Parts for Lg LMX25964SS: Ice Maker Parts

The LG Refrigerator Water Filter is an OEM Replacement Part. It is designed to improve the quality of water and protect refrigerators and ice machines from sediment deposits. This NSF-Certified filter effectively reduces iron and particulates. It also preserves beneficial minerals like fluoride. The filter measures 5.6 inches high and 3.3 inches in diameter.

It is installed by removing the top shelf and pulling the old filter downward. Then turn it counter-clockwise, and replace it with the new filter aligned in a horizontal position. To ensure the best performance and the removal of trapped air and contaminants, it's recommended to flush the dispenser with 2.5 gallons of water in alternating cycles. If your model includes a water filter indicator, press and hold the Filter or Reset button for 5 seconds after installation. With a lifespan of 6 months and a 500-gallon capacity, this filter provides both quality and longevity.

Note: 90 degree elbow coupler (Fits 1/4" diameter tubing on each end) For 5/16" elbow connector, order part# 4932JA3009B.

The Water Line Union is an OEM part for LG refrigerators. This component connects sections of the water line, ensuring a secure and leak-free passage of water to the refrigerator's icemaker and water dispenser. It is an elbow tube union connector, which connects two tubes at a 90-degree angle.

Causes of a bad water line union can include wear and tear from frequent use, damage from high water pressure, or deterioration due to mineral buildup and age. A compromised union can lead to water leaks and disruption in the water supply.

Symptoms of a bad Water Line Union include:

• Water leaks around the connection points
• Reduced water flow to the icemaker or water dispenser
• Puddles or moisture near the refrigerator
• Unusual noises from the water line

This OEM LG part is also compatible with Sears/Kenmore.

The Ice Maker Water Line is an OEM part for LG refrigerators. This water line is responsible for delivering water to the ice maker, enabling the production of ice. It is designed to ensure a reliable and leak-free connection between the water supply and the ice maker unit.

You should replace the ice maker water line if it becomes damaged or blocked. Causes of a bad water line can include kinks, cracks, or blockages due to mineral deposits or debris. Over time, these issues can prevent the proper flow of water, leading to reduced ice production or leaks.

Symptoms of a bad water line include:

• No ice being produced
• Low ice production
• Water leaks around the refrigerator or ice maker area
• Visible kinks or cracks in the water line

This OEM LG part is also compatible with Sears/Kenmore.

The Water Line is an OEM part for LG refrigerators. It is designed to transport water from the home’s supply to the refrigerator, enabling the production of ice and the dispensing of fresh water. This tubing is essential for the refrigerator's water and ice features to function correctly, ensuring clean, clear water is available at all times.

Symptoms of a bad Water Line include:

• Noticeable leaks or dampness along the line's path.
• Decreased water flow to the dispenser or ice maker.
• Unusual noises like buzzing or humming from the line when the dispenser is used.

Causes of a bad water line can include physical damage such as cracks or punctures, blockages from mineral buildup inside the line, or deterioration due to aging or environmental factors such as heat or pressure.

This OEM LG part is also compatible with Sears/Kenmore, ensuring broad compatibility across multiple refrigerator models.

The Reservoir Water Supply Line is an OEM part for LG refrigerators. This component is essential for delivering water from the reservoir to the dispenser and ice maker, ensuring a steady and reliable flow.

Symptoms of a bad Reservoir Water Supply Line include:

• Leakage of water at connection points or along the line.
• Reduced water flow to the dispenser or ice maker.
• Unusual tastes or odors in the dispensed water.
• Visible signs of wear, such as kinks or brittleness.

Causes of a bad water supply line can include physical damage from bending or pinching, chemical degradation from exposure to contaminants, or blockages due to sediment or scale buildup.

This OEM LG part is also compatible with Sears/Kenmore.

The Water Valve Assembly is an OEM part for LG refrigerators. It is essential for controlling the flow of water to the ice maker and the water dispenser. This solenoid-operated valve responds to signals from the refrigerator’s electronic control system to accurately manage the release of water, ensuring efficient operation and reliability.

Symptoms of a bad Water Valve Assembly include:

• The ice maker not producing ice or producing very small cubes
• The water dispenser not functioning or dispensing a trickle instead of a steady flow
• Water leaking from the refrigerator

Causes of a bad water valve assembly can stem from mineral deposits that clog the valve, electrical failures that impair the valve’s operation, or wear and tear from normal usage leading to leaks or malfunctions.

This OEM LG part is also compatible with Sears/Kenmore.

Note: Flow meter is not needed on all models, remove if necessary. Redesigned single valve replaces older dual solenoid valves. Wiring harness is included. Located behind the refrigerator.

The Water Valve Assembly is an OEM part for LG refrigerators. It is essential for controlling the flow of water to the ice maker and the water dispenser. This solenoid-operated valve responds to signals from the refrigerator’s electronic control system to accurately manage the release of water, ensuring efficient operation and reliability.

Symptoms of a bad Water Valve Assembly include:

• The ice maker not producing ice or producing very small cubes
• The water dispenser not functioning or dispensing a trickle instead of a steady flow
• Water leaking from the refrigerator

Causes of a bad water valve assembly can stem from mineral deposits that clog the valve, electrical failures that impair the valve’s operation, or wear and tear from normal usage leading to leaks or malfunctions.

This OEM LG part is also compatible with Sears/Kenmore.

Note: Flow meter is not needed on all models, remove if necessary. Redesigned single valve replaces older dual solenoid valves. Wiring harness is included. Located behind the refrigerator.

This cover cap is a small plastic trim piece that protects exposed fasteners and improves the appliance's appearance. It snaps into place to hide mounting posts and help prevent snags or debris buildup. What it does:

• Covers and protects exposed screws, posts, or fasteners for a finished look
• Prevents lint, dust, and debris from collecting around the mounting point
• Reduces the chance of fabric snags or contact with sharp edges
• Restores worn or missing trim for improved cosmetics

• Disconnect power to the appliance before starting any service that exposes electrical components
• Usually installs by snapping over the post or press-fitting into the trim opening — no special tools required
• If needed, remove adjacent trim pieces to gain access, then reinstall trim in reverse order
• Inspect surrounding mounting hardware for damage and replace if necessary

This pipe holder is a small plastic clip that secures tubing and small pipes inside the appliance, helping keep lines organized and preventing rubbing or disconnection. It restores proper routing and reduces vibration-related noises. What it does:

• Holds and secures water, drain, or refrigerant tubing to prevent sagging and chafing
• Keeps lines routed away from moving parts to reduce wear and noise
• Helps maintain proper tube alignment to avoid strain on fittings
• Commonly replaced when the original clip is cracked, broken, or missing

• Disconnect power and water before working on the appliance
• Inspect surrounding tubing and fittings for damage when replacing the clip
• Typically installs as a push-fit or snap-on clip; use gentle pressure and avoid forcing
• Replace broken or brittle clips to prevent tubing damage or leaks

This holder is a small mounting bracket that secures a mating component in place inside the appliance. Replacing a cracked or missing holder restores a firm, rattle-free fit and proper alignment.

• Provides a stable mount for the designated part
• Prevents shifting and vibration that can cause noise or premature wear
• Common signs of failure: broken tabs, stress cracks, or the attached part sagging or falling out
• When damaged, the connected component may be loose, noisy, or misaligned

• Disconnect power; if working near water tubing, also shut off the water supply
• Note the original orientation and mounting points; take a photo before removal
• Reuse existing fasteners and avoid overtightening to prevent cracking the plastic
• Ensure the attached component is secure and clears any moving parts before restoring power
