Parts for Lg LFX23961SB/00: Doors Parts

This replacement screw secures appliance components in their proper position. Replacing a missing or damaged fastener restores a snug fit, reduces rattling or vibration, and helps keep assemblies aligned for reliable operation.

• Secures panels, brackets, and internal components as specified by your model's parts diagram
• Replaces stripped, rusted, or missing hardware
• Helps address symptoms like rattling/vibration noise, loose panels/trim, or minor misalignment
• Maintains a stable, safe assembly during normal use

• Disconnect power; turn off water and gas supplies if applicable
• Match screw to its original location; do not mix different lengths or types
• Start threads by hand to avoid cross-threading; tighten snugly—do not overtighten
• Follow your model's service/parts diagram for correct placement

This refrigerator door gasket creates an airtight seal between the door and cabinet to keep cold air in and moisture out. Replace a worn or torn seal to restore cooling performance, reduce frost, and prevent temperature fluctuations.

• Forms a continuous seal around the door perimeter to minimize air leaks
• Helps maintain proper temperatures and humidity inside the refrigerator
• Common failure signs: gaps, tears, or hardened/warped corners
• Symptoms may include doors not closing flush, condensation or frost buildup, and longer run times

What's included: 1 door gasket assembly Installation notes:

• Unplug the refrigerator before servicing
• Warm the new gasket in hot water or with a hair dryer on low to improve flexibility
• Pull the old gasket from the retainer channel; press the new gasket into the channel, starting at the corners
• Close the door and check for uniform contact all around; re-seat and adjust as needed

This freezer handle assembly replaces a cracked, loose, or missing freezer door handle to restore safe opening and closing and improve grip. It fits original mounting points for a factory-like appearance and function. What it does:

• Replaces a damaged or worn freezer door handle so the door can be opened and closed securely
• Restores proper grip and lever action to prevent accidental drops or slippage
• Helps maintain door alignment when pulling to reduce stress on the latch and seal
• Compatible with factory bracket and mounting hardware where the original design is intact

• One freezer door handle assembly

• Check that existing mounting screws or trim clips are present and undamaged before installation
• Some installations require removing interior trim or lifting the door slightly to align mounting pins
• Use hand tools only; avoid overtightening fasteners which can crack plastic parts
• Disconnect power or follow manufacturer safety guidance if working near electrical components or lights

This name plate is the exterior emblem that mounts to the appliance's front panel. It replaces a missing, cracked, or faded badge to restore a clean, factory look and cover the designated trim area.

• Attaches to the outer panel to display brand/series identification
• Restores a finished appearance where the original emblem sits
• Direct replacement for a lost, damaged, or worn badge
• Typical symptoms: missing emblem, loose or broken tabs, peeling, or discoloration

• Disconnect power before servicing the appliance
• Carefully remove the old emblem; release any tabs from behind or peel away remaining adhesive
• Clean and dry the mounting surface; remove all residue for best fit
• Align with the recess/holes and press evenly until fully seated

The Handle Mounting Stud is an OEM replacement part for LG refrigerator doors. It provides a sturdy mounting point for the door handle assembly. Reliable handle connection and support is crucial for dependable door function and access.

Causes of a faulty stud can include damage from excess weight or impact over time rendering the stud loose or unstable.

Symptoms of a bad stud include:

• Loose or sagging door handle
• Difficulty opening and closing the refrigerator door
• Potential for the handle to detach completely
• Safety concerns if the handle connection fails

This OEM LG replacement stud is also compatible with Sears/Kenmore models.

This replacement cover is an exterior access panel that protects internal components and restores the appliance's finished appearance. It keeps wiring and mechanisms enclosed while maintaining the cabinet's original look. What it does:

• Covers and protects internal components from dust, spills, and accidental contact
• Restores the appliance's cosmetic appearance when the original cover is cracked, chipped, or missing
• Helps maintain proper airflow routing and component spacing behind the panel
• Prevents small objects from entering service areas that could cause damage

• One replacement cover

• Disconnect power and water before starting any repair
• Remove fasteners or release retaining clips holding the old cover; keep hardware if re-using
• Align the new cover carefully and secure with the original screws or clips; do not force into place
• If clips or mount points are damaged, replace them before finishing installation

The Gasket Holder is an OEM replacement part for LG refrigerators. It is inside the freezer door and functions to securely seal in cold air. The holder provides a mounting point and compression fit for the door gasket, preventing air leakage along the perimeter.

