Parts for Thermador SMW272YS AFTER S/N 8204: 02 - Top Plenum Control Parts

Fix a range that won't heat or has no power with a new terminal block. This socket connects power supply wiring to your electric range heating elements.

Fix a loud humming or buzzing noise from your wall oven control panel. This low-voltage transformer powers the control board and related circuits.

If your wall oven won't power on or trips the breaker, a faulty terminal block may be the cause. This electrical socket connects power to your oven.

Wall oven won't heat or stops heating mid-cycle? A faulty thermal fuse is often the cause. This safety component prevents overheating damage.

Single oven. Includes display board, relay board, wire harness and instructions. For the double oven display kit order 00702451.

Single oven. Includes display board, relay board, wire harness and instructions. For the double oven display kit order 00702451.

White touch control glass panel for ovens and ranges. Replaces cracked, broken, or scratched control overlay. Includes filter for display clarity.

Replacement tension spring for ovens and ranges. Restores proper tension to mechanisms when the original spring becomes worn, stretched, or broken.

This wiring harness connects the oven door latch and self-clean lock mechanism to the oven's control system, restoring electrical connection for the door locking function during self-clean cycles. Use when the door lock won't engage or the lock switch has no power. What it does:

• Routes electrical signals between the oven control and the door latch/lock assembly
• Enables the door to receive lock/unlock commands during self-clean cycles
• Commonly replaced when the door won't lock, the lock motor doesn't respond, or self-clean won't start
• Helps clear failures caused by broken, burned, or disconnected latch wiring

• One oven door latch/self-clean wiring harness

• Disconnect power to the appliance before beginning any repair
• Access may require removing the oven door or inner panels; follow OEM disassembly steps
• Match connector shapes and wire routing; secure harness to prevent pinching or heat exposure
• Test door locking operation and self-clean function after installation

Display signal wire harness for ovens and ranges. Connects control board to display panel. Replace if wires are damaged, connectors broken, or harness is worn.

Replace your oven's keypad wire harness if the wiring is frayed, damaged, or connections are loose. Ensures reliable electrical connection between control board and keypad assembly.
