Parts for Kitchenaid KRSC503EBS01: Cabinet Parts

The FreshFlow Refrigerator Air Filter is an OEM component for Whirlpool and Maytag refrigerators. Located inside the ventilation system, this filter purifies circulated air. This air filter is 3" wide by 2" high and white in color. It should be replaced every 6 months to ensure the best performance.

Causes of failure relate to clogging from trapped dust, dander and other allergens despite regular replacement intervals. Performance decreases as filter media becomes saturated over months of use.

Symptoms of a dirty or blocked refrigerator air filter include:

• Reduced airflow causes higher compressor runtime hours
• Odors being pulled into the fridge from unfiltered vents
• Shortening of food storage life due to unpurified air exposure
• Reduced fan speeds or strange noises originating from the vents

This genuine Whirlpool filter is also compatible with Maytag, Jenn-Air, and Amana models as well.

The Whirlpool EveryDrop Ice and Refrigerator Water Filter 1 is an OEM replacement part for Whirlpool refrigerators. This filter works to remove small particles from water to ensure clean, great-tasting ice and drinking water directly from the refrigerator door.  Measuring approximately 2.50 x 2.50 x 8.69 inches, this filter is easy to install.

For optimal performance, we recommend replacing the filter every six months. The filter material is made from coconut carbon block, which has a micron rating of 0.5 and a flow rate of 0.5 gpm. The filter is designed to operate at a maximum pressure of 125 psi and an operating temperature of 38-100°.

Symptoms of a filter needing replacement include:

• Gradual decline in water/ice quality over time exhibiting muddy appearance or odd tastes
• Filter life indicator appears showing it is time for a new one

Causes stem from normal usage over the stated capacity of the original filter. Allowing one to expire could produce unhealthy water.

This OEM replacement part is compatible with select Maytag, Jenn-Air, and Amana models as well.

The Roller is an OEM part for Whirlpool refrigerators. It is designed to facilitate the smooth movement of your refrigerator, making it easier to position and clean underneath the appliance. The roller supports the weight of the refrigerator and allows for easy adjustments in placement.

Causes of a bad fridge roller can include wear and tear from frequent movement, exposure to heavy loads that can damage the roller, or accumulation of dirt and debris that can impede its function. When a roller is damaged, it can affect the stability and mobility of the refrigerator.

Symptoms of a bad Roller include:

• Difficulty moving the refrigerator
• Unusual noises when the refrigerator is moved
• Uneven leveling of the refrigerator
• The refrigerator not staying in place

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This 1/4-20 screw is a direct replacement fastener used to secure appliance panels, brackets, and assemblies. It restores proper fit and prevents rattling or loose components for safe, reliable operation. What it does:

• Fastens panels, mounting brackets, and components in place
• Replaces missing or stripped screws that cause loose or rattling parts
• Maintains alignment of assemblies to prevent wear and vibration
• Works wherever a 1/4-20 machine screw is specified by the manufacturer

• Disconnect power and follow the appliance manufacturer's safety instructions before servicing
• Use the correct-size driver or socket to avoid stripping the head
• Do not overtighten; snug until secure to avoid damaging threads or components
• If the original screw was rusted or seized, apply penetrating lubricant and use proper extraction tools

This rear roller is a replacement for the rollers in a refrigerator. The rollers are not used often, but they have an important purpose. They make it easier to move the refrigerator from one area to another. If the roller had been damaged and is not working properly, it will be difficult to maneuver the refrigerator. Replacing the damaged roller with a new one before moving the refrigerator a long distance is a good idea.The rollers on the refrigerator are meant to handle a lot of pressure. However, they can still wear down and break eventually. They could also be damaged during a previous move. Before replacing the rear roller, unplug the refrigerator and remove the connection to the water supply. The replacement will require only a few tools, such as a screwdriver. It may require moving other parts of the refrigerator to get access to the rear rollers.The rear roller will work for certain models of refrigerators from Whirlpool, GE, KitchenAid, Inglis, Maytag, Admiral, International, Amana, Jenn-Air, Crosley, and Magic Chef. This is a genuine OEM replacement part that is sold individually.