Symptoms of a bad gasket holder include:

• Cold air escaping around the door seal
• Frost or moisture buildup near the gasket area
• The door not shutting tightly

Note: About 38.5" long

Over time, the holder's mounting points can warp or weaken from repeated opening and closing of the freezer door. This allows for gasket movement and compromised sealing.

This replacement is compatible with Sears/Kenmore models as well.

The Left Door Closing Cam is an OEM replacement part for LG refrigerators. It is a mechanical component located on the inside of the refrigerator door that works with the door closing mechanism. The door closing cam helps ensure the refrigerator door closes and seals properly each time.

Causes of a bad door closing cam can include wear and tear over time, damage from repeatedly closing the heavy refrigerator door, or misalignment affecting the door seal.

Symptoms of a bad door closing cam include:

• The refrigerator door not sealing tightly when closed
• Difficulty closing or opening the door
• Excessive movement or wobbling of the door
• Cool air escaping around the door seal

This OEM LG part is also compatible with Sears/Kenmore fridges.

The Door Closing Cam is an OEM replacement part for LG refrigerators. Positioned at the lower hinge of the right side refrigerator door, this cam assists in the smooth and controlled opening and closing of the door. It ensures that the door closes securely to maintain the internal temperature and energy efficiency of the appliance.

Causes for a malfunctioning Door Closing Cam can include wear and tear from frequent use, damage incurred from forceful opening or closing of the door, or issues with the alignment that prevent the cam from operating smoothly.

Symptoms of a bad Door Closing Cam include:

• The refrigerator door not closing securely
• A sagging or misaligned door
• Unusual noises when opening or closing the door
• Difficulty in opening or a lack of smooth motion when closing the door

This OEM LG part is also compatible with Sears/Kenmore models.

This door basket is a replacement storage bin that restores usable shelving space in the refrigerator door so you can neatly store bottles, condiments and small containers. It replaces a cracked, warped or missing door bin to keep items secure and accessible. What it does:

• Provides a stable shelf on the refrigerator door for bottles, jars and small food containers
• Replaces damaged or broken door storage that causes items to fall or shift
• Restores original organization and usable door capacity
• Matches OEM mounting points for a secure fit when installed correctly

• One door basket

• Remove food and empty the door before replacing the basket
• Align the basket with the door rail grooves and snap into place; do not force
• Inspect mounting rails and clips for damage and replace if needed
• Disconnect power only if required by your model's service instructions

The Door Basket Assembly is an OEM part for LG refrigerators. It is designed to provide additional storage space on the refrigerator door, allowing for the convenient organization of smaller items like condiments, beverages, and snacks. The bin has dimensions of approximately 13 inches in width, 3-1/2 inches in height, and 7 inches in depth.

Causes of a bad door basket assembly can include wear and tear over time, damage from overloading, or accidental impacts that can crack or break the basket.

Symptoms of a bad door basket assembly include:

• Cracks or visible damage to the basket
• Difficulty in securely holding items
• The basket detaching from the door

This OEM LG part is also compatible with Sears/Kenmore.

The Door closer is an OEM part for LG refrigerators, this part prevents the refrigerator door from swinging open too widely. By limiting the door's range of motion, the Door Stop ensures that the door opens smoothly and safely, contributing to the longevity of the appliance and maintaining the aesthetic integrity of your kitchen space.

Causes of a bad Door closer can stem from physical damage, wear and tear over time, or loosening of the component due to repeated use.

Symptoms of a bad Door closer include:

• The refrigerator door swinging open too far
• Damage or marks on adjacent walls or furniture from the door hitting them
• Increased wear on the refrigerator's hinges due to uncontrolled door movement

This OEM LG part is also compatible with some Kenmore models.

