Parts for Dacor ER48DSCHNGH: Oven Parts 2 Parts

This welded glass frame for the broiler door replaces a damaged or worn frame to restore the door's appearance and help the broiler seal and operate as intended. Fits into the broiler door assembly and supports the broiler glass. What it does:

• Replaces a cracked, warped, or separated broiler glass frame that can let heat escape or expose sharp edges
• Supports and secures the broiler glass panel inside the oven door assembly
• Restores proper alignment of the broiler glass for safer operation and better heat containment
• Helps prevent rattling or movement of the broiler glass during use

• One welded broiler glass frame

• Disconnect power and allow the appliance to cool completely before starting
• Handle glass edges carefully; wear protective gloves and eye protection
• Installation typically requires removing the broiler/oven door or door inner panel to access the frame

A direct-replacement broil element that restores high-heat cooking performance for the oven's broiler. Replaces a failed or damaged element to help return even browning and proper broiling results. What it does

• Heats to provide the intense, direct heat used for broiling and top-surface browning.
• Commonly installed when the broiler will not heat or produces weak/uneven browning.
• Replaces elements that show visible damage, arcing, or open electrical continuity.
• Works with the oven's broil circuit and control system to reach broiling temperatures.

• One broil element

• Disconnect power to the appliance at the breaker or unplug before starting work.
• Access typically requires removing the oven cavity or rear panel—follow your model's service instructions.
• Handle the element and terminals carefully to avoid bending or damaging mounting tabs and electrical connectors.
• Verify electrical connections and test continuity with a multimeter after installation.

The Broiler Glass for Mechanical Sewing Machines is designed to seamlessly restore the functionality of your Samsung sewing machine. This genuine OEM part ensures a perfect fit, maintaining the integrity and performance of your appliance. Crafted from high-quality materials, the Broiler Glass offers excellent resistance to heat and wear, providing durability and longevity for your sewing machine. Its precise design allows for easy installation, enabling you to quickly replace a cracked, missing, or damaged glass component without the need for professional assistance. By choosing this genuine OEM part, you ensure compatibility with your Samsung mechanical sewing machine, guaranteeing reliable operation and consistent results for all your sewing projects. The Broiler Glass not only protects the internal components of your machine but also contributes to a safer and more efficient sewing experience. Invest in this essential replacement part to keep your sewing machine running smoothly and effectively, enhancing your overall crafting endeavors.

A replacement bake glass panel for the oven door that restores the viewing window and barrier between the oven cavity and exterior. Helps maintain a clear view of cooking and restores the door's protective glass. What it does:

• Replaces cracked, chipped, or fogged oven door glass to restore visibility and appearance
• Provides the glass barrier that helps contain heat inside the oven cavity
• Reduces drafts or heat loss from a damaged door glass
• Works as the visible window for monitoring food without opening the door

• One oven door bake glass panel

• Disconnect power to the appliance before beginning any repairs
• Handle glass carefully; wear cut-resistant gloves and eye protection
• Installation may require removing the oven door and separating door panels—refer to OEM service instructions
• Reuse existing parts or obtain OEM replacements

This oven bake gasket seals the gap between the oven door and cavity to help retain heat and maintain even cooking. It replaces a worn or damaged seal for improved temperature performance and reduced heat loss. What it does:

• Seals the oven door to help keep heat inside the cooking cavity
• Reduces heat escape that can cause uneven baking or longer cook times
• Helps prevent hot air and smoke from leaking around the door
• Replaces torn, flattened or brittle gasket material that no longer seats correctly

• One bake gasket (single oven door seal)

• Disconnect power (and gas if applicable) and allow the oven to cool before servicing
• Handle the gasket carefully and wear gloves to avoid cuts from metal edges or glass
• Ensure gasket is seated fully into the channel and trim/fit per OEM guidance; door or inner panel removal may be required

The Halogen Light Assembly is an OEM part for Samsung ovens. It provides illumination within the oven cavity, allowing you to easily monitor the cooking progress of your dishes.

