Parts for Thermador SGS/X365ZS: 01 - Burner Components Parts

The Cooktop Bracket Kit is an OEM part for Bosch cooktops. This bracket and hardware kit serves to securely fasten the cooktop surface to the underlying countertop.

Causes of a bad bracket can include wear and deformation from heavy cooktop use over time, or damage to fastening screws from accidental impacts.

Symptoms of a bad bracket and fastening kit include:

• The cooktop surface becoming loose, wobbly, or unstable during use
• Gaps appearing between the cooktop and countertop edges
• Reduced heat containment and risk of burns from loose surfaces

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This jet holder secures the jet/nozzle assembly, keeping it correctly positioned for consistent flow and performance. Replacing a cracked or loose holder restores proper alignment and helps prevent leaks, drips, or irregular spray from the outlet.

• Holds the jet/nozzle firmly in place to maintain directed flow
• Keeps the jet aligned for even, reliable output
• Helps seal the connection to reduce drips at the fitting
• Typical symptoms: loose or missing jet, visible cracks, leaks, weak or erratic spray

• Disconnect power and shut off the applicable supply to the appliance before servicing
• Access the jet assembly and note the holder's orientation for correct reinstallation
• Inspect any O-rings/seals at this connection and replace if worn or damaged
• Reassemble carefully and avoid overtightening; test for proper flow and no leaks

This jet holder mounts in the burner assembly for a 12,000 BTU burner. It positions and secures the orifice (jet) and helps seal and align the gas path so the burner lights reliably and produces a steady flame.

• Holds and aligns the burner orifice for the 12,000 BTU burner
• Provides a sealed passage from the valve to the burner head
• Helps restore proper flame height and pattern when the original holder is stripped, cracked, or corroded
• Common symptoms: weak or uneven flame, burner won't light, or jet/orifice will not seat securely

• Shut off gas supply and power; allow the appliance to cool before starting
• Remove grates, burner caps, and burner head to access the holder
• Transfer the existing orifice/jet to the new holder; tighten fittings carefully—do not overtighten into soft metal
• Reassemble, restore gas, and perform a leak check with an approved solution

This jet holder mounts in the burner assembly for a 12,000 BTU burner. It positions and secures the orifice (jet) and helps seal and align the gas path so the burner lights reliably and produces a steady flame.

• Holds and aligns the burner orifice for the 12,000 BTU burner
• Provides a sealed passage from the valve to the burner head
• Helps restore proper flame height and pattern when the original holder is stripped, cracked, or corroded
• Common symptoms: weak or uneven flame, burner won't light, or jet/orifice will not seat securely

• Shut off gas supply and power; allow the appliance to cool before starting
• Remove grates, burner caps, and burner head to access the holder
• Transfer the existing orifice/jet to the new holder; tighten fittings carefully—do not overtighten into soft metal
• Reassemble, restore gas, and perform a leak check with an approved solution

This replacement jet holder fits the 15,000 burner on gas cooktops and ranges. It supports the orifice and channels gas to the burner head, helping restore a stable flame and consistent heat when the original holder is damaged or corroded.

• Positions and secures the orifice for the 15,000 burner
• Routes gas from the valve/manifold to the burner head
• Helps maintain proper flame shape and output
• Replace if cracked, warped, or corroded; symptoms can include weak or uneven flame, yellowing, or difficulty lighting at that burner

• Shut off gas supply and disconnect power before servicing
• Remove grates, burner caps, and heads; raise or remove the cooktop surface to access the holder
• This holder is specific to the 15,000 burner position; transfer the orifice and any seals as required
• After reassembly, check all gas connections for leaks with a soap-and-water solution and verify burner operation

This replacement jet holder fits the 15,000 burner on gas cooktops and ranges. It supports the orifice and channels gas to the burner head, helping restore a stable flame and consistent heat when the original holder is damaged or corroded.

• Positions and secures the orifice for the 15,000 burner
• Routes gas from the valve/manifold to the burner head
• Helps maintain proper flame shape and output
• Replace if cracked, warped, or corroded; symptoms can include weak or uneven flame, yellowing, or difficulty lighting at that burner

• Shut off gas supply and disconnect power before servicing
• Remove grates, burner caps, and heads; raise or remove the cooktop surface to access the holder
• This holder is specific to the 15,000 burner position; transfer the orifice and any seals as required
• After reassembly, check all gas connections for leaks with a soap-and-water solution and verify burner operation

Used to hold down the jet holder assembly.

