Parts for Lg LNXC23766D/01: Drawers & Vegetable Room Parts

This Air Filter Assembly helps reduce odors and airborne particles inside the appliance for fresher-smelling air and improved interior environment. Designed as a direct-replacement filter assembly matching the OEM design. What it does:

• Captures odors and helps reduce airborne contaminants that cause unpleasant smells
• Restores the appliance's built-in air-cleaning function when the original filter is worn or missing
• Commonly replaced when you notice persistent odors or reduced air freshness inside the appliance
• Works as part of the appliance's ventilation/air circulation system to maintain interior air quality

• One complete air filter assembly (as shown)

• Refer to your appliance manual for the correct access panel and replacement procedure
• Replace with the appliance powered off and follow basic electrical safety if removal requires accessing wiring
• Verify correct orientation and secure mounting so the filter seals properly in the housing
• Dispose of the old filter per local regulations

This cover assembly is a molded exterior panel that shields and finishes the appliance. Replacing a cracked or missing cover restores proper fit and protection for internal components, and keeps the unit looking the way it should.

• Protects internal components by covering and sealing the opening
• Helps maintain proper alignment with adjacent parts and trim
• Reduces gaps where dust and debris can enter
• Common signs of failure: cracks, broken tabs, loose fit, rattling, or visible damage

• Disconnect power; for appliances with water connections, shut off the water supply
• Note screw locations and take photos before removal for reference
• Transfer any clips, gaskets, badges, or lenses from the original as needed
• Align tabs and mounting holes; snug fasteners without overtightening and confirm clearances before restoring power

This shelf holder is a replacement support bracket that secures a refrigerator shelf in place so glass or wire shelves stay level and stable. Restores proper shelf alignment and helps keep stored items from shifting. What it does:

• Supports and secures a refrigerator shelf to the cabinet or shelf frame
• Prevents shelves from sagging or sliding out during normal use
• Commonly replaced when the original holder is cracked, broken, or missing
• Helps restore correct shelf positioning and safe storage of food

• High-level swap: remove shelf, unclip or unscrew the old holder, then snap or fasten the new holder into place
• Work with shelves emptied to avoid dropped items or damage
• No specialized tools usually required; use basic screwdrivers if fasteners are present

A replacement TV cover assembly that restores the rear cabinet housing and protects internal components from dust and impact. Replaces a cracked, warped, or missing rear panel to help maintain safe operation and appearance. What it does:

• Replaces damaged or missing rear cabinet housing on the TV
• Protects internal boards, wiring, and vents from dust and debris
• Restores proper fit and alignment for back-panel-mounted components
• Helps resolve rattling or loose-back symptoms caused by a broken cover

• Installation requires removing the TV stand and disconnecting power before starting.
• Handle with care to avoid scratching the bezel or damaging internal connections.
• Keep screws and mounting clips in a safe place; use the OEM fasteners for reassembly.

The Temperature Sensor is an OEM part for LG refrigerators. It monitors the internal temperature and sends this information to the control board, ensuring that the refrigerator maintains the correct temperature for optimal food preservation.

Over time, temperature sensors can fail due to electrical issues, exposure to moisture, or wear and tear from continuous use.

Symptoms of a bad temperature sensor include:

• Inaccurate temperature readings
• The refrigerator or freezer being too warm or too cold
• The refrigerator running constantly or not running at all
• Error codes displayed on the control panel

This OEM LG part is also compatible with Sears/Kenmore models.

This ferrite magnet is a replacement magnetic element used in compatible appliance assemblies to help secure components and maintain proper alignment. It restores magnetic retention and reduces shifting or misalignment during operation. What it does:

• Provides magnetic retention for panels, assemblies or components that rely on ferrite magnets
• Helps maintain proper alignment and secure closure where magnets are used
• Can reduce noise and vibration related to loose magnetic components
• Useful when a brittle, cracked or weak magnet no longer holds parts in place

• Disconnect power and follow the appliance manufacturer's safety instructions before servicing
• Handle the magnet carefully; ferrite material is brittle and can chip or shatter if dropped or struck
• Keep magnets away from sensitive electronics and credit cards; avoid pinching fingers between strong magnets
• If the original magnet is bonded or embedded, some adhesive or light trim may be needed for proper fit.