This axle roller is the replacement support shaft that lets the appliance's rotating assembly turn smoothly and quietly. Installing a new axle roller corrects wobble and reduces grinding or squealing caused by a worn shaft. What it does:

• Supports the rotating drum or rack so it spins freely and stays aligned
• Helps prevent metal-to-metal contact that causes loud noise or scraping
• Stops uneven rotation and vibration that can lead to further wear
• Restores smooth operation when an original axle is bent, worn, or broken

• Disconnect power (and gas, if applicable) before starting any repair
• Access location and removal steps vary by model; follow the OEM service manual or diagram
• Inspect related parts (pulleys, idler, glides, bearings) and replace if they show wear
• Use basic hand tools; keep fingers and loose clothing clear of moving parts during testing

This steel rivet secures appliance panels and small components, restoring proper fit and preventing rattles or loose parts. It's a straightforward replacement when a worn or missing rivet causes instability. What it does

• Fastens sheet metal or trim pieces to the cabinet or internal brackets
• Restores secure mounting when a previous rivet has sheared or fallen out
• Stops panel vibration or rattling caused by a loose fastener
• Provides a permanent, non-threaded mechanical connection for components

• Replacement typically requires a rivet tool or rivet setter; drill-out may be needed to remove a broken rivet
• Match rivet type and length to the original for a secure fit
• Disconnect power and follow all safety precautions before accessing internal parts

Replacement bracket that secures and supports internal components, restoring firm mounting and reducing rattling. Replaces a worn or damaged bracket to help keep appliance parts aligned for quieter, more reliable operation. What it does:

• Provides a stable mounting point to hold internal components in place
• Reduces rattling, vibration, and misalignment caused by a loose or damaged bracket
• Restores proper component spacing to help prevent contact and wear
• Works as a direct replacement for a failed bracket to return proper function

• Disconnect the appliance from power (and water, if applicable) before servicing
• Handle edges carefully; wear gloves to avoid cuts during removal/installation
• Reuse existing fasteners unless new hardware is specified; ensure bracket is securely tightened and component alignment is checked

The Leveling Leg is an OEM replacement part for Whirlpool refrigerators. It is one of four legs situated internally at the base corners for proper tilt positioning. It raises or lowers each leg independently to stabilize units on uneven kitchen floors.

Causes of replacement consist of wear from continual torque required during positioning processes. Thread damage or corrosion buildup attributable to floor locations over extended use necessitates periodic renewal as well.

Symptoms involve:

• Doors that fail to align or seal completely during open-close cycles
• Noisy imbalances traced to feet contacting floor surfaces
• Appliance rocking is unable to be remedied through existing leg corrections

This is a genuine Whirlpool OEM replacement this part is also compatible with Maytag, Jenn-Air, and some Kenmore models

This hinge screw secures the door hinge to the appliance cabinet or door. Replacing a missing or stripped screw restores a tight, aligned hinge connection for smooth opening and reliable sealing.

• Fastens the hinge to the frame or door to prevent looseness
• Helps maintain door alignment for smooth opening/closing
• Direct replacement for lost, rusted, or stripped hinge screws
• Common symptoms: loose hinge, door sagging, rubbing/binding, or poor sealing

• Disconnect power before service; if working on a refrigerator, also shut off the water supply
• Support the door before loosening or tightening hinge hardware
• Start threads by hand to avoid cross-threading; tighten securely without over-torquing

This OEM Replacement Part is a single water inlet valve designed for use in Whirlpool refrigerators. Its key function is to supply water to the refrigerator's ice maker and water dispenser. When energized, this valve releases water from the supply line into the ice mold. If the water valve develops a crack, it will need replacement. The valve accommodates two different sizes of tubing: the smaller inlet measures 1/4", and the larger inlet measures 5/16".

By maintaining the integrity of this component, users can ensure the proper functioning of the refrigerator's ice maker and water dispenser. Always consult your appliance manual for accurate installation and replacement guidelines. This part is compatible
with select brands including Whirlpool, KitchenAid, Kenmore, and Maytag.