The Tape, Foam is an OEM part for Bosch cooktops. This foam tape creates a tight seal between the cooktop surface and surrounding countertop. It helps contain spills and keeps external surfaces heat-isolated.

Causes of bad foam tape can include wear and breakdown of the adhesive over repeated exposure to cooking heat and cleaning chemicals.

Symptoms of a bad foam tape include:

• Fluids leaking down around the edges of the cooktop
• Hot surfaces outside the cooktop area that can cause burns
• Reduced heat containment impacting cooking efficiency

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This push-on retainer clip holds a 6mm shaft securely in place on compatible appliance components, restoring proper axial restraint and preventing parts from sliding off during operation. Simple, low-profile fastening for shaft retainment. What it does:

• Secures shafts and spindles with a 6mm outer diameter to prevent axial movement
• Keeps knobs, pulleys, or rotating components positioned correctly during use
• Commonly used where a quick, tool-free clip is required for retention
• Can resolve symptoms like loose or detached knobs, wobbling pulleys, or parts sliding along the shaft

• One push-on retainer clip sized for 6mm shaft mounting

• Push the clip onto the shaft groove until it snaps into place; ensure full engagement before operating
• Use snap-ring pliers or appropriate tools if removal is required to avoid damage
• Wear eye protection when installing or removing clips to guard against sudden release

This left-side burner base fits the "D" burner location and provides a stable, heat-resistant support for the burner assembly so the cooktop heats evenly and stays aligned during use. Replaces a worn, cracked, or warped burner base. What it does

• Supports and positions the burner head and cap for proper flame distribution
• Keeps burner components aligned to prevent gas/air misflow and uneven heating
• Resists heat and wear from regular cooking use
• Helps prevent burner wobble, cracking, or contact with the cooktop surface

• One left-side burner base (left "D" position), exactly as pictured

• Turn off gas/electric and disconnect power to the appliance before starting work
• Remove grates and burner components to access and replace the base; keep track of fasteners
• Inspect nearby parts (burner head, cap, ignition) for damage when replacing the base

This burner venturi is the air-gas mixing tube between the orifice and burner head on select gas cooktops and ranges. The 10.7 mm size matches specific burners. Replacing a clogged or damaged venturi restores proper flame and dependable ignition.

• Mixes incoming gas with primary air and channels it to the burner head
• Can help resolve weak/uneven flame, yellow tipping, or delayed ignition when the original venturi is restricted or damaged
• Supports consistent heat output and stable blue flames on the matched burner
• Installs between the orifice holder/nozzle and the burner base

• Shut off gas supply and power; allow the appliance to cool completely
• Remove burner cap and head; note the venturi's orientation before removal
• Clear debris from the orifice area without pushing material into the jet
• Reassemble, restore gas, then leak-test and verify proper flame pattern

This 13.7 mm venturi is the burner mixing tube used on select gas cooktops and ranges. It blends gas with air to create a stable flame and helps restore consistent burner performance when the original is clogged or damaged.

• Mixes gas from the orifice with air to support proper ignition and flame quality
• Helps maintain a steady blue flame and even heating
• A restricted or damaged venturi can cause weak or uneven flames, delayed ignition, yellow/orange flames, or popping/lifting
• Replacing a corroded or blocked venturi can improve burner performance

• Shut off gas supply and power; allow the surface to cool before servicing
• Remove grates, burner caps, and burner head to access the venturi; note orientation and routing
• Seat the venturi fully over the orifice; transfer/reuse any original screws, spacers, or gaskets if applicable
• Restore gas and check connections with a soapy-water test; verify flame height and quality

Replacement potentiometer that restores precise control of appliance settings by regulating resistance in the control circuit. Use it when a rotary control is unresponsive or produces inconsistent settings for reliable operation. What it does:

• Varies electrical resistance to adjust settings controlled by the knob (e.g., temperature, speed, or level)
• Replaces a worn or faulty rotary control that causes unresponsive or erratic behavior
• Helps restore smooth, predictable adjustment when the original control no longer responds properly
• Fits into the existing control assembly to restore user input accuracy

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Access the control panel or module to remove the old potentiometer; note knob/shaft orientation and wiring
• Match wire connections and mounting position of the replacement part; test operation before reassembling the panel