The Refrigerator Door Handle is an OEM replacement part for LG refrigerators. The door handle provides an easy grip point for opening and closing the refrigerator door.

Symptoms of a bad door handle include:

• Looseness, wobbling, or detachment from the refrigerator door
• Cracking or splitting of the plastic material
• Discoloration or warping from sun exposure

Causes can be regular wear and tear over many opening and closing cycles. Repeated force exerted by grabbing the handle may cause stress fractures. Exposure to direct sunlight's UV rays can degrade plastic over time as well.

This OEM LG part is also compatible with Sears/Kenmore refrigerators.

RAIL,SLIDE-LEFT

RAIL,SLIDE-RIGHT

This connector secures and transmits motion between the drawer drive and the sliding assembly, restoring smooth drawer movement and alignment. It's a direct-fit replacement that helps fix sticking, slipping, or non-moving drawers. What it does:

• Couples the drawer drive mechanism to the sliding gear, allowing the drawer to open and close reliably
• Replaces worn or broken connector teeth or mounts that cause skipping or jammed operation
• Helps correct uneven or noisy drawer movement caused by damaged linkage
• Restores proper engagement so the drawer responds to normal open/close controls

• One connector as shown

• Disconnect power to the appliance before servicing to avoid electrical shock or injury
• Inspect surrounding gears, tracks, and mounting points; replace any damaged parts for best results
• Basic hand tools are typically required; handle plastic gears carefully to avoid further damage

This is a ring intended for use in refrigerators. The ring is used to adjust the height of the door. Genuine OEM replacement rings are necessary for the repair to ensure a proper fitting.If the refrigerator door no longer opens or closes easily, or if it is not sealing properly, the rings may need to be replaced. Visual inspection can determine if there are problems with the refrigerator door rings. Make sure to unplug the device before starting any of the disassemblies of the machine. Wear gloves.This ring is an authentic OEM replacement part. It is sold as an individual unit. The ring is made of high-quality, durable materials. The replacement piece is sourced directly from the manufacturer. It can be installed in several models of refrigerators. The genuine OEM replacement ring is compatible with refrigerators produced by both LG and Kenmore.

The Hinge Bushing is an OEM part for LG refrigerators. It serves as a crucial component in the door hinge mechanism, ensuring smooth and stable operation when opening and closing the refrigerator door.

You should replace this hinge bushing if it becomes worn out or damaged. Common causes of a bad hinge bushing include constant use leading to wear and tear, misalignment of the door, or physical damage due to impact.

Symptoms of a bad hinge bushing include:

• Difficulty in opening or closing the door
• The door sagging or not aligning properly
• Unusual noises like squeaking or grinding when the door is moved

This OEM LG part is also compatible with Sears/Kenmore.

The Water Tube Connector is an OEM part for LG refrigerators. It is specifically designed to securely connect the water supply tubes in the refrigerator. The connector ensures a proper seal, preventing leaks and ensuring a consistent water supply to your refrigerator.

Causes of a bad water tube connector can include wear and tear over time, exposure to water pressure, or damage due to accidental impact or mishandling. These factors can result in leaks, water flow disruptions, or a loose connection, leading to issues with water dispensing or ice making.

Symptoms of a bad water tube connector may include:

• Water leaks at the connection point
• Reduced or intermittent water flow
• Complete water flow blockage

This OEM LG part can also be used on Kenmore/Sears appliances.

The Water Line Connector is an OEM replacement part for LG refrigerators. It is responsible for connecting the water supply line from the home plumbing to the refrigerator's internal water distribution system, allowing for ice and water dispenser functionality.

Causes of a bad water line connector can include cracking, leaks, or deterioration of the connector material over time due to regular water pressure and temperature fluctuations. Connectors may also become damaged if exposed to impact.

Symptoms of a bad water line connector include:

• Leaks at the connection point between the line and refrigerator
• Loose, slipping, or disconnected water line fitting
• Reduced water pressure or no water flow to the dispenser
• Error codes related to water flow from the refrigerator diagnostics

 This OEM LG part is also compatible with Sears/Kenmore refrigerators.
