Parts for Whirlpool WRS311SDHT03: Dispenser Parts

This electronic control board manages the appliance's user interface and cycle functions, restoring reliable control of settings, timers, and electronic diagnostics. Replaces a failed main control to recover normal machine operation. What it does:

• Receives input from the control panel and tells the appliance when to start, stop, and run cycles
• Controls timers, relays, and electronic sensors for correct cycle sequencing
• Common symptom: appliance won't start or complete cycles, or cycles act erratically
• Common symptom: display is blank, shows error codes, or buttons are unresponsive

• Disconnect all power (unplug or switch off at the breaker) before starting
• Label wiring and take photos to ensure correct re-connection
• Handle the board by the edges and avoid static discharge; do not touch component leads
• Test operation before reassembling trim panels.

This genuine replacement fitting connects appliance water or fluid lines to internal plumbing, restoring a secure seal and proper flow. Use it to replace a worn or damaged connector and stop leaks or loose hose connections. What it does:

• Provides a sealed connection between a hose and the appliance plumbing
• Helps stop leaks from cracked, corroded, or loose fittings
• Restores reliable water or fluid flow through the supply line
• Fits where the original factory connector was used

• One replacement fitting as shown

• Turn off water and disconnect power to the appliance before starting
• Inspect and replace any worn O-rings or gaskets as needed
• Hand-start threads, then tighten to factory torque; avoid over-tightening

This replacement ice door is the inner dispenser door that covers the ice chute, helping keep ice contained and reducing warm air entry into the freezer. Fits models that use part W11678841. What it does:

• Covers the ice chute so crushed or cubed ice dispenses cleanly and stays inside the dispenser area
• Helps limit warm air and moisture from entering the freezer when the dispenser is not in use
• Prevents visible ice and debris from falling into the dispenser opening
• Resolves symptoms like a cracked or broken dispenser flap, ice falling out, or a door that won't close fully

• One ice door (inner dispenser door)

• Disconnect power to the appliance before beginning any repair
• Access typically requires removing the freezer door inner panel or dispenser bezel; keep screws and fasteners organized
• Handle plastic components carefully to avoid breaking tabs; test door movement before reassembling panels

This ice door is the interior flap that opens and closes the freezer dispenser chute to control ice release and help keep cold air inside. Replaces a cracked, warped or broken dispenser flap to restore normal ice dispensing and reduce drafts. What it does:

• Seals the ice chute when the dispenser is idle to help maintain freezer temperature
• Opens and closes with dispenser actuation to allow ice to pass through
• Prevents large debris from entering the ice chute and interfering with dispensing
• Commonly replaced when the door is cracked, stuck, or no longer sealing

• One ice door (single dispenser flap)

• Disconnect power to the appliance before attempting any service
• Remove the dispenser bezel or access panel per your model's service instructions to reach the flap
• Handle plastic parts gently to avoid cracking; verify proper orientation before reassembly

This replacement screw secures panels, brackets, and internal components within your appliance. Replacing a missing or damaged fastener restores a tight fit, reduces vibration and noise, and helps keep parts properly aligned during operation.

• Fastens panels, trim, brackets, or internal components to the chassis
• Maintains proper alignment and stability during normal use
• Replaces missing, rusted, or stripped hardware
• Common symptoms: loose or rattling panels, vibration, difficulty fastening, or a visibly missing screw

• Disconnect power; for gas appliances, also shut off the gas supply
• Match length and thread to the original; replace one-for-one in the same location
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• If the receiving hole is stripped, repair threads or replace the clip/nut before installing

This retainer is a small mounting clip that secures an appliance component or assembly in place to prevent shifting and reduce noise or wear. It restores proper fit and alignment where a worn or broken clip allows movement. What it does:

• Holds panels, trim, or small assemblies securely to their mounting points
• Prevents rattling, shifting, or misalignment caused by a missing or damaged clip
• Helps maintain proper spacing so seals and connections stay aligned
• Works as a direct-fit replacement when the original retainer is broken or missing

• One retainer

• Disconnect power and, if applicable, water supply before starting any repair
• Remove surrounding fasteners or trim gently to access the clip; avoid forcing plastic tabs to prevent breakage
• Replace with the exact part number and ensure the component is seated fully before reassembling