This replacement gas valve regulates gas flow to the appliance's burner assembly so the unit can ignite and reach proper heat. Use this exact-fit valve to restore reliable ignition and consistent heating performance. What it does:

• Controls and meters gas flow to the burner assembly for safe ignition and stable flame
• Replaces a failed or leaking valve to stop intermittent or no-heat operation
• Addresses symptoms such as burners not lighting, weak or inconsistent flame, or the appliance failing to heat
• Works as the original-style valve designed for the specified 210 / 15,000 configuration

• Turn off gas supply and electrical power before starting work; follow local codes
• After installation, check all connections and test for gas leaks with a proper leak detector or soapy-water test
• Do not attempt to disassemble or repair the valve; replace if defective

Solenoid valve controls the appliance's water inlet using an electrically actuated plunger to open and close flow. Replacing a failing valve helps restore proper filling and can stop leaks, overfilling, or no-fill conditions. What it does

• Electrically opens and closes the inlet to allow water into the appliance during fill cycles.
• Shuts off water flow when the valve is de-energized to prevent overfilling.
• Common symptom fixes: no water fill, continuous filling, visible leaks at the inlet, or related fill/flood error codes.
• Interfaces with the appliance inlet hose and the electrical connector for timed/controlled fill cycles.

• One solenoid valve.

• Disconnect power and shut off the water supply before starting any repair.
• Handle electrical connectors carefully; ensure correct orientation and a secure connection.
• Inspect and replace any worn seals, gaskets, or hoses to prevent leaks after installation.

The Spark Switch is an OEM part for Bosch ranges. This part ignites the burners by sending a signal to the spark module, which then produces the spark needed to ignite the gas.

Causes of a bad spark switch can include wear and tear from regular use, damage from spills or cleaning agents, or electrical issues.

Symptoms of a bad spark switch include:

• Burners not igniting
  Continuous clicking even after the knob is turned off
  No spark when attempting to ignite the burner
  The cooktop not producing a flame

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

The Simmer Control is an OEM component specifically designed for Bosch ranges. It regulates gas flow to provide the lowest possible flame setting needed for delicate cooking tasks. Precise control allows for uniform, attentive simmering.

Symptoms of a bad simmer control include inconsistent or unadjustable flame heights on low settings. Cracks, damage, or wear of internal mechanisms over time can also cause unstable flame control.

Causes of bad simmer control can be normal wear and tear issues like dirt buildup impeding mechanisms. Accidental impact or overheating leading to cracks are other causes for replacement.

Symptoms of a bad simmer control include:

• Flames that surge or fluctuate below the lowest settings
• Inability to adjust the flame down sufficiently low
• Burners that shut off or cause overflow flooding on low-heat

This OEM Bosch part is also compatible with Thermador and some Kenmore ranges. Replace for dependable, Fine-tuned low-heat performance.


This is a quality spark re-igniter module for stoves, ranges, and ovens. This part is located between the cooktop on the stove. This part creates a spark to ignite a low-pressure gas flow that goes to the flame pilot light. It will stay lit until the thermostatic control on the oven is turned to the off position.Sometimes, the spark re-igniter will become damaged or stop working, which can cause problems using the range. If there is a weak or nonexistent spark between the igniter pin and the edge of the gas burner, this is a sign the spark re-igniter needs to be replaced. The first thing to do is unplug the stove from the wall. Access the back of the stove and remove the large panel. Remove the original component and install the new one in its place.This is an authentic OEM replacement part that has been obtained directly from the manufacturer. The spark re-igniter module is sold as a single part. It is made to be compatible with Bosch and Thermador stoves and ranges.

The Knob is an OEM part for Bosch ovens and ranges, designed to offer precise control over the cooking settings. This knob allows users to set the temperature and cooking mode, ensuring a seamless cooking experience. Crafted with durability and usability in mind, it fits comfortably in the hand, offering a smooth rotation for adjusting settings.

Causes for a Knob to require replacement can include physical damage from accidental knocks, degradation of materials over time, or the effects of heat and cleaning chemicals that can wear down the text and symbols.

Symptoms of a bad Knob include:

• Difficulty in turning the knob
• Faded or worn indicators, making it hard to select the correct settings.
• The knob coming loose or falling off

This OEM Bosch part can also be used on Thermador and Gaggenau appliances.

Color: black. Measures about 2 inches in diameter.

