Parts for Maytag MEC4536WB00: 01 - Cooktop Parts

This cooktop glass surface replaces a damaged or worn top on compatible Whirlpool cooktops, restoring a smooth cooking surface and original appearance. Designed to accept burners and control components without needing a full appliance replacement. What it does

• Provides the main cooking surface and seals the cavity below from spills and debris
• Restores a flat, stable surface for burners or radiant elements
• Replaces cracked, chipped or heavily scratched glass to improve safety and appearance
• Helps prevent electrical and component damage by maintaining the original barrier between burners and internal parts

• Disconnect power at the breaker before starting; surface removal exposes wiring and terminals
• Handle with care — glass is fragile and may require two people for safe removal and installation
• Use only the correct part number for your model;
• Follow OEM instructions and manufacturer torque/fastening sequences for secure fit and proper alignment

The Stove Top Drip Pan is an OEM replacement part for Whirlpool gas and electric ranges. It is located underneath the stove burners and grates to catch and contain grease drippings and spills. Over time, grease and cooking residue buildup can cause drip pans to crack, warp or corrode.

Symptoms of a bad stove top drip pan include:

• Grease spillovers outside of the drip pan area
• Flames or heating elements obstructed by built-up debris
• Warping or cracking of the pan surface
• Difficulty removing or cleaning the drip pan

Causes can be normal wear from heat and long-term grease exposure. Accidental damage during cleaning is also possible.

 This OEM part is also compatible with Maytag, Jenn-Air, Amana and some Kenmore models.

The Stove Top Drip Pan is an OEM replacement part for Whirlpool ranges. It is the shallow metal pan located below the stove burner elements that collects grease and food particles. The drip pan helps direct spills and drips away from the burner area to the bottom drawer for easy cleanup.

Symptoms of a bad drip pan include:

• Grease or food spilling below the burners outside of the pan
• Burner elements showing signs of corrosion or damage from drips
• The drip pan no longer fitting properly or securely in place

Causes can be warping or damage of the drip pan over time due to exposure to heat. Dents and structural changes compromise its ability to direct drips properly.

This OEM replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

If you require a compatible 6-inch drip bowl, suggest considering our WPW10196406 model for a perfect fit. For a black option include the 6-inch W10290353RW and 8-inch WPW10290350 models.

Replacement indicator light for control panels that restores visible status and cycle feedback. Ideal when the control-panel light is dim, cracked, or not illuminating—helps active functions and cycle progress at a glance. What it does:

• Illuminates to indicate active functions and cycle/status information on the control panel.
• Replaces a cracked, burnt-out, dim, or non-functioning indicator light.
• Common symptoms it can fix: a dark, flickering, or intermittently working panel indicator.

• Disconnect power (unplug or shut off the circuit breaker) before servicing the appliance.
• Access may require removing the control panel or lens; follow the owner's manual or service guide for panel removal.
• Handle the light and lens carefully to avoid damage; avoid touching bulb surfaces with bare hands.

This replacement light lens covers the appliance's bulb, protecting it from contact, moisture, and splashes while diffusing illumination. Replacing a cracked or missing lens restores safe, even lighting and keeps the bulb properly shielded. What it does:

• Shields the bulb from contact, moisture, and debris
• Diffuses light for more even illumination with reduced glare
• Helps protect the socket area from contamination
• Typical symptoms: cracked, warped, or missing lens; discoloration; exposed bulb; harsh or uneven lighting

• Includes: 1 light lens

• Disconnect power to the appliance before servicing; allow the lamp/area to cool completely
• Wear gloves and eye protection when handling an old or broken lens
• Remove retaining screws, tabs, or clips and note lens orientation for reassembly
• Reuse existing hardware if required; do not overtighten; restore power and test light operation

This genuine-style control knob restores safe, confident control of a stove or oven function. It replaces a cracked, faded, loose, or missing knob so you can set temperature or burner levels accurately and easily. What it does:

• Replaces a damaged or missing control knob so you can turn burner or oven controls smoothly.
• Stops slipping or wobbling that prevents accurate setting selection.
• Restores the visible indicator for setting positions so you can confirm selections at a glance.
• Useful when the original knob is cracked, melted, discolored, or the grip is worn.

• One control knob.

• Disconnect power to the appliance or switch off the gas/electric supply before servicing.
• Most control knobs are push-fit; pull straight off the control shaft and press the new knob onto the splined shaft until fully seated.
• Do not force or hammer the knob onto the shaft; verify alignment of the indicator with the control setting.

This infinite switch controls the heat level of an electric cooktop surface burner, restoring variable temperature control for cooking. It replaces a failed or erratic burner control to help burners heat evenly and respond to the knob. What it does:

• Regulates current to a surface heating element so the burner cycles between power levels
• Restores adjustable heat when a burner stays on one setting, won't heat, or heats intermittently
• Replaces a worn or damaged control that causes inconsistent burner performance
• Works with the cooktop's control knob to provide stepped power levels for cooking

• One infinite switch assembly

• Disconnect power to the appliance at the breaker before servicing
• Match this part to the existing switch by part number and terminal layout before installation
• Handle terminals and wiring carefully; secure connectors fully to prevent loose connections

2100W. Size: 8 inch. Location: Right front.

The 6 Inch Small Surface Element is an OEM part for Whirlpool electric ranges and cooktops. This component is essential for providing consistent, controlled heat to cookware on the stovetop.

Symptoms of a bad 6 Inch Small Surface Element include:

• Lack of heat production, with the element failing to warm up at all.
• Inconsistent heating, where the element may fluctuate in temperature or only partially heat.
• Visible damage such as blistering, bubbling, or cracks on the element's surface.
• A tripped circuit breaker when the element is turned on, indicating a short.

Causes of a bad surface element can include prolonged use leading to element burnout, electrical faults such as faulty wiring or internal failures, and physical damage from impact or heavy cookware being dropped on the element.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

8-inch element is part number WP660533.

Size: 10-24X5/16-NI

This conduit is a protective sleeve that routes and shields appliance wiring to help prevent chafing and abrasion. It keeps wires organized and reduces the risk of shorting or electrical damage in tight areas. What it does:

• Protects wiring from wear where wires pass through openings or near moving parts
• Helps prevent short circuits caused by chafed or pinched insulation
• Reduces vibration-related wire damage and keeps harnesses neatly routed
• Can address symptoms like intermittent electrical issues, visible wire abrasion, or burning/plastic odors near wiring

• One conduit

• Disconnect power to the appliance before inspecting or replacing wiring components
• Verify correct conduit length and orientation before securing; do not force or kink the sleeve
• Use existing clips/fasteners or manufacturer-recommended retainers to secure the conduit
• If wires show damage, replace the wiring harness rather than relying on the conduit alone