This hinge cover assembly replaces a damaged or missing trim piece that protects and conceals the appliance hinge, restoring a clean appearance and preventing fabric or items from catching. It's a direct-fit cosmetic and protective cover. What it does:

• Covers and protects the hinge area to prevent snagging and wear on clothing or items
• Conceals hinge mechanisms for a finished appearance
• Helps keep dirt and debris out of the hinge area
• Restores proper alignment of exterior trim when the original is cracked or broken

• One hinge cover assembly

• Disconnect power (and gas/water if applicable) before starting any repair
• Typical installation requires removing the outer panel or door access screws to reach the hinge; keep track of fasteners
• Handle plastic trim carefully to avoid cracking; use non-marring tools where possible

This name plate is the exterior emblem that mounts to the appliance's front panel. It replaces a missing, cracked, or faded badge to restore a clean, factory look and cover the designated trim area.

• Attaches to the outer panel to display brand/series identification
• Restores a finished appearance where the original emblem sits
• Direct replacement for a lost, damaged, or worn badge
• Typical symptoms: missing emblem, loose or broken tabs, peeling, or discoloration

• Disconnect power before servicing the appliance
• Carefully remove the old emblem; release any tabs from behind or peel away remaining adhesive
• Clean and dry the mounting surface; remove all residue for best fit
• Align with the recess/holes and press evenly until fully seated

This refrigerator door gasket seals the door to the cabinet to keep cold air in and humid air out. Replacing a worn or torn seal restores proper temperatures, reduces frost and condensation, and helps the unit run efficiently.

• Creates an airtight seal between the door and cabinet perimeter
• Helps maintain internal temperature stability and energy efficiency
• Reduces frost/ice buildup and moisture around the door opening
• Common symptoms: visible tears or warping, gaps, door not sealing, warm spots, frost or condensation near the door

• Unplug the appliance before servicing
• Let the new gasket relax flat at room temperature, or gently warm it to make it more pliable
• Clean the sealing surfaces; seat corners first, then work evenly along the sides
• Close the door and check for uniform contact all around; adjust as needed for a consistent seal

This refrigerator door gasket assembly restores a tight, even seal around the door. A proper seal keeps cold air in and moisture out, helping maintain temperature, reduce frost and condensation, and prevent warm spots around the perimeter.

• Forms a continuous seal between the door and cabinet to prevent air leaks
• Helps maintain stable internal temperature and humidity
• Reduces frost/ice and condensation near the door area
• Replace if the gasket is torn, cracked, deformed, or won't sit flat
• Symptoms include gaps around the door, moisture on the gasket, frost buildup, or a door that won't close/seal properly

• Unplug the refrigerator before servicing
• Let the new gasket relax; use warm water or low heat to remove shipping creases
• Insert the gasket lip fully into the door's channel, starting at the corners, then work along the sides
• After installation, close the door and check for uniform contact all around; adjust the gasket as needed

This rubber door stopper cushions and limits appliance door movement to prevent hard closing, reduce noise, and protect the cabinet and door edge from damage. Designed as a direct-fit replacement for the original factory bumper. What it does:

• Absorbs impact when the door closes to reduce slamming and rattling
• Keeps the door aligned and prevents metal-on-metal contact or chipping
• Helps maintain door seal integrity by stabilizing closing position
• Commonly replaced when worn, torn, or missing and causing noise or misalignment

• One rubber door stopper

• Basic push-fit replacement—remove the old bumper and press the new stopper into the mounting hole
• Inspect the mounting boss for damage; replace the housing if the mounting area is broken
• Disconnect power or ensure appliance is off and stable before working on doors for safety
• No special tools typically required; use a flat tool for leverage if the old bumper is stuck