This replacement plate restores the proper mounting/cover surface specified in your appliance's assembly, helping keep components aligned, protected, and secure for reliable operation. Ideal for replacing a bent, cracked, or missing original.

• Serves as the specified support/cover plate within the assembly
• Maintains alignment and a secure fit for adjacent parts
• Replace when the original is bent, cracked, worn, or missing
• Symptoms can include rattling, misalignment, loose components, or visible damage in the plate area

• Disconnect power and shut off gas/water supplies (as applicable) before servicing
• Refer to your model's parts diagram to locate and orient
• Transfer or reuse original fasteners and seals if in good condition
• Hand-start screws and tighten evenly; verify alignment and smooth operation after installation

This burner cap is a genuine OEM replacement part sourced directly from the manufacturer intended for use on gas stoves. This burner cap is for the B burner on the stove. The burner cap sits over the burner head to dissipate the heat and protect the burner head from food spills. If the burner cap is damaged due to food spills or becomes lost, it should be replaced before the burner is used. It is difficult to cook evenly if the burner cap is missing. The flame from the burner head is not evenly dispersed and is more intense. If the burner cap is damaged or missing, it should be replaced immediately.Tools are not required to replace the burner cap. Make sure the stove is not hot and has not been used recently before making the repair. To start, disconnect the gas and power from the stove. Remove the burner grate from the stove. Lift the burner cap and remove it from the burner head. Place the new cap over the burner head and align it. Set the cap on the burner head and return the burner grates to their places. Restore the power and gas to the stove.This burner cap for the B burners is made of heavy-duty metal. It is individually sold and made for gas stoves manufactured by Thermador and Bosch.

This is a genuine OEM replacement burner cap part sourced directly from the manufacturer intended for use on gas stoves. This burner cap is made for the C burner. Burner caps cover the burner head where the flame comes out to cook the food. The burner cap spreads the flame out rather than allowing it to shoot straight up. This helps to cook the food evenly by heating the pans on the burner grate around the bottom rather than just the middle. The burner cap also helps protect the burner head from spills that occur when food boils over. Food spills could clog the gas burner and cause more extensive damage to the stovetop.The stove should be cool enough to touch before the burner cap is replaced. Unplug its power source and turn the gas off to the stove. Remove the burner grate and burner cap from the stove. Place the new burner cap over the burner head and replace the burner grate. Reconnect its power source and turn the gas back on.This burner cap for C burners is made of heavy-duty metal. It is individually sold and made for gas stoves manufactured by Thermador and Bosch.

The Venturi Gas Tube is an OEM replacement part for Bosch gas cooktop ranges. Its primary function is to ensure an optimal gas/air mixture for consistent and efficient burner combustion, thereby enhancing the overall performance of the cooktop.

Causes involve normal wear of internal components from continuous heating and cooling cycles. Corrosion damage may also disrupt the venturi tube over time.

Symptoms of a faulty venturi gas tube include:

• Unstable or hard-to-control flame levels
• Potential issues shifting burner flames out of their intended position
• Safety risks including carbon monoxide from improper fuel/air balance

This OEM Bosch part is also compatible with Thermador, Gaggenau and some Kenmore models.

This ignition device generates the high-voltage spark that lights gas burners so your cooktop or range ignites reliably. Replace a failing module to stop repeated clicking and restore consistent ignition. What it does:

• Produces spark pulses for gas burners and oven ignition.
• Stops continuous clicking when the burner won't light.
• Fixes intermittent ignition or no-spark symptoms at the burner.
• Helps prevent prolonged gas flow when ignition fails.

• Turn off electrical power and shut off the gas supply before beginning any service.
• Handle the module and wiring harness carefully.
• Avoid wetting the module or direct contact with high-voltage terminals; use basic hand tools and follow factory service instructions.
• After installation, test operation and check for proper ignition; if you smell gas or ignition still fails, stop.

This replacement plate restores the proper mounting/cover surface specified in your appliance's assembly, helping keep components aligned, protected, and secure for reliable operation. Ideal for replacing a bent, cracked, or missing original.

