.

Causes of a bad cap can be normal wear and tear over time, cracks or breakage, or issues with the dispenser mechanism it interacts with.

Symptoms of a bad rinse dispenser cap include:

• Insufficient or improper dispensing of rinse aid during cycles
• Water spots or film left on dishes after washing
• Difficulty filling or refilling the rinse aid reservoir

This Kit Dispenser is an OEM part for Fisher & Paykel dishwashers. It is a crucial component that houses and dispenses detergent and rinse aid during the dishwasher's cycles. Designed specifically for Fisher & Paykel models, this dispenser kit ensures a perfect fit, and effective operation, and maintains the dishwasher's efficiency.

Dispenser problems in dishwashers can arise from mechanical failure, clogging due to detergent residue, or wear and tear over time. A malfunctioning dispenser can affect the dishwasher's cleaning performance, leading to poorly cleaned dishes.

Symptoms of a failing dispenser in a dishwasher include:

• Detergent is not being released properly during cycles.
• Rinse aid compartment leaking or not dispensing correctly.
• The dispenser door not opening or closing properly.
• Residue or buildup is visible in the dispenser area.
• Dishes remaining greasy or spotted after washing.

This OEM Fisher & Paykel part is also compatible with Bertazzoni, Dacor, and Viking brands.


This harness and fan assembly supplies the electrical connections and blower fan needed to restore airflow and cooling in compatible Fisher & Paykel appliances. It replaces a damaged harness or failed fan to help re-establish proper ventilation. What it does:

• Provides the wire connections and mounted fan used to move air for cooling, venting or drying cycles
• Restores airflow when a unit has reduced or no air movement
• Can address symptoms such as a noisy fan, intermittent fan operation, or overheating warnings
• Secures wiring and fan in the original mounting location to maintain safe operation

• Disconnect power to the appliance before attempting any service
• Inspect connectors and routing; match OEM connector orientations during installation
• Use basic hand tools and avoid pinching wires; replace any damaged clips or fasteners

The Control Module is an OEM part for Fisher & Paykel dishwashers. It is a key electronic component responsible for operating and controlling the various functions and cycles of the dishwasher.

Causes of a bad control module can include damage due to power surge or fluctuation, faulty wiring connections, or general component failure over time.

Symptoms of a bad control module include:

• The dishwasher not turning on at all
• Blinking or unresponsive display
• Inability to select wash cycles
• Improper functioning of wash arms, spray jets, or other moving parts

This motor assembly (PH5) kit replaces the worn or failed motor that powers the appliance's driven component, restoring normal operation and reducing noise or intermittent function. Designed as a direct-fit replacement when the original PH5 motor fails. What it does:

• Drives the appliance's mechanical component to restore normal operation.
• Stops symptoms such as the motor not running, intermittent operation, or unusual humming/noise.
• Replaces worn bearings or electrical winding failures that cause reduced performance.
• Helps prevent secondary damage from a failing motor (e.g., overheating or seizing).

• One motor assembly kit (PH5)

• Disconnect power to the appliance before beginning any work.
• Basic hand tools typically required;
• Handle the motor and connectors carefully to avoid damage to wiring and mounting surfaces.

A replacement flap valve kit that restores the flap seal and O-ring used in the appliance's valve assembly to help control and seal water flow. Fits as a direct replacement to repair leaks or improper valve sealing. What it does:

• Replaces worn or damaged flap valves and O-rings that can allow leaks or prevent proper valve closure
• Restores a reliable seal in the valve/flap assembly to help stop drips and reduce water bypass
• Helps correct symptoms like intermittent leaking from the valve area or inconsistent water flow through the valve
• Simple wear-part replacement—addresses age-related deterioration of rubber sealing surfaces

• Disconnect power and water supply before beginning any repair
• Inspect valve housing for debris or damage before installing new parts
• Ensure flap orientation and O-ring seating are correct; replace one side at a time if helpful
• Hand-tighten fittings and test for leaks after reassembly; do not overtighten plastic components

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

The Spray Arm Assembly is an OEM part for Fisher & Paykel dishwashers. It is responsible for evenly distributing water and cleaning solution throughout the dish rack during the wash cycle. The spray arm assembly features holes that rotate, ensuring all dishes are thoroughly rinsed and sanitized.

Symptoms of a faulty spray arm assembly include:

• Poor or uneven cleaning and rinsing results
• Caking or spots left behind on dishes
• Mineral or limescale buildup inside the dishwasher

Causes can be mineral deposits or food residue clogging spray arm holes over time. Repeated impact or damage reduces the assembly's spray pressure and distribution.

The Kit Seal Wash 605 is an OEM part for Fisher & Paykel dishwashers. It is a multi-piece sealing kit that includes gaskets, o-rings, tub seals and drainage components. These seals work together to prevent water leaks, ensuring cycles finish efficiently.

Symptoms of a leaking or faulty seal kit are:

• Puddles or standing water inside or underneath the dishwasher
• Extended or incomplete drying even when water has fully drained
• Water marks or residue left behind on dishes after washing

Causes of a failed seal kit include normal deterioration of rubber and plastic materials over extended use. Mineral deposits can harden seals, compromising flex.

This shim motor assembly provides the replacement spacer and mounting hardware that secures and positions the motor for proper alignment and stable operation. It helps restore correct motor fit and reduces vibration-related noise. What it does:

• Centers and spaces the motor to maintain correct shaft alignment
• Helps prevent motor wobble that can cause noise, wear, or rubbing
• Restores correct clearance between the motor and adjacent components
• Supports reliable motor mounting after wear or damage to the original shim

• Disconnect power to the appliance before attempting any repair
• Inspect surrounding mounting points and fasteners; replace any damaged hardware
• Reassemble panels and test operation after installation