Color: Black

Color: Grey

Color: Black

The Hinge-Door is an OEM part for Whirlpool refrigerators. The refrigerator door hinge is a crucial component that allows the door to properly open and close while securely holding it in place. These hinges are responsible for smooth and reliable door operation through thousands of openings and closings.

Causes of a bad hinge can include wear and tear from prolonged use, stress from overloading the door, or accidental impact damage.

Symptoms of a bad hinge include:

• The door not closing properly or staying fully shut
• Difficulty or resistance when opening/closing the door
• The door sagging or wobbling excessively
• Noise or grinding sounds coming from the hinge area

This OEM Whirlpool replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This is a replacement 8-18 threaded screw used to secure panels and components on compatible Whirlpool appliances. It restores proper fastening where a missing or damaged screw causes loose parts or vibration. What it does

• Fastens panels, brackets, and small assemblies to the appliance frame
• Replaces stripped, corroded, or missing screws that cause rattling or loose components
• Helps maintain proper alignment of panels and controls for safer operation
• Suitable where an 8-18 threaded machine screw is specified by the manufacturer

• One replacement screw

• Disconnect power to the appliance before service to prevent shock or injury
• Use the correct driver to avoid stripping the screw head; do not force mismatched tools
• Tighten until snug — avoid over-tightening which can strip threads or crack plastic
• If replacing multiple fasteners, check mating threads and replace any damaged clips or anchors as needed

Color: Black. For biscuit order 98008169. For white order WP98008544.

Color: Grey

The Door Hinge is an OEM part for Whirlpool refrigerators. It supports and allows the smooth opening and closing of the refrigerator door. It also maintains the door alignment and the door seal, preventing cold air from escaping and keeping your food fresh.

A bad door bottom hinge can occur due to wear and tear over time, accidental damage, or excessive weight on the door. If you notice symptoms such as a sagging or misaligned door, difficulty in opening or closing the door, or a loose or wobbly hinge, it may be time to replace this part.

Symptoms of a bad door bottom hinge include:

• Sagging or misaligned door
• Difficulty in opening or closing the door
• Loose or wobbly hinge

Restore your Whirlpool refrigerator door by replacing the faulty or damaged door bottom hinge with this genuine OEM part.

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.
Color: Grey

The Hinge Door is an OEM component specifically designed for Whirlpool refrigerators. It acts as the pivot point and support for the refrigerator door, controlling its movement on its hinges. The hinged door functions to securely hold the door in place while facilitating easy and reliable opening and closing.

Symptoms of a bad hinge door include:

• Loose or sagging refrigerator door that does not stay shut properly
• Difficulty smoothly opening and closing the door
• Excessive noise or vibration coming from the hinges
• Door alignment issues causing gaps around the door seal

Causes of a bad hinge door can include normal wear and tear over time, strain from heavy door usage, or damage from accidental impacts.

Color: Black

This OEM Whirlpool replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Cam Door Fridge is an OEM component specifically designed for Whirlpool refrigerators.  It works to operate and support the refrigerator door, controlling its opening and closing movements.  The cam door uses a precisely engineered cam mechanism to provide a smooth and balanced door function.

Causes of a bad cam door can include worn out or damaged parts from repeated opening and closing of the door. The cam mechanism may no longer operate properly if components are broken or out of alignment.

Symptoms of a bad cam door include:

• Difficulty opening or closing the refrigerator door
• The door not staying securely closed or properly sealed
• Excessive noise or vibration coming from the door area
• Door alignment issues causing gaps around the door seal

Color: Black

This OEM Whirlpool replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Color: Grey

Replacement screw that secures panels, brackets, and other components inside your appliance, keeping assemblies tight and aligned. Replace missing or stripped hardware to eliminate looseness, reduce vibration, and restore a solid, factory-fit hold.