This front plate assembly is the exterior trim piece that restores the appliance's front surface and protects internal components from dirt and damage. It improves appearance and helps maintain a proper seal and alignment. What it does:

• Replaces a cracked, dented, or missing front plate to restore the unit's exterior finish
• Shields controls and internal components from dust, spills, and everyday wear
• Helps maintain proper fit and alignment of adjacent panels and trim
• Returns the appliance to a finished, factory appearance

• Disconnect power to the appliance before beginning any repair.
• Installation typically requires removal of adjacent trim or the control bezel; keep all screws and fasteners for reinstallation.
• Handle the plate carefully to avoid scratching the finish during installation.

This refrigerator door basket assembly replaces a cracked or missing door bin to restore secure storage for bottles, jars, and condiments. It mounts to the door liner to keep items organized and easy to reach. What it does:

• Attaches to the door liner to provide shelf-style storage
• Restores lost capacity and organization when a bin is broken or missing
• Helps keep beverages and condiments stable during door movement
• Common symptoms: cracked plastic, broken locking tabs, bin won't stay seated, items falling, door interference

• 1 door basket assembly

• Unplug the refrigerator and remove items from the affected bin area
• Lift the old bin straight up to disengage the tabs, then pull it out
• Align the new bin with the door liner mounts and press down until fully seated
• Verify the door closes freely and avoid overloading the new bin

This door stopper cushions and limits the appliance door's movement to help prevent slamming, misalignment, and wear. A small replacement part that restores smoother, quieter door operation. What it does:

• Absorbs impact when the door closes to reduce noise and shock
• Keeps the door from over-travel that can cause misalignment or rubbing
• Helps the door latch and seal properly by stabilizing movement
• Stops rattling or binding caused by a worn or broken stopper

• Disconnect power to the appliance before starting any repair
• Access may require opening or removing the door or a trim panel; use basic hand tools
• Remove the old stopper and install the replacement in the same position and orientation

This Door Stopper is the hinge-mounted stop that limits your refrigerator door's swing. Replacing a worn or broken stopper restores smooth, controlled movement and helps protect hinges and nearby cabinetry from overextension. What it does:

• Controls the door opening angle on the hinge to prevent overextending
• Helps maintain door alignment for a reliable seal and smooth closing
• Reduces clunking or clicking at the hinge caused by a worn stop
• Replace if the door swings too far, binds, won't close smoothly, or the stopper is cracked/missing

• 1 door stopper

• Disconnect power and support the door to relieve hinge load before service
• Remove hinge cover/fasteners as needed and note the old stopper's orientation
• Install the new stopper on the hinge/bracket, reassemble, and check door travel
• Verify the door seals fully and opens within the normal range

This door basket is the replacement storage basket that holds silverware and small items in the dishwasher door, restoring organized loading and secure drying. It keeps utensils separated and prevents shifting during wash cycles. What it does:

• Holds forks, knives, spoons and other small utensils in the dishwasher door for safer, more organized washing
• Keeps items separated to improve wash and rinse contact
• Secures small items to prevent them from falling into the tub or blocking spray arms
• Replaces broken, cracked, warped, or missing baskets that allow utensils to shift or fall

• One door/cutlery basket

• Disconnect power to the appliance or turn off the circuit breaker before servicing
• Remove the door inner panel or access clips per the appliance manual as needed—follow OEM instructions
• Handle sharp utensils and plastic parts carefully to avoid cuts or damage

This center hinge assembly replaces the middle pivot that supports and guides a refrigerator door, restoring smooth opening and proper door alignment. It helps reduce sagging, misalignment, and uneven closing for standard top/bottom door configurations. What it does:

• Re-establishes the central pivot point so the door seals and lines up correctly
• Reduces rubbing, scraping, and noisy movement at the center hinge
• Helps prevent gaps that can cause cooling loss or uneven temperatures
• Provides the structural support needed for proper door swing and closure

• Disconnect power and empty/support the door before removing hinges to avoid damage or injury
• Support the door weight; two people are recommended for safe removal and reinstallation
• Follow OEM instructions for hinge orientation and torque on fasteners; confirm seal alignment after installation
• Use appropriate tools and replacement fasteners if original hardware is worn or damaged

The Spanner Wrench is an OEM replacement part for LG refrigerators. This tool allows you to adjust the door hinges to ensure the doors are level and aligned properly. A well-aligned door is crucial for maintaining the internal temperature and efficiency of the refrigerator, preventing energy loss and ensuring food is stored under optimal conditions.