• Serves as the specified support/cover plate within the assembly
• Maintains alignment and a secure fit for adjacent parts
• Replace when the original is bent, cracked, worn, or missing
• Symptoms can include rattling, misalignment, loose components, or visible damage in the plate area

• Disconnect power and shut off gas/water supplies (as applicable) before servicing
• Refer to your model's parts diagram to locate and orient
• Transfer or reuse original fasteners and seals if in good condition
• Hand-start screws and tighten evenly; verify alignment and smooth operation after installation

This is a genuine OEM replacement burner cap part sourced directly from the manufacturer intended for use on gas stoves. This burner cap is made for the C burner. Burner caps cover the burner head where the flame comes out to cook the food. The burner cap spreads the flame out rather than allowing it to shoot straight up. This helps to cook the food evenly by heating the pans on the burner grate around the bottom rather than just the middle. The burner cap also helps protect the burner head from spills that occur when food boils over. Food spills could clog the gas burner and cause more extensive damage to the stovetop.The stove should be cool enough to touch before the burner cap is replaced. Unplug its power source and turn the gas off to the stove. Remove the burner grate and burner cap from the stove. Place the new burner cap over the burner head and replace the burner grate. Reconnect its power source and turn the gas back on.This burner cap for C burners is made of heavy-duty metal. It is individually sold and made for gas stoves manufactured by Thermador and Bosch.

This burner cap is a genuine OEM replacement part sourced directly from the manufacturer intended for use on gas stoves. This burner cap is for the B burner on the stove. The burner cap sits over the burner head to dissipate the heat and protect the burner head from food spills. If the burner cap is damaged due to food spills or becomes lost, it should be replaced before the burner is used. It is difficult to cook evenly if the burner cap is missing. The flame from the burner head is not evenly dispersed and is more intense. If the burner cap is damaged or missing, it should be replaced immediately.Tools are not required to replace the burner cap. Make sure the stove is not hot and has not been used recently before making the repair. To start, disconnect the gas and power from the stove. Remove the burner grate from the stove. Lift the burner cap and remove it from the burner head. Place the new cap over the burner head and align it. Set the cap on the burner head and return the burner grates to their places. Restore the power and gas to the stove.This burner cap for the B burners is made of heavy-duty metal. It is individually sold and made for gas stoves manufactured by Thermador and Bosch.

The Regulator is an OEM part for Bosch ranges. This regulator controls gas flow to the burners, ensuring they receive the proper amount of fuel to achieve the desired cooking heat levels.

Causes of a bad regulator include cracks, jets becoming clogged over time, or damaged thermostatic components that improperly sense temperature.

Symptoms of a bad regulator include:

• Burners that will not ignite or light unevenly
• Inability to adjust burner flames precisely
• Burners that become too hot or too cool unexpectedly
• Yellow burner flames instead of blue

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This blue spark electrode wire connects the oven/range spark electrode to the ignition module so burners or the oven spark reliably. Replacing a damaged or frayed wire restores proper ignition and reduces intermittent or no-spark problems. What it does

• Carries the high-voltage spark from the ignition module to the electrode so the gas ignites.
• Commonly fixes symptoms like burners or oven not sparking, intermittent ignition, or visible wire damage.
• Helps prevent arcing and erratic ignition when the original wire is cracked, burnt, or corroded.
• Matches the OEM shape/color for proper routing and fit in compatible models.

• One blue spark electrode wire (single wire as shown)

• Disconnect power and shut off gas supply before starting any work; follow all safety precautions.
• Handle porcelain/ceramic electrode tips and insulation carefully to avoid damage.
• Route the wire along the original path and secure any retainers; avoid contact with hot surfaces.

This spark electrode wire routes the ignition spark from the igniter/ignition module to the burner electrode so gas ovens and ranges can light reliably. It replaces a worn or damaged ignition lead to restore proper spark delivery. What it does:

• Carries the high-voltage spark from the ignition module to the burner electrode
• Enables ignition of the gas by delivering a consistent spark at the burner
• Common symptom repair: no ignition or intermittent sparking at a burner
• Can also address continuous clicking or weak spark issues when the lead is damaged

• One spark electrode wire (yellow)

• Turn off electrical power and shut off the gas supply before starting work
• Handle ceramic electrode and wire ends carefully to avoid cracking or contamination
• Ensure connections are secure and wire routing avoids contact with hot surfaces or sharp edges

This spark electrode wire routes ignition spark from the module to the oven/burner electrode so the appliance lights reliably. Durable insulated lead designed to restore consistent sparking and improve ignition performance. What it does:

• Conducts high-voltage spark from the ignition module to the electrode to ignite gas burners.
• Commonly replaces cracked, frayed, or heat-damaged ignition leads.
• Can resolve intermittent or no-spark ignition and burners that fail to light.
• Fits applications needing a single insulated black electrode lead.