• Fastens panels, brackets, trim, or internal components
• Helps maintain alignment and reduce rattling/vibration
• Replaces missing, loose, rusted, or stripped hardware
• Common signs: stripped head/threads, loose panel, buzzing/rattling noises

• Disconnect power before service; shut off gas/water if applicable
• Match to the original screw; start threading by hand to avoid cross-threading
• Use the correct driver size to prevent stripping
• Tighten snugly; do not overtighten. If it won't hold, inspect the receiving hole/clip

This is a high-quality refrigerator power supply board. It's an internal component that is made to control the refrigerator functions. This part is made with small precision parts to help with timing defrost and cooling cycles. This part can be damaged or malfunction and stop operating correctly. This may prevent the refrigerator from running, cause strange sounds, or cause the refrigerator to run at the wrong temperature.If this part is damaged, it will need to be replaced. Before replacing the power supply board, make sure the refrigerator is unplugged from the wall. The process will require a flathead screwdriver and a nut driver. Use the tools to unthread the screws on the access cover. Depress the retaining tab to remove the inner cover and disconnect the wires. Press the tab to release the power supply board and snap in the new component. Make sure the wires are properly connected and reassemble.This genuine OEM replacement part is sold on an individual basis. It is directly acquired from the manufacturer and is designed to be compatible with refrigerators made by Kenmore, Whirlpool, Maytag, and KitchenAid.

This black plastic corner cover replaces a damaged or missing exterior trim piece to restore the appliance's finished appearance and protect internal edges from dirt and wear. Fits the factory location and matches original styling. What it does:

• Covers and protects the appliance corner or trim area from chips, scuffs, and debris.
• Restores a clean, finished look where the original corner piece is cracked, broken, or missing.
• Helps keep moisture and grime from reaching internal seams at the corner.
• Matches the original color and shape to maintain the appliance's aesthetic.

• Install with the appliance powered off and unplugged for safety if cover removal exposes wiring.
• Remove any broken fragments and clean the mounting area before installing the new cover.
• May snap or screw into place depending on model; keep fasteners from the original cover for re-use.

This cover corner replaces a missing or damaged corner trim piece to restore the refrigerator's interior/exterior finish and help keep shelves and bins seated properly. It provides a clean, finished look and protects edges from wear. What it does:

• Replaces the corner trim/filler that covers panel edges or joins interior liners
• Helps keep adjoining panels, shelves or bins aligned and reduces gaps
• Restores appearance after chipping, cracks or impact damage

• Designed for drop-in or snap-on installation; verify fit against the appliance before final assembly
• Use basic hand tools; avoid excessive force which can crack plastic parts
• Disconnect power if removing interior panels or working near electrical components

This is the lower front grille for select appliances. It finishes the base opening and helps channel airflow to the condenser area while protecting components from bumps and debris.

• Covers the lower front opening and provides a clean, finished look
• Helps direct cooling airflow to the condenser compartment
• Shields components from minor impacts and debris
• Common signs it needs replacement: cracked or missing grille, broken mounting tabs, grille won't stay attached, rattling from a loose or damaged panel

• Disconnect power before servicing; use proper PPE
• Remove existing fasteners or release tabs, then pull the old grille straight off
• Align the new grille and secure with the original screws/clips as configured
• Do not overtighten fasteners; ensure even engagement of all tabs

This base grille covers the lower front of the refrigerator in a midnight gray finish. It directs airflow to the condenser and protects internal components—restoring proper ventilation and a clean, finished look when the original is damaged or missing.

• Covers the toe-kick area and helps channel cooling air through the condenser compartment
• Protects coils and lower components from bumps and debris
• Restores the unit's finished appearance
• Common symptoms include a cracked or missing grille, loose/rattling panel, or broken mounting tabs

• Disconnect power before servicing; use gloves to protect hands from sharp edges
• Open the doors; remove any retaining screws or release the grille's clips, then pull the old grille forward
• Align the new grille with the mounting points and snap or screw into place
• Ensure vents are unobstructed and the grille is secure before restoring power

The Screw is an OEM replacement part for Whirlpool appliances. The precise threads allow screws to join or assemble other parts securely.

Causes of a bad screw can include stripping, cracking, or loss of threads due to repeated installation/removal over time. Corrosion is also possible depending on environmental conditions.