Symptoms that you might need to adjust the door hinges and potentially need this wrench include:

• Doors not closing properly or sealing tightly
• Visible gaps between the door and the main body of the refrigerator
• The refrigerator tilting or not sitting level

This spanner wrench is also compatible with some Sears/Kenmore refrigerators.

This hinge cover assembly replaces a damaged or missing trim piece that protects and conceals the appliance hinge, restoring a clean appearance and preventing fabric or items from catching. It's a direct-fit cosmetic and protective cover. What it does:

• Covers and protects the hinge area to prevent snagging and wear on clothing or items
• Conceals hinge mechanisms for a finished appearance
• Helps keep dirt and debris out of the hinge area
• Restores proper alignment of exterior trim when the original is cracked or broken

• One hinge cover assembly

• Disconnect power (and gas/water if applicable) before starting any repair
• Typical installation requires removing the outer panel or door access screws to reach the hinge; keep track of fasteners
• Handle plastic trim carefully to avoid cracking; use non-marring tools where possible

This upper hinge assembly secures and guides the appliance door at the top, restoring correct door alignment and smooth opening. Replace a worn or damaged hinge to stop door sagging and improve sealing and operation. What it does:

• Supports the top of the door and keeps it aligned on the cabinet
• Allows the door to pivot smoothly during opening and closing
• Prevents or corrects door sag, rubbing, or uneven gaps that can affect sealing
• Stops grinding, squeaking, or binding caused by a damaged hinge

• One upper hinge assembly

• Unplug the appliance or disconnect power before starting work
• Support the door while removing and installing the hinge to prevent dropping or injury
• Use basic hand tools; follow the appliance service manual for torque and alignment steps

This upper hinge assembly secures and allows the refrigerator door to pivot smoothly, restoring proper door alignment and sealing. It replaces worn or damaged upper hinge hardware to stop sagging or uneven door movement. What it does:

• Supports the top of the refrigerator door and provides the pivot point for opening and closing
• Restores proper door alignment and helps the door form a tight seal when closed
• Stops symptoms such as a sagging or tilted door, door rubbing, or uneven movement
• Durable metal/plastic construction resists wear from regular use

• One upper hinge assembly

• Unplug the appliance or disconnect power before starting work
• Support the door before removing the hinge to prevent it from falling
• Reuse any original screws/fasteners only if undamaged; replace damaged fasteners

This lever holder is the replacement mounting bracket that secures the door lever so the microwave door operates smoothly and reliably. It restores proper lever alignment to help the door latch and release as intended. What it does:

• Secures the door lever assembly so the door can latch and release properly
• Keeps the lever aligned to prevent binding, sticking, or loose movement
• Helps restore normal door operation and user access to the oven cavity
• Common symptom: door feels loose, lever moves freely, or door will not latch

• Disconnect power before beginning any repair to avoid shock or injury
• Remove the outer cabinet or door trim only as needed to access the lever area
• Handle door components and glass carefully to avoid damage or injury

This replacement spring provides the tension for a door hinge, helping the door open smoothly and stay closed for a proper seal and consistent appliance performance.