• One black spark electrode wire as shown.

• Disconnect power and turn off the gas supply before starting any service.
• Handle the ceramic/insulator and electrode tip carefully; avoid bending or cracking.
• Ensure secure, clean connections at both ends; do not splice unless specified by manufacturer.

The Knob is an OEM part for Bosch ovens and ranges, designed to offer precise control over the cooking settings. This knob allows users to set the temperature and cooking mode, ensuring a seamless cooking experience. Crafted with durability and usability in mind, it fits comfortably in the hand, offering a smooth rotation for adjusting settings.

Causes for a Knob to require replacement can include physical damage from accidental knocks, degradation of materials over time, or the effects of heat and cleaning chemicals that can wear down the text and symbols.

Symptoms of a bad Knob include:

• Difficulty in turning the knob
• Faded or worn indicators, making it hard to select the correct settings.
• The knob coming loose or falling off

This OEM Bosch part can also be used on Thermador and Gaggenau appliances.

The Knob is an OEM part for Bosch ranges. This part allows users to control the heat settings of the burners, providing precise adjustments for cooking.

Causes of a bad knob can include cracking, breaking, or the internal mechanisms wearing out, preventing it from properly engaging with the control shaft.

Symptoms of a bad knob include:

• Difficulty turning the knob
• The knob not staying in place or feeling loose
• Inability to adjust the burner settings accurately
• The knob falling off or not engaging with the control shaft

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

The Knob is an OEM part for Bosch ranges. This part allows users to control the heat settings of the burners, providing precise adjustments for cooking.

Causes of a bad knob can include cracking, breaking, or the internal mechanisms wearing out, preventing it from properly engaging with the control shaft.

Symptoms of a bad knob include:

• Difficulty turning the knob
• The knob not staying in place or feeling loose
• Inability to adjust the burner settings accurately
• The knob falling off or not engaging with the control shaft

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This R/I box is the refrigerator control/interface module that routes power and signals between the main control and components. Replacing a faulty unit restores proper electrical communication and helps resolve intermittent or failed functions. What it does:

• Acts as an electrical interface between controls and components, routing signals and power.
• Can cause loss of specific functions (ice maker, dispenser, lights) when failing.
• May produce intermittent operation, no-response to controls, or communication errors.
• Used when diagnostics show the interface module is faulty or damaged.

• One R/I box (control/interface module)

• Disconnect power before servicing to avoid shock or damage.
• Ensure connectors are fully seated and wiring is routed as originally installed.
• Inspect mounting and surrounding components for damage; replace if needed.

This rough-in box provides the recessed connection point needed to route electrical and service lines for a built-in dishwasher, keeping connections protected and out of sight for a clean installation. What it does:

• Provides a recessed enclosure to house dishwasher electrical and connection points
• Keeps wiring and junctions protected from moisture and accidental disturbance
• Organizes service access for power and service lines behind the appliance
• Helps maintain a flush, professional finish between the appliance and cabinetry

• Mount in the cabinet opening per manufacturer instructions so the appliance can recess properly
• Turn off power at the breaker before making any electrical connections
• Use approved connectors and strain reliefs;

This replacement tubing connects the water inlet valve to the solenoid, directing water flow where the appliance needs it. Replaces worn or cracked hose to restore proper water routing and reduce leaks. What it does:

• Carries water from the inlet valve to the solenoid assembly
• Prevents leaks and maintains correct water flow when intact
• Commonly replaced if cracked, split, or hardened with age
• Helps resolve intermittent filling or leakage symptoms related to damaged tubing

• Inspect adjacent fittings and clamps; replace any damaged fasteners to ensure a proper seal
• Turn off water supply and unplug the appliance before attempting replacement
• Slide hose fully onto barbed fittings and secure with the correct clamp type; test for leaks after reassembly

This gas top burner tube is used on many Thermador models begining with SGS.

Kit incldes 3 grates: left, center and right.

Kit incldes 3 grates: left, center and right.

Kit incldes 3 grates: left, center and right.

Kit incldes 3 grates: left, center and right.

Kit incldes 3 grates: left, center and right.

Kit incldes 3 grates: left, center and right.

Kit incldes 3 grates: left, center and right.

Kit incldes 3 grates: left, center and right.

Kit incldes 3 grates: left, center and right.
