Parts for Thermador SGS30S: 05 - Sgscv36g Burner Box Parts

Heat shield for cooktop side panel. Protects surrounding components from heat damage. Replace if cracked, warped, or missing to maintain proper insulation.

This secondary griddle drip pan catches grease and food drippings under the griddle surface to keep the cooktop area cleaner and reduce smoke during cooking. It's a direct-replacement service part for compatible Bosch gas griddles. What it does:

• Collects grease and food particles that fall from the griddle while cooking
• Helps prevent grease buildup on burner components and the oven floor
• Reduces smoke and flare-up risk by channeling drips away from burners
• Makes cleanup easier by containing mess in a removable pan

• One secondary griddle drip pan

• Turn off gas and allow all surfaces to cool completely before servicing
• Remove grates and any top covers per your model's service instructions to access the pan
• Slide the replacement pan into the same position, ensuring it seats correctly and drains as designed
• Inspect for damage and clean surrounding areas before reassembly

Replace your cooktop's burner bracket if it's cracked, broken, or missing. This structural part secures the burner assembly in place on your cooktop.

Replacement burner bracket for gas cooktops. Secures and supports the burner assembly. Needed when original is bent, broken, or corroded affecting fit.

This umbrella-style seal fits around the dishwasher pump shaft to help prevent water from leaking between the pump and the tub. It keeps the pump assembly sealed so your dishwasher can drain and run without unwanted leaks. What it does:

• Forms a flexible watertight barrier around the pump shaft to reduce leaks at the pump/tub interface
• Helps maintain proper drainage by keeping pump openings sealed
• Commonly replaced when you find water pooling under the dishwasher or active leaks near the pump area
• Designed to resist dishwasher detergents and typical wash temperatures

• Disconnect power and shut off water before starting any repair.
• Access typically requires removing the dishwasher toe kick and possibly the pump assembly; follow the service manual for your model.
• Inspect the pump housing and surrounding seals/fasteners; replace any damaged components to restore a reliable seal.

Replacement mounting screw for ranges and cooktops. Secures components and panels. Order a new screw if yours is stripped, missing, or damaged.

Burner won't light or has no gas flow? This top burner valve controls gas to individual burners. Moderate DIY repair with basic tools needed.

Brass nut secures the jet holder assembly on gas ranges and cooktops. Replace if stripped, corroded, or damaged during burner maintenance or repair.

Fixes burners that won't ignite or spark continuously. This spark module generates the high-voltage needed for gas ignition. DIY repair, 1-2 hours.
