Parts for Kitchenaid KMHP519ESS2: Air Flow Parts

This lamp cover is the replacement lens that protects and diffuses your oven's interior light, restoring even illumination while keeping the bulb shielded from heat and food residue. It helps maintain safe, usable oven lighting. What it does:

• Protects the oven light bulb from splashes, crumbs and direct contact.
• Diffuses the bulb for more even interior illumination.
• Replaces a cracked, cloudy, melted or missing lens that can cause dim or exposed lighting.
• Fits over the lamp housing to restore the oven's normal light appearance and function.

• Disconnect power to the appliance before starting and allow the oven to cool completely.
• Handle the cover carefully—wear gloves to protect from sharp edges or broken glass.
• Remove any retaining screws or clips, swap the old cover for the new one, then secure the retainer.
• After installation, restore power and replace the bulb if issues persist.

This oven temperature sensor senses cooking cavity heat and sends accurate temperature readings to the range control so your oven can reach and maintain set cooking temperatures. Replaces a failed or intermittent sensor for consistent performance. What it does:

• Detects oven cavity temperature and relays readings to the controller
• Helps the oven maintain set temperatures for proper cooking and baking
• Common fix when oven won't heat correctly or displays inaccurate temps

• One oven temperature sensor (W10557536)

• Disconnect power to the appliance before servicing to avoid shock
• Handle the sensor and connector carefully; avoid bending or crimping the probe
• Verify connector type and routing match your model before final assembly

The Light Bulb is an OEM part for Whirlpool microwaves. It provides illumination within the microwave cavity, enhancing visibility so you can monitor your cooking without opening the door. This feature is essential for convenience and to ensure proper cooking, as it helps to prevent heat loss and maintain the microwave’s energy efficiency.

Symptoms of a bad Light Bulb include:

• The microwave interior remaining dark despite the appliance being in use.
• Flickering or inconsistent lighting when the microwave is operating.
• The bulb not turning on, indicating it may be burnt out or there is a connection issue.

Causes of a bad light bulb can include filament wear out due to prolonged use, damage from moisture or grease exposure inside the microwave, or electrical surges that can shorten the bulb's lifespan.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models, ensuring it fits a wide range of microwave models.

This air deflector redirects airflow inside the appliance to help maintain proper circulation and temperature control. It's a simple replacement that restores intended airflow routing and helps improve performance. What it does:

• Guides internal airflow to prevent hot or cold spots and ensure even temperature distribution
• Helps reduce airflow-related noise from misdirected air paths
• Can improve heating/cooling efficiency when the original deflector is cracked or missing
• Common symptom: uneven drying/heating, reduced performance, or noisy airflow

• One air deflector

• Disconnect power (and gas if applicable) before starting any repair
• Inspect mounting tabs or screw holes on the old and new part for secure alignment
• This part typically snaps or screws into place; handle carefully to avoid damaging mounting features

The Motor-Fan is an OEM part for Whirlpool ranges. This motor works with the lower convection fan to circulate heat underneath and throughout the oven cavity during the baking and broiling functions.

Causes of a bad motor can include normal wear over several years of continuous usage. Issues may also stem from dust or grease buildup inhibiting free fan rotation.

Symptoms of a bad motor-fan include:

• The lower convection fan not spinning or circulating air
• Improper or uneven cooking temperatures inside the oven
• Slower cook times compared to when new
• Possible smoke or burning of foods from poor air flow

This essential Whirlpool replacement is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore oven models.

This Charcoal Filter is an OEM replacement part for Whirlpool microwaves. The charcoal filter is responsible for improving the air quality in the kitchen by removing impurities and odors from the air. It is used to remove smoke, grease, and cooking odors as it is drawn up through the vent fan. By trapping these particles, the filter helps maintain cleaner air in the kitchen and prevents odors from recirculating and affecting the taste and smell of your food.

Causes of a bad Charcoal Filter include saturation from absorbing smoke and odors over time, accumulation of grease and particles that clog the filter, leading to decreased effectiveness, and physical damage that compromises its ability to filter air properly.

Symptoms of a bad Charcoal Filter include:

• Persistent odors in the kitchen after cooking.
• Smoke not being effectively vented out during microwave use.
• Reduced airflow from the microwave's venting system.

Replacing the charcoal filter at regular intervals or when these symptoms are noticed ensures that your microwave continues to operate efficiently and keeps your kitchen air clean. This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Description- Color: metallic. Measures about 5 inches wide by 5 inches deep.

The Fixed thermostat is an OEM component specifically designed for Whirlpool microwaves. This part plays an important role in regulating the internal cavity temperature during the cooking cycle.

Symptoms of a bad Thermost-Fix include:

• Food not heating evenly or completely
• Portions of food becoming overcooked while others remain cold
• Inconsistent or improper cooking at set power levels

Causes of a bad Thermost-Fix can include failure or damage of internal thermostatic components or sensors, electrical issues preventing proper communication, or obstructions interfering with temperature monitoring.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This magnetron is the high-voltage microwave tube that creates the microwaves used to heat food. Replacing a failed magnetron restores heating so your microwave can cook and warm food properly. What it does

• Converts high-voltage electrical energy into microwave energy to heat food.
• Commonly fails when the oven runs but doesn't heat.
• May cause symptoms such as no heat, intermittent heating, loud humming or buzzing, or electrical arcing/sparking.
• Works with the high-voltage circuit (magnetron, transformer, capacitor and diode) to deliver power to the cooking cavity.

• One magnetron

• High-voltage components store lethal charge—always unplug the appliance and discharge the HV capacitor before servicing.
• Handle the magnetron carefully; avoid touching the ceramic antenna and mounting surfaces.
• Verify the part number and oven wiring before installation; replace associated HV parts (capacitor/diode) if damaged.

This is a thermal safety fuse that opens the circuit if temperatures rise beyond a safe limit, protecting the appliance from overheating and preventing further damage. Replacing a failed fuse restores power to the affected circuit once the underlying cause is addressed.

• Monitors temperature in a protected circuit and cuts power if unsafe heat is detected
• Helps prevent overheating-related damage
• Typical failure signs: no power/no operation, cycle won't start, shuts off mid-cycle after overheating event
• Must not be bypassed; replace if open and investigate the root cause of overheating

• Unplug appliance or disconnect power before service
• Verify the fuse is open with a multimeter; replace only after correcting any airflow/overheating issues
• Install in the same orientation and location as the original to ensure proper temperature sensing
• Handle wiring carefully; transfer connectors one at a time to avoid miswiring
