Parts for Broan 113023: Wiring Diagram / Hardware Bag Parts

This strain relief secures and protects a power cord where it enters the appliance, preventing wire pull-out and insulation damage for safer, longer-lasting operation. It's a direct-fit replacement used on compatible Broan ventilation products. What it does:

• Clamps and supports the power cord to prevent tugging from stressing internal connections
• Reduces wear to wire insulation at the cabinet entry point
• Helps maintain a secure electrical connection to avoid intermittent power or arcing
• Protects wiring from sharp edges and improves overall safety

• One strain relief clamp

• Turn off and disconnect power at the breaker before servicing the appliance
• Remove access panels as needed to reach the cord entry; install the clamp around the cord and seat into the cabinet opening
• Ensure wiring insulation is undamaged and routed without pinches before reassembling

This is a factory replacement part sold individually to service compatible Broan ventilation products. It provides a direct-replacement component when the original, compatible part is missing or damaged to help restore normal operation. What it does:

• Replaces a failed or missing factory component in supported Broan ventilation equipment
• Helps restore fit and function without modifying the appliance
• Commonly used during routine repairs or component swaps
• Resolves symptoms such as unusual noise, loose fit, or missing functionality when the original piece is damaged

• One replacement part

• Verify OEM part number and appliance model before ordering
• Disconnect power to the appliance before attempting any service
• Follow appliance manufacturer instructions
• Use correct fasteners and torque; do not force parts into place

This listing is for an unidentified Broan replacement part. It may be the service part your appliance needs when an original component is missing or damaged. What it does

• Sells as a direct replacement for a Broan part that currently lacks an OEM name/description
• Can help restore appliance function when matched to the correct model and part number
• Use only after confirming the part number and physical match to your existing component

• One unidentified Broan replacement part as shown

• Disconnect power to the appliance before attempting any service
• Return or exchange only if the shipped part exactly matches the component on your appliance

This screw is a direct replacement fastener used to secure range hood and ventilation components. It restores proper fit and helps stop loose panels or rattling for a stable, safe appliance. What it does:

• Secures panels, brackets, or housing components to prevent movement and vibration
• Restores proper alignment of covers, filters, or internal parts
• Helps eliminate rattling noises caused by loose fasteners
• Works with compatible Broan range hood and ventilation assemblies

• Disconnect power to the appliance before servicing to reduce shock risk
• Use the correct driver or bit to avoid stripping the screw head
• Thread carefully and avoid overtightening to prevent damage to mounting holes or plastic parts

A small flat washer that helps secure fasteners and evenly distributes clamping force to protect parts and reduce loosening or wear. Commonly used on mounting screws and appliance panels to improve fit and stability. What it does:

• Spreads load from a screw or bolt to prevent damage to mounting surfaces
• Helps keep fasteners tight and reduces the chance of loosening or vibration
• Prevents metal-on-metal contact, reducing wear and noise
• Useful when replacing corroded, bent, or missing washers that cause rattling or loose panels

• Disconnect power to the appliance before servicing and follow all safety precautions
• Use the correct screw/bolt size and washer orientation—replace like-for-like
• Inspect mating hardware and threads; replace damaged fasteners if needed
• Small part: keep away from children and work on a clean surface to avoid loss
