Parts for Kitchenaid KCGD500GSS00: 04 - Burner Box Parts

This replacement drip tray catches and channels excess water beneath the appliance to help prevent puddles and floor damage. It restores the original drain path so condensate and minor leaks drain safely away. What it does:

• Collects and directs water away from the appliance base to prevent pooling on the floor
• Helps contain leaks from defrost or drain systems to limit damage to surrounding areas
• Can reduce musty odors and water stains caused by trapped moisture
• Fits into the appliance base to restore original water collection and drainage

• One drip tray

• Disconnect power to the appliance before servicing
• Remove lower access panels or kickplate as needed to access the tray
• Align the tray with the chassis rails or mounting tabs and slide or snap into place
• Inspect surrounding seals and drain paths; if you find corrosion or other damage, replace those parts as needed.

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This spark module controls ignition for four surface burners and provides automatic reignition if a flame goes out. It generates the high-voltage spark and monitors flame for dependable lighting and consistent cooktop performance.

• Generates high-voltage pulses to ignite up to four surface burners
• Senses flame presence and automatically re-sparks if a flame is lost
• Helps stop sparking once flame is detected to reduce clicking
• Symptoms this part is involved with include: no spark on any burner, intermittent or weak spark, or continuous clicking after lighting

• Disconnect power and shut off gas before servicing
• Access is typically under the cooktop or behind a panel; mount the module securely away from heat and moisture
• Transfer wires one at a time to matching terminals; ensure ground/neutral connections are secure for proper flame sensing
• After reassembly, restore power and test each burner for ignition and that clicking stops when flame is present

This manifold routes gas from the supply to the oven or range burner ports so burners light and heat consistently. Replacing a worn or damaged manifold restores reliable gas flow for normal cooking performance. What it does:

• Distributes incoming gas to the oven/range burner ports for even ignition and heat
• Ensures proper gas flow to each burner; prevents weak or uneven flames
• Can cause burners that won't light or that produce irregular flames when damaged
• Works with associated valves and igniters to maintain safe operation

• Turn off gas supply and disconnect power before service; follow local codes
• Inspect related valve and igniter components while replacing the manifold
• Use proper seals and torque on fittings; check for leaks with a soapy water solution after installation

This burner valve controls gas flow to a single surface burner, restoring safe, adjustable flame control for gas ranges. It replaces a worn or faulty valve to help burners light and maintain the correct flame level. What it does:

• Regulates gas flow to a single surface burner so you can adjust flame height
• Restores reliable ignition and helps burners light and hold a steady flame
• Replaces valves that leak, stick, or fail to respond to the control knob
• Commonly used when burner flame is too high, too low, or will not stay lit

• Disconnect power and turn off gas supply before beginning service.
• Inspect fittings and gaskets for damage; replace any worn parts and test for leaks after installation.
• Follow OEM service instructions and local codes when reassembling and relighting the appliance.

This burner valve is a direct-replacement gas control valve that regulates fuel flow to a single cooktop burner, restoring proper ignition and flame control for safe, consistent cooking performance. What it does:

• Controls gas flow to one burner so the burner ignites and adjusts flame size
• Replaces a failed or leaking valve that can cause no gas flow or inability to light
• Helps stop unwanted gas flow when the control knob is off
• Restores normal knob-to-flame response for accurate heat control

• Turn off gas supply and unplug the appliance before servicing.
• Access may require removing the cooktop or control panel; follow OEM disassembly steps.
• After installation, check all connections for leaks and test burner operation with proper ventilation.

This gas pressure regulator controls and stabilizes incoming fuel supply to the appliance's burner system, helping ensure consistent flames and reliable operation. Replace it if pressure is unstable or burners/oven won't heat or ignite correctly. What it does:

• Reduces household gas supply to the appliance-rated pressure for proper burner performance
• Maintains steady pressure as burner demand changes to prevent over/under-firing
• Helps prevent yellow, lifting, or flickering flames and sooting caused by pressure issues

• 1 gas pressure regulator

• Shut off gas supply and disconnect power before servicing
• Observe flow-direction arrow on the regulator body; install between supply and appliance manifold
• Use approved gas-rated thread sealant on threaded connections; do not overtighten
• After installation, check all joints for leaks with a non-corrosive leak-detection solution; correct any leaks before use

This switch seal is a replacement gasket that helps keep moisture and debris away from the appliance's door/control switch, protecting the switch assembly and helping restore reliable door detection and operation. What it does:

• Seals the area around the door/control switch to block water, lint, and grime.
• Helps prevent intermittent trips or failures caused by moisture or foreign material contacting the switch.
• Promotes consistent switch actuation and can extend the service life of the switch assembly.
• Useful when the existing seal is cracked, torn, flattened, or missing.

• Disconnect power before servicing to avoid electrical shock.
• Access typically requires removing the door trim or control panel—follow your model's service instructions.
• Inspect the switch and surrounding area for damage or corrosion and clean before installing the new seal.

This switch assembly harness connects the oven's gas valve to the control and safety switches, restoring proper signal and gas valve operation. It's a direct-replacement harness used on compatible Whirlpool gas ranges to fix ignition and valve control issues. What it does:

• Routes electrical signals between the gas valve and oven control/safety switches
• Enables the gas valve to open when the control calls for heat
• Helps resolve problems like no ignition, oven not heating, or intermittent valve response
• Matches OEM connector and wire grouping for a plug-and-play replacement when compatible

• One switch assembly harness

• Disconnect power and shut off the gas supply before beginning work
• Avoid bending or pinching wires; secure harness per original routing

This is a direct-replacement screw used to secure appliance panels, brackets and other small components. It restores proper fastening where the original screw is missing, stripped, or corroded to help reduce rattles and looseness. What it does

• Fastens panels, trim, brackets and similar small appliance parts
• Restores a secure connection when the original fastener is missing or damaged
• Helps stop vibration-related rattling and movement of mounted components
• Matches the original mounting point to maintain proper alignment

• Disconnect power and water before beginning any repair
• Use the correct screwdriver or bit to avoid stripping the head
• Thread carefully and do not overtighten to prevent damage to the mating part
• Replace only with the same part number or equivalent for proper fit
