Parts for Kitchenaid KRSF505ESS01: Freezer Door Parts

The FreshFlow Refrigerator Air Filter is an OEM component for Whirlpool and Maytag refrigerators. Located inside the ventilation system, this filter purifies circulated air. This air filter is 3" wide by 2" high and white in color. It should be replaced every 6 months to ensure the best performance.

Causes of failure relate to clogging from trapped dust, dander and other allergens despite regular replacement intervals. Performance decreases as filter media becomes saturated over months of use.

Symptoms of a dirty or blocked refrigerator air filter include:

• Reduced airflow causes higher compressor runtime hours
• Odors being pulled into the fridge from unfiltered vents
• Shortening of food storage life due to unpurified air exposure
• Reduced fan speeds or strange noises originating from the vents

This genuine Whirlpool filter is also compatible with Maytag, Jenn-Air, and Amana models as well.

The Whirlpool EveryDrop Ice and Refrigerator Water Filter 1 is an OEM replacement part for Whirlpool refrigerators. This filter works to remove small particles from water to ensure clean, great-tasting ice and drinking water directly from the refrigerator door.  Measuring approximately 2.50 x 2.50 x 8.69 inches, this filter is easy to install.

For optimal performance, we recommend replacing the filter every six months. The filter material is made from coconut carbon block, which has a micron rating of 0.5 and a flow rate of 0.5 gpm. The filter is designed to operate at a maximum pressure of 125 psi and an operating temperature of 38-100°.

Symptoms of a filter needing replacement include:

• Gradual decline in water/ice quality over time exhibiting muddy appearance or odd tastes
• Filter life indicator appears showing it is time for a new one

Causes stem from normal usage over the stated capacity of the original filter. Allowing one to expire could produce unhealthy water.

This OEM replacement part is compatible with select Maytag, Jenn-Air, and Amana models as well.

The Door Handle is an OEM part for Whirlpool refrigerators. This sturdy handle serves as a convenient way to open and close the doors of your appliance. The handle offers a comfortable grip and provides  an easy way to access your refrigerator and freezer compartments.

A bad door handle can occur due to excessive force, accidental impacts, or simply regular use over time. If you notice symptoms such as a loose or wobbly handle, difficulty in opening or closing the doors, or visible cracks or damage, it may be time to replace this part.

Symptoms of a bad door handle include:

• Loose or wobbly handle
• Difficulty in opening or closing the doors
• Visible cracks or damage

Restore your Whirlpool refrigerator by replacing the worn or damaged door handle with this genuine OEM part.

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.


The Door Thimble, Top is an OEM part for Whirlpool refrigerators. This component is used to support and secure the door hinge, ensuring smooth and stable opening and closing of the refrigerator door.

You should replace the door thimble if it becomes damaged or worn out. Causes of a bad door thimble include wear and tear from frequent use, stress from heavy door loads, or damage from accidental impacts. A faulty thimble can lead to misalignment of the door, causing it to sag or not seal properly.

Symptoms of a bad Door Thimble, Top include:

• Difficulty in opening or closing the door
• The door not aligning correctly with the refrigerator frame
• Noticeable sagging or wobbling of the door
• Unusual noises when the door is moved

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This 10-32 machine screw secures appliance components such as brackets, panels, and trim. Replace missing or stripped hardware to restore a tight, rattle-free fit and maintain proper alignment of the assembly.

• Fastens parts that require a 10-32 threaded fastener
• Helps prevent vibration, noise, and movement from loose hardware
• Restores correct fit and alignment after a screw is lost or damaged
• Common signs: loose panel/trim, rattling, or a missing/stripped screw

• Disconnect power and shut off water/gas as applicable before servicing
• Compare to the original and start threads by hand to avoid cross-threading
• Tighten snugly; do not overtighten to prevent stripping or damage
• Match thread size and length to your original fastener for proper fit

The Door Handle Mounting Screw is an OEM part for Whirlpool refrigerators. It secures the door handle to the refrigerator door.

Causes of a bad door handle mounting screw can include wear and tear over time, improper installation, or excessive force applied to the handle. These factors can result in a loose or wobbly handle, compromising the functionality and aesthetics of your refrigerator.

Symptoms of a bad door handle mounting screw may include:

• A loose or unstable handle
• Difficulty in opening or closing the refrigerator door
• The handle becoming detached

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Replacement door bin that restores secure storage inside the refrigerator door for bottles, condiments and small items. Ideal when the original bin is cracked, broken, loose or missing and items slide or fall out. What it does:

• Holds and organizes bottles, condiments and small containers to prevent shifting in the door.
• Replaces a cracked, broken or missing door bin that causes items to fall or roll out.
• Snaps into existing door shelf supports to restore stable storage and organization.
• Conservatively restores normal door storage without replacing the entire door assembly.

• Most installs require no tools: remove contents, lift the damaged bin out and snap the replacement into the door shelf supports.
• Remove food and bottles before replacing to avoid spills.
• Wear gloves when handling broken plastic to avoid cuts.

This factory fastener secures appliance components and panels. Replacing worn, stripped, or missing screws restores a tight, rattle-free fit and keeps parts properly aligned for dependable performance.