Symptoms of a bad screw include:

• Loosened or detached components that were once fastened
• Reduced structural integrity of connections or assemblies
• Potential safety hazards if critical parts become dislodged

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This cam-door is a direct-fit replacement part that helps the appliance door operate smoothly and latch securely for proper use. Restores correct door movement and helps prevent gaps or misalignment that stop the door from closing. What it does

• Guides and supports the door latch mechanism so the door opens and closes correctly
• Helps the latch engage fully to maintain a tight, secure door seal
• Worn or broken cams can cause the door to hang, fail to latch, or make scraping/catching noises
• Replacing a damaged cam often restores normal door alignment and operation

• Disconnect power (unplug or turn off circuit breaker) before starting any repair
• Access may require removing the door or inner panel
• Inspect surrounding latch components and replace any damaged parts for reliable operation

This door closing cam mounts at the bottom of the refrigerator door and mates with the hinge cam to raise and lower the door as it swings, promoting smooth self-closing action and a reliable gasket seal.

• Provides lift-and-drop detent at the lower hinge to guide door movement
• Helps the door self-close in the final inches for a consistent seal
• Supports proper door alignment to reduce air leaks and temperature fluctuations
• Common symptoms: door won't self-close, pops/clicks at the hinge, sags or binds, poor seal or moisture around the door

• Disconnect power and remove items from the door to reduce weight
• Support the door; remove hinge cover and lower hinge/pin, then lift the door off carefully
• Replace the cam on the door/hinge as designed; inspect the mating cam and hinge pin and lightly lubricate
• Reinstall, level, and verify smooth closing and proper gasket contact

This is a replacement screw designed to work with a wide range of household appliances. It is used for many purposes in these appliances, from holding body panels together to securing electronics into control boards. However, screws are subject to damage through corrosion, impact, and improper installation/removal. In most cases, the primary damage to this screw is through corrosion – it may become rusted or corroded in place, depending on the appliance and the maintenance provided during its lifespan. The screw may also be stripped or rounded due to improper removal or installation. If the screw is damaged, lost, or corroded in place, it will need to be replaced. In most cases, removal will require nothing more than a Phillips head screwdriver or the appropriately sized socket with a ratchet. However, if the screw is damaged, it may require a tap set to remove it from its mounting location. Note that this is a genuine OEM replacement screw made from durable, high-quality metal, and is sold individually. It fits Whirlpool, Maytag, Roper, Estate, Amana, Crosley, and Thermador appliances. It is used in over 150 machines, ranging from washers and dryers to air conditioners.

This water inlet tube routes supply water from the inlet valve into the appliance's internal water path, restoring a secure flow path and helping prevent leaks, spray, or fill problems caused by cracked, brittle, or clogged tubing.

• Directs water from the inlet valve into the unit's water system/tub
• Replaces tubing that is cracked, kinked, brittle, or mineral-clogged
• Helps resolve leaks near the inlet connection or water dripping during/after fill
• Improves fill performance when the original tube is restricted or collapsing

• Disconnect power and shut off the water supply before servicing
• Place a towel or pan to catch residual water when lines are opened
• Note the tube's routing/orientation; transfer any fittings or clamps and avoid kinks
• Restore water and power, run a test fill, and inspect carefully for leaks

This water tube directs supply water where needed inside the appliance to restore reliable water flow and help prevent leaks. Use this replacement when the existing tube is cracked, split, or restricting water to the ice maker or dispenser. What it does:

• Routes water from the appliance supply line to internal components (ice maker, dispenser) for proper filling and operation.
• Replaces cracked, pinholed, or kinked tubing that can cause leaks or reduced water flow.
• Helps resolve intermittent or no-water symptoms at the dispenser or ice maker when caused by damaged tubing.
• Durable replacement to restore sealed connections and reduce drips at the tube fittings.

• Disconnect power and shut off the water supply before beginning any work.
• Drain residual water from lines and have towels/containers ready to catch spills.
• Ensure fittings and seals are seated properly; hand-start fasteners, then snug—do not overtighten.

The Main Control Board is an OEM component specifically designed for Whirlpool refrigerators. It is the central processing unit that monitors and controls all refrigerator functions.

