Parts for Thermador SGCS304RW: 04 - Gas And Electric Component Parts

Brass nut secures the jet holder assembly on gas ranges and cooktops. Replace if stripped, corroded, or damaged during burner maintenance or repair.

Mounting bracket that secures double burner assemblies to your gas cooktop frame. Replace if cracked, bent, or missing to properly support burner units.

Secures the burner orifice in position to deliver the correct gas jet size for your 12,500 BTU natural gas burner. Replace if cracked, broken, or missing.

Jet holder with nut for gas cooktops and ranges. Holds the orifice that controls gas flow to each burner. Replace if cracked, corroded, or damaged.

Gas supply tube for cooktops. Connects gas source to burner assembly. Replace if cracked, kinked, damaged, or leaking to restore safe gas flow.

Replacement gas tubing assembly that routes fuel between the valve and burner manifold. Needed when original tubing is damaged, cracked, or leaking.

Burner won't light or has no gas flow? This top burner valve controls gas to individual burners. Moderate DIY repair with basic tools needed.

This is a redesigned kit. It is strongly recommended to have a certified Thermador technician install this kit as some modifications may be necessary.

Protective cover for the potentiometer switch on your gas cooktop. Installs over the control shaft to maintain knob alignment. Replace if cracked or missing.

Protective cover for the potentiometer switch on your cooktop. Replaces cracked, broken, or missing covers to restore a clean, finished appearance.

Burner won't spark or ignite? This spark switch signals the ignition module to light gas burners. Common DIY repair with basic tools, 15-30 minutes.

Fixes burners that won't ignite or spark continuously. This spark module generates the high-voltage needed for gas ignition. DIY repair, 1-2 hours.

Cooktop won't power on or has intermittent electrical issues? This terminal block with strain relief connects power supply wiring to your appliance.

This part has been discontinued by the manufacturer and is no longer available.

Replacement power cord for gas cooktops. Connects your cooktop to the electrical outlet. Replace if cord is frayed, damaged, or missing for safe operation.

This heat shield protects surrounding components from oven or cooktop heat, helping prevent damage and maintain safe operation. It's a direct-fit replacement that restores proper heat deflection in compatible Bosch units. What it does:

• Deflects and disperses heat away from nearby panels, wiring, and components
• Helps stop heat-related discoloration, warping, or premature component failure
• Restores original clearance and airflow paths behind panels or under cooktops
• Useful when a bent, corroded, or missing shield is causing contact or heat contact symptoms

• One replacement heat shield

• Disconnect power (and gas if applicable) before servicing the appliance
• Handle carefully — edges may be sharp; wear gloves and eye protection
• Use existing mounting points and hardware unless damaged; do not force or bend the shield to fit