• Fastens brackets, panels, and internal parts in the specified location
• Helps maintain alignment and reduces vibration or rattling
• Direct replacement for a missing, damaged, or stripped screw
• Symptoms include loose or shifting parts, gaps, or buzzing/rattle noises

• Disconnect power; turn off water or gas supply if applicable
• Use the correct driver; start threads by hand to avoid cross-threading
• Tighten until snug—do not overtighten
• Inspect/repair stripped threads or damaged mating hardware before installation

Color: Mist Beige

Color: Black

Color: Grey

This small bushing fits over the hinge cam to guide the door's swing. Replacing a worn thimble restores smooth movement and alignment so the door opens and closes consistently and helps maintain a proper seal. What it does:

• Provides a low-friction bearing surface between the hinge pin and cam
• Helps control door swing and detent/self-close action
• Supports proper door alignment to reduce rubbing or sagging
• Symptoms may include popping/clicking, grinding, binding, uneven closing, or a door that doesn't fully close

• 1 door hinge cam thimble

• Disconnect power and remove items from the door before servicing
• Support the door; remove hinge cover/fasteners and lift the door off the hinge
• Replace the thimble on the hinge/cam, matching the original orientation and fully seating it
• Inspect the mating cam and hinge surfaces; replace worn parts as needed and verify gasket seal after reassembly

Thimble cam that secures and guides the dryer door latch assembly, helping the door close and stay latched so the appliance can run safely and reliably. Replaces worn or damaged door cam components. What it does:

• Engages the door latch/strike to keep the door closed during cycles.
• Helps maintain proper door alignment so the lid/door seals and latches correctly.
• A worn or broken cam can cause the door to hang, fail to latch, or prevent the dryer from starting.
• Works as the mechanical interface between the door and latch assembly.

• Disconnect power (and shut off gas supply on gas models) before servicing.
• Access typically requires removing the dryer door trim or access panel.
• Inspect the latch, strike, and mounting hardware; replace any worn or damaged fasteners when installing the new cam.

The Bracket is an OEM part for Whirlpool-brand refrigerators. These brackets are mounted internally to provide secure anchoring points for door assemblies on the refrigerator frame.

Causes of a bad bracket can include cracks from over-tightening during installation, or metal fatigue over many open/close cycles.

Symptoms of a bad bracket include:

• Loose or sagging refrigerator doors that do not close flush
• Gaps appearing around door seals
• Noises or vibrations emitting from door areas
• Doors difficult to open/close smoothly

As a core mounting component, brackets ensure doors remain firmly and safely attached year after year of use. Replacing a damaged bracket with this OEM part restores a proper secure fit. Compatible also with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This factory screw secures components in your appliance to keep them properly mounted and stable during operation. Replacing a missing or damaged screw restores a tight fit and helps prevent vibration, noise, or loosening parts.

• Fastens panels, brackets, or trim to maintain correct alignment
• Can address rattling, vibration, or loose/misaligned parts where this screw is used
• Helps prevent wear from movement caused by missing or stripped hardware

• Unplug power and shut off utilities before service
• Note original screw location and orientation; replace like-for-like
• Do not overtighten—start by hand to avoid cross-threading
• Address threads before installing the new screw

This replacement door stop cover protects the dryer/washer door stop assembly and restores a finished look to the front-control area. It helps cover the stop hardware and prevents snagging or cosmetic damage. What it does:

• Covers the door stop hardware on front-control appliances to protect clothing and hands
• Restores the finished appearance where the original cover is cracked, missing, or worn
• Helps prevent edges of the stop assembly from catching fabric
• Matches the original white finish for a neat, factory look

• Disconnect power to the appliance before starting any repair
• Remove the front-control panel or access trim per your model's instructions to reach the stop cover
• Use basic hand tools; avoid force to prevent damage to surrounding trim or clips
• If clips or fasteners are broken, replace them with OEM parts for a secure fit

This COVER-WIRE protects appliance wiring from abrasion and incidental contact, helping keep connections organized and shielded. It's a simple replacement that restores the factory routing and protection for exposed harnesses. What it does:

• Shields wiring from chafing and contact with sharp edges
• Helps prevent insulation wear that can lead to exposed conductors
• Keeps harnesses routed neatly to reduce stress and snagging
• Can reduce intermittent electrical issues caused by damaged wire insulation

• One COVER-WIRE as shown

• Disconnect power (and water, if applicable) before servicing to avoid shock or damage
• Inspect surrounding wiring and connectors; replace any damaged wires or terminals
• Typically secures with factory clips or fasteners—use OEM fasteners where required

This bin frame is the structural support that holds a refrigerator storage bin or drawer in place, restoring proper alignment and smooth operation. It prevents sagging and keeps the drawer securely seated for reliable everyday use. What it does:

• Supports and stabilizes the storage bin/drawer to prevent drooping or falling out
• Keeps the drawer aligned for smooth sliding and proper sealing
• Reduces rattling or noisy operation caused by a broken or bent frame
• Helps prevent caught or jammed drawers that won't open or close fully

• Disconnect power to the appliance before beginning work to reduce shock risk
• Remove food and the drawer/bin before replacing the frame
• Use basic hand tools; avoid forcing parts to prevent damage
• Inspect adjacent clips or slides and replace if worn for best fit