A bad halogen light assembly can be caused by electrical issues, component failure, or damage to the bulb or socket. When the light assembly malfunctions, it can result in a range of problems, such as no light being emitted, flickering light, or the bulb not turning on at all.

Symptoms of a bad halogen light assembly include:

• No light emitted from the oven cavity
• Flickering light or poor illumination
• Bulb not turning on when the oven is in use
• Error codes displayed on the control panel

Replace your faulty halogen light assembly with this genuine OEM part to restore your oven. This Samsung part can also be used on Kenmore/Sears appliances.


The 12 Volt Halogen Bulb is an OEM replacement part for Samsung ranges and wall ovens. It is a specialized lighting component designed to illuminate the oven cavity, providing clear visibility and ensuring accurate monitoring of the cooking process.

Causes of a bad halogen bulb can include normal burnout over time, exposure to moisture, or damage due to impact. Electrical surges can also shorten the lifespan of the bulb.

Symptoms of a bad 12 Volt Halogen Bulb include:

• The light not turning on
• Flickering or dim light
• Intermittent lighting issues
• Blackened or broken bulb

This OEM Samsung part ensures compatibility and reliable performance for your appliance.

This wire harness routes power between the oven's control and the bake/broil elements to enable consistent heating. It replaces a damaged or worn harness to restore reliable bake and broil function. What it does:

• Connects bake and broil heating elements to the oven control and terminal block
• Provides secure wiring paths and insulated connections to prevent shorts
• Commonly replaced when bake or broil functions fail or work intermittently
• Helps stop issues like no heat, uneven heating, or tripped breakers caused by damaged wires

• Always disconnect power to the appliance before starting any repair
• Inspect connectors and terminals for corrosion or damage; replace if necessary
• Route harness to avoid contact with sharp edges or high-heat surfaces

This male service connector provides a secure connection point for refrigeration service access on compatible appliances, allowing technicians to attach service hoses for pressure checks and refrigerant handling during maintenance. What it does:

• Connects a service hose to the appliance service port for pressure testing and diagnostics
• Enables refrigerant charging and evacuation when used with proper service equipment
• Provides a sealed interface to minimize leaks at the service access point
• Helps restore proper serviceability when the original connector is damaged or worn

• For use by qualified appliance or refrigeration technicians only; follow all refrigerant-handling regulations
• Depressurize and isolate the system before removal or installation
• Use appropriate tools and leak-testing methods after installation
• Replace any damaged seals or gaskets and ensure a proper torque on fittings

This is the upper/broil heating element for electric ovens, designed to restore high-heat broiling and even top-surface browning. Replaces a failed broil coil so your oven can reach proper broil temperatures again. What it does:

• Provides the intense, direct heat required for broiling and browning food
• Heats the oven's upper cavity so broil cycles reach target temperatures
• Commonly fails open or shorts, causing no broil heat or a tripped breaker
• Restores consistent top-element performance when damaged, burned, or broken

• One broil (upper) heating element

• Disconnect power at the breaker before attempting any service
• Allow the oven to cool completely; heating elements can be hot or fragile
• Remove the oven racks and access the element mounting screws; support the element while disconnecting wiring

This is a replacement bake element for compatible electric ovens that provides the lower-oven heat source used for baking and roasting. Restores even bottom-heat performance when the original element is faulty. What it does

• Heats the oven's lower cavity to provide the radiant heat needed for baking and roasting.
• Commonly replaced when the oven fails to reach set temperatures or bakes unevenly.
• Can show visible damage (breaks, blisters) or electrical failure (no heat) when defective.
• Works with oven controls to cycle on/off for temperature regulation.

• 1 bake element

• Disconnect power at the breaker before inspecting or replacing the element.
• Handle the element carefully to avoid bending or damaging the terminals.
• Verify terminal connections are tight and secure; replace mounting screws if worn.
