Parts for Kitchenaid KCGD506GSS00: 04 - Burner Box Parts

This replacement drip tray catches and channels excess water beneath the appliance to help prevent puddles and floor damage. It restores the original drain path so condensate and minor leaks drain safely away. What it does:

• Collects and directs water away from the appliance base to prevent pooling on the floor
• Helps contain leaks from defrost or drain systems to limit damage to surrounding areas
• Can reduce musty odors and water stains caused by trapped moisture
• Fits into the appliance base to restore original water collection and drainage

• One drip tray

• Disconnect power to the appliance before servicing
• Remove lower access panels or kickplate as needed to access the tray
• Align the tray with the chassis rails or mounting tabs and slide or snap into place
• Inspect surrounding seals and drain paths; if you find corrosion or other damage, replace those parts as needed.

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This is the spark ignition module for gas cooktops and ranges. It generates the high-voltage pulses that light the surface burners, restoring consistent ignition when multiple burners won't spark or there's no clicking when a knob is turned. What it does:

• Sends high-voltage pulses to the surface igniters when a burner switch is turned on
• Distributes spark to ignite gas at the burners
• Failure may cause no spark at any burners, weak or intermittent sparking on several burners, or burners that only light with a match

• One spark module

• Disconnect power and shut off gas supply before servicing
• Access location varies by model
• Move wires over one at a time to maintain correct connections
• Secure the module and test all burners for proper spark before reassembly

• If only one burner won't spark while others work, check that burner's igniter electrode and the switch harness before replacing the module.

This gas burner valve controls the flow of fuel to a cooktop burner, restoring proper flame adjustment and heat control for safe, consistent cooking. Replacement helps resolve control and ignition issues. What it does:

• Regulates gas flow to a single surface burner so you can adjust flame size
• Enables reliable ignition and stable flame during normal use
• Stops uncontrolled high or low flames caused by a failing valve
• Helps address symptoms like burners that won't light, won't stay lit, or have poor flame control

• 1 burner valve

• Turn off the appliance, shut off the gas supply, and disconnect power before beginning work
• Only install if this exact part matches your model's parts list; follow the manufacturer service instructions
• Check all gas fittings for leaks after installation and before returning appliance to service

This burner valve controls gas flow to a single cooktop burner so the burner lights and holds a steady flame. It restores proper burner operation and flame adjustment when the valve is worn or faulty. What it does:

• Regulates gas flow to one surface burner for ignition and flame control
• Helps stop issues like weak flame, burner that won't stay lit, or no flame at all
• Replaces a worn or leaky valve to restore safe, consistent operation
• Works with the range's existing gas and control fittings when correctly matched

• One burner valve

• Turn off gas supply and disconnect power before starting any repair
• Only install if the part number and valve style match your appliance's service diagram
• Inspect and tighten all gas fittings; test carefully for leaks after installation

The Gas Cooktop Burner Valve is an OEM part for Whirlpool gas ranges. It is responsible for controlling the flow of gas to individual cooktop burner flames.

Symptoms of a bad valve include:

• Inability to light or adjust burner flames
• Flames that are too low, too high, or unstable
• Gas smell when the burner is switched on without ignition

Causes of a faulty valve stem from issues like cracks, leaks, or worn components due to regular use over time. Accidental damage could also cause problems for the valve.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore gas ranges.

This gas pressure regulator controls and stabilizes incoming fuel supply to the appliance's burner system, helping ensure consistent flames and reliable operation. Replace it if pressure is unstable or burners/oven won't heat or ignite correctly. What it does:

• Reduces household gas supply to the appliance-rated pressure for proper burner performance
• Maintains steady pressure as burner demand changes to prevent over/under-firing
• Helps prevent yellow, lifting, or flickering flames and sooting caused by pressure issues

• 1 gas pressure regulator

• Shut off gas supply and disconnect power before servicing
• Observe flow-direction arrow on the regulator body; install between supply and appliance manifold
• Use approved gas-rated thread sealant on threaded connections; do not overtighten
• After installation, check all joints for leaks with a non-corrosive leak-detection solution; correct any leaks before use

This switch seal is a replacement gasket that helps keep moisture and debris away from the appliance's door/control switch, protecting the switch assembly and helping restore reliable door detection and operation. What it does:

• Seals the area around the door/control switch to block water, lint, and grime.
• Helps prevent intermittent trips or failures caused by moisture or foreign material contacting the switch.
• Promotes consistent switch actuation and can extend the service life of the switch assembly.
• Useful when the existing seal is cracked, torn, flattened, or missing.

• Disconnect power before servicing to avoid electrical shock.
• Access typically requires removing the door trim or control panel—follow your model's service instructions.
• Inspect the switch and surrounding area for damage or corrosion and clean before installing the new seal.

The cooktop Switch Assy-HARNESS,VALVE,GAS is an OEM component specifically designed for Whirlpool cooktops. This assembly includes the switch harness, valve, and all necessary gas components to control burner ignition and flame level adjustment.

Symptoms of a bad assembly include:

• Inability to ignite or control burner flames
• Erratic or intermittent flame levels
• Gas leaks around connections or components
• Loose, damaged, or faulty wiring

Over time, components like connectors, wires, valves and switches are susceptible to wear and tear that can diminish performance or cause safety issues.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This is a direct-replacement screw used to secure appliance panels, brackets and other small components. It restores proper fastening where the original screw is missing, stripped, or corroded to help reduce rattles and looseness. What it does

• Fastens panels, trim, brackets and similar small appliance parts
• Restores a secure connection when the original fastener is missing or damaged
• Helps stop vibration-related rattling and movement of mounted components
• Matches the original mounting point to maintain proper alignment

• Disconnect power and water before beginning any repair
• Use the correct screwdriver or bit to avoid stripping the head
• Thread carefully and do not overtighten to prevent damage to the mating part
• Replace only with the same part number or equivalent for proper fit