The control board plays a vital role in operating cooling cycles, monitoring temperatures in individual compartments, and activating other components like fans, lights, ice makers, and dispensers. It allows for precise temperature regulation and customizable settings.

Symptoms of a bad control board include:

• Refrigerator not cooling properly or temperatures fluctuating
• Ice maker or water dispenser not functioning
• Fans running constantly or lights not turning on
• Error codes appearing on the internal display

Causes of a bad control board can include failure from water damage, power surges over time, or other impacts that disrupt electronic connections.

This OEM Whirlpool replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and some Kenmore models.

The cover-unit protects the appliance's control console and provides a finished appearance. It shields buttons, knobs and internal control components from dust, moisture and incidental damage so controls stay usable and the cabinet looks complete. What it does:

• Covers and protects the control console and the underlying control assembly
• Helps prevent debris and moisture from reaching buttons, switches and electronic components
• Restores the appliance's finished look when the original cover is cracked, broken or missing
• Keeps controls stable and reduces the chance of accidental contact or damage

• Disconnect power before servicing to avoid shock or injury
• Remove any trim or console fasteners before replacing the cover
• Handle carefully to avoid scratching the finish; use proper fasteners and align tabs during reassembly
• If controls or wiring are exposed or damaged, inspect wiring and control components.

This retainer clip secures the appliance axle in place to keep rotating parts aligned and running smoothly. Replacing a worn or broken clip helps reduce noise, vibration and drivetrain misalignment for reliable operation. What it does:

• Holds the axle/shaft in position to prevent lateral movement and maintain alignment
• Prevents excessive play that can cause noise, vibration or uneven wear
• Helps keep connected components (drum/rotor/wheel) tracking correctly
• Commonly replaced when clipped, bent or missing after repair or wear

• Disconnect power before starting any repair
• Removal may require pliers or a small punch to release the old clip; reinstall by snapping into the axle groove
• Inspect mating shaft and housing for wear or damage before installing the new clip

This replacement mounting ring secures small appliance components to maintain proper alignment and reliable operation. Use it when the original ring is worn, cracked, or missing to reduce play and restore normal function. What it does:

• Holds and centers components on a shaft or housing to prevent misalignment
• Replaces a worn or damaged ring that can cause excessive movement or noise
• Helps maintain stable operation of the assembly it secures
• Small, durable part used where a precision spacer or retainer is required

• Disconnect power and follow all safety procedures before starting repairs
• Inspect surrounding parts for wear; replace any damaged components to prevent repeat failure
• Use appropriate hand tools; do not force the ring into place

This water supply tube connects at the inlet water valve, routing water through your appliance's water system. Replacing a brittle, cracked, or kinked line helps restore reliable, leak-free operation and proper water flow. What it does:

• Carries water from the inlet valve to the designated component (such as dispenser, icemaker, or filter housing, depending on model)
• Helps maintain proper water pressure and uninterrupted flow
• Common symptoms include leaks at the back/bottom, slow or no water at the dispenser, or an icemaker not filling
• Addresses visible cracks, brittleness, or kinks in the existing tubing

• 1 water supply tube

• Disconnect power and shut off the household water supply; relieve line pressure by dispensing water
• Place a towel to catch residual water and note the original routing before removal
• For push-in/quick-connect fittings, insert fully and tug back to verify engagement; if using compression fittings, tighten snugly without overtightening
• Turn water on and check all connections for leaks before restoring power

The Water Inlet Valve is an OEM part for Whirlpool refrigerators. It regulates the flow of water into the refrigerator’s water dispenser and ice maker. This valve ensures that the correct amount of water is supplied to these components, enabling the production of ice and the dispensing of water on demand.

Over time, the water inlet valve can wear out due to mineral deposits, electrical malfunctions, or general wear and tear. These issues can lead to inadequate water flow, which can affect the performance of both the water dispenser and the ice maker, or cause leaks within the refrigerator.

Symptoms of a bad water inlet valve include:

• Water dispenser not working or having low flow
• Ice maker not producing ice
• Water leaks around the valve area

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.
