Parts for Jenn-Air JGRP648HM05: Burner Box, Grate, And Grill Parts

This speaker module provides audible tones and chimes used by the appliance to signal cycle progress and user alerts. It restores clear sound feedback so you can hear cycle completion, alerts, and error tones. What it does:

• Produces the appliance's audible chimes, beeps, and alert tones
• Signals cycle completion and user prompts with clear sound
• Helps indicate error codes and status changes through audible alerts
• Interfaces with the main control to provide user feedback

• Disconnect power to the appliance before servicing to avoid electrical shock
• Handle the module and wiring harness carefully; avoid static discharge and bent pins
• Reconnect the wiring harness fully and secure the module in its mounting location
• Test the appliance after installation to ensure audible tones function correctly

This replacement screw secures appliance panels and components so they stay tight and aligned during use. Replacing a missing or damaged screw restores a solid fit and helps eliminate rattles, loose trim, or shifting parts.

• Fastens brackets, panels, trim, or components to the appliance chassis
• Helps correct loose or missing hardware after vibration or service
• Replaces stripped, rusted, or broken screws
• Can reduce rattling noises or misaligned parts caused by missing fasteners

• Disconnect power; for gas appliances, also shut off the gas supply
• Support the part being fastened; start threads by hand to avoid cross-threading
• Use the correct driver size; tighten snugly without overtightening
• Replace hardware with the exact part number to ensure proper fit

This heater deflector directs heated air inside the dryer and protects nearby components from excessive heat, helping maintain proper airflow and reduce wear on internal parts. What it does:

• Shields the dryer cabinet and nearby components from direct heater/element heat
• Helps channel heated air for more even drying performance
• Can prevent heat-related damage that leads to component failure
• Common symptoms: burning or metallic smell, uneven drying, or visible heat damage near the heater area

• Disconnect power (and gas, if applicable) before beginning any repair
• Accessing this part usually requires removing the dryer cabinet or rear panel; follow your model's service instructions
• Handle carefully to avoid bending the deflector; install with original fasteners and correct orientation
• If you see damaged insulation or other heat-damaged parts, inspect and replace those items as needed

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This main wiring harness connects an appliance's control and power components, restoring reliable electrical connections for normal operation. It routes and links multiple wires into a single plug-and-play assembly to replace damaged or worn wiring. What it does:

• Carries power and signals between control board, motors, switches and sensors
• Replaces frayed, melted or broken wiring that can cause intermittent operation
• Helps resolve symptoms like no power to components, controls not responding, or appliances that won't start
• Restores factory routing and connector fit for safe, reliable connections

• One complete wire harness assembly as pictured

• Disconnect all power (unplug or shut off breaker) before starting any repair
• Match connector shapes and pin counts; do not force connectors together
• Route harness away from sharp edges, moving parts and high-heat areas; secure with existing clips or ties

This yellow wire electrode connects the broil ignitor to the oven's ignition system so the broil burner can spark and light reliably. Replaces a damaged or brittle ignitor lead to restore consistent broil operation. What it does:

• Transfers ignition spark/current from the control to the broil ignitor so the broil burner can light
• Commonly used when broil fails to ignite, sparks are intermittent, or wire insulation is cracked or burned
• Serves as the low-voltage lead between the oven control/igniter and the broil element/ignitor assembly

• One yellow wire electrode (single lead) as pictured

• Disconnect power (and gas supply where applicable) before inspecting or replacing any ignition components
• Handle the electrode tip and connector carefully to avoid damage to the ceramic/insulator
• Route and secure the wire away from hot surfaces and moving parts; replace any damaged clips or insulation

Screws for range anti tip bracket: WP3801F656-51. Includes 2 screws.
