Parts for Ge ZDP486LRP4SS: 01 - Gas & Burner Parts

This lubricant/cleaner is used during service of cooking appliances to dissolve residue and provide light lubrication on small moving parts. It helps restore smoother operation of control shafts and valves when burner knobs feel stiff or sticky. What it does:

• Cleans deposits and old grease from control shafts and valve components
• Provides light lubrication to reduce friction and sticking
• Helps address symptoms such as hard-to-turn burner knobs or rough valve rotation
• Supports preventative maintenance during range/cooktop service

• Lubricant/cleaner

• Disconnect power and shut off gas; allow the appliance to cool before servicing
• Work in a well-ventilated area and keep away from open flames or ignition sources
• Apply sparingly per service instructions; avoid contact with igniters, electrical components, and flame ports
• Replace any worn or leaking valve—do not rely on lubricant/cleaner to correct a leak

Natural gas. Main burner.

Natural gas. Simmer burner

Liquid propane. Main burner.

Liquid propane. Simmer burner

The Burner Box Harness is an OEM part for GE gas cooktops and ranges. It is responsible for securely connecting wiring from the cooktop control board to the individual burner boxes located beneath each cooktop burner.

Causes of a bad burner box harness include worn, cracked, or damaged insulation coating the individual wires. Improper routing or bending of wires during installation or servicing can also weaken connections over time.

Symptoms of a bad burner box harness involve issues controlling specific burners such as:

• Burners failing to ignite during start-up
• Igniters or valves malfunctioning intermittently
• Error codes related to individual burner components

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This 1/4-20 screw secures panels, brackets, and other assemblies in your appliance. It restores a tight, reliable hold when an original fastener is missing, stripped, or corroded.

• Fastens components that require a 1/4-20 threaded screw
• Helps keep panels and assemblies aligned and rattle-free
• Direct replacement for worn, rusted, or lost hardware
• Common symptoms: loose or vibrating parts, misaligned brackets, missing fastener

• Disconnect power; turn off gas supply before servicing
• Allow the appliance to cool; wear gloves and eye protection
• Start threads by hand to avoid cross-threading; use the correct driver/tool
• Tighten snugly—do not overtighten to prevent stripping or damage

This six-point spark ignition module for gas cooktops/ranges converts line voltage into high-voltage pulses that fire the burner igniters. It restores consistent, reliable lighting across multiple burners when you turn a knob.

• Distributes high-voltage pulses to up to six surface-burner igniters when a burner switch is turned on
• Helps resolve no spark/click on all burners, no spark on some burners, intermittent ignition, or continuous clicking
• Replaces a module that produces weak, erratic, or no spark
• Ignition control only; it does not regulate gas flow or flame size

• Disconnect power and shut off gas before servicing
• Photograph and label all wires; transfer them one at a time to the matching terminals (six HV outputs plus power/ground)
• Mount securely in the original location and keep connections dry; after installation, ensure burner caps are seated and igniters are clean

18K

This LED light assembly replaces a failed or damaged interior refrigerator light to restore bright, energy-efficient illumination inside the fresh-food compartment. It mounts in the light housing and connects to the factory wiring harness. What it does:

• Replaces burned-out or broken interior LED lighting
• Restores consistent, flicker-free illumination when the door is opened
• Helps you see foods and settings clearly on shelves and door bins
• Works with the factory light housing and wiring for a direct replacement

• Disconnect power to the appliance before beginning any work to avoid electric shock.
• Handle the LED assembly and connectors carefully; avoid touching LED surfaces or exposing contacts to moisture.
• Some installations require removing the light housing or interior trim; keep fasteners organized for reassembly.
• If mounting screws, brackets, or clips are not obvious, refer to the appliance's parts diagram or service manual to identify the correct removal order.

This switch valve assembly replaces the appliance's combined valve and switch module to restore controlled on/off operation of the valve. It provides a direct replacement for the original electromechanical valve switch to help the appliance operate reliably. What it does:

• Acts as the combined valve and switch module that controls flow when signaled by the appliance control
• Reestablishes reliable electrical switching to open and close the valve under normal operation
• Commonly used when the valve fails to actuate or when intermittent valve switching occurs
• Helps eliminate symptoms such as failure to start flow, no actuation, or inconsistent on/off cycling

• Disconnect power to the appliance before servicing; if the valve controls gas or water, also shut off supply
• Take photos or mark wiring before disconnecting to ensure correct reconnection
• Handle the part by mounting points; avoid stressing wiring or connectors

This handle grommet cushions and secures a range or oven door handle, preventing vibration and wear while keeping the handle snug. It's a small replaceable part that restores proper fit and reduces rattling. What it does

• Provides a soft mounting surface between the handle and door to prevent metal-to-metal contact
• Keeps the handle tight and aligned to stop looseness or movement
• Dampens vibration and reduces rattling during operation
• Helps protect the door finish where the handle mounts

• One handle grommet

• High-level push-fit part; remove the handle or access the mounting area per your model's service instructions
• Disconnect power to the appliance before beginning service when accessing electrical or heated components
• Use a plastic trim tool or small screwdriver to pry out the old grommet carefully to avoid scratching the door
• If the handle or mounting hardware is damaged, inspect and replace as needed for a lasting repair

This replacement transformer converts household line voltage to the correct level for the appliance's control circuits. It restores stable power to the display and relays so the unit can start and run consistently.

• Converts incoming AC power to the proper voltage for electronic controls and relays
• Failure can leave the display blank and controls unresponsive even though power is supplied
• Intermittent resets or loss of functions can indicate a weakening transformer
• Replace if windings test open/shorted or the part shows overheating damage

• Disconnect power at the breaker before servicing; this part connects to line voltage
• Photograph and label wires; transfer connections one at a time to the new part
• Mount securely and route wiring away from sharp edges and hot components
• Restore power and verify the controls power up normally

This safety valve controls gas flow to the range/oven burner and helps ensure reliable ignition and shutoff for safe cooking. Replacing a worn valve restores proper gas delivery and can stop intermittent heating issues. What it does:

• Opens and closes the gas supply to the oven/burner so burners ignite only when commanded
• Prevents uncontrolled gas flow when the appliance is off
• Common replacement when burners or oven fail to light or heat inconsistently
• Can address persistent clicking, weak flame, or failure to maintain temperature

• One safety valve

• Turn off the appliance power and gas supply before starting work
• Inspect and replace any damaged gaskets or fittings during installation
• Use proper tubing fittings and a leak test after reassembly; check for tight seals