• Applies controlled tension to the hinge mechanism for smooth door movement
• Helps the door stay closed and aligned against the gasket
• Worn or broken spring symptoms can include the door dropping open, not staying closed, an uneven gap, or squeaking/binding at the hinge
• Restores normal feel and operation to the door

• Disconnect power and allow the appliance to cool completely before servicing
• Support the door; removal of the door or hinge arm may be required
• Use caution—hinge springs are under significant tension; wear gloves and eye protection
• Replacing both springs together helps maintain balanced tension

This button assembly replaces the user-facing control buttons on the appliance's control panel, restoring tactile input and reliable selection of cycles and options. It provides a direct fit for the original control interface. What it does:

• Replaces worn, cracked, or non-responsive control panel buttons
• Restores tactile feel so selections register properly
• Helps resolve intermittent or unresponsive button presses
• Maintains proper alignment and spacing of control inputs

• Disconnect power and/or unplug the appliance before starting repairs
• Remove the front console or control bezel to access the button assembly; keep screws and small parts organized
• Handle the control board and ribbon/connector gently to avoid damage and electrostatic discharge

The Compressor is an OEM component specifically designed for LG refrigerators. Located inside the refrigerator compartment, the compressor pressurizes and circulates refrigerant through the cooling system. Through precisely timed operation, the compressor maintains optimal freshness.

Symptoms of a bad compressor include:

• Elevated interior temperatures failing to efficiently chill
• Loud buzzing or vibrating noises coming from inside the walls
• Frost buildup indicating ineffective cooling cycles
• Complete cooling system failure leaving foods unpreserved

Causes involve refrigerant leaks, blocked airflow to the compressor, or simply wear over tens of thousands of hours of use breaking down moving components.

This OEM LG part is also compatible with some refrigerator models from Kenmore and Sears. Replace to restore reliable, long-term temperature control keeping contents at peak freshness.

This overload protector is a compressor safety device that helps stop the compressor if it draws too much current or overheats, preventing damage and helping the refrigerator system run safely. What it does:

• Interrupts compressor power during excessive current draw or overheating to protect the compressor motor
• Can prevent short cycling and repeated restart attempts that damage the compressor
• Commonly replaced when compressor hums but will not start, or when the appliance stops cooling due to compressor protection
• Works as part of the compressor start/protection assembly alongside the start relay and capacitor

• Disconnect power to the appliance before accessing the compressor or electrical components
• Handle terminals carefully and reconnect to the matching terminals only; do not modify leads
• Verify the part number against the existing component before installation

This PTC thermistor assembly monitors internal temperature and sends a temperature signal to the appliance control so the unit can regulate cooling and defrost cycles. It replaces a failed or intermittent temperature sensor. What it does:

• Detects temperature changes and provides a stable resistance signal to the control board
• Helps the control maintain proper cooling and defrost timing
• Commonly linked to symptoms like inconsistent cooling, excessive frost buildup, or erratic temperature readings
• Designed as a direct-replacement harness and sensor assembly for compatible units

• Disconnect power to the appliance before installing to avoid shock or damage
• Handle the sensor tip and wiring harness gently; avoid pulling on wires
• Verify the part number on the old assembly matches this replacement before installing

A small retaining pin used to secure moving parts and keep components aligned for smooth operation. Replacing a worn or broken common pin can stop rattling and restore proper fit between linked parts. What it does:

• Holds or aligns two parts together so they move correctly and stay in position
• Helps prevent rattling, looseness, or parts slipping out of place
• Works as a simple mechanical fastener—no electronics involved

• One common pin

• Disconnect power to the appliance before beginning any service
• Keep track of small parts; lay out components in order to aid reassembly
• May require removal of trim or a hinge/retainer to access the pin—use basic hand tools
• If the pin is difficult to seat, do not force; inspect mating parts for damage

This cabinet roller supports the refrigerator and lets the unit roll in and out of place for cleaning or service. Replace a worn or broken roller to restore smooth movement and help keep the appliance properly positioned.

• Supports the base of the refrigerator and enables rolling movement
• Helps with safe positioning and service access without dragging
• Common failure signs: appliance is hard to move, scraping or rolling noises, a flat-spotted/cracked wheel, or a wheel that won't turn
• Replace when the roller is damaged, seized, or missing

• Disconnect power and shut off water supply; protect flooring before moving the appliance
• With help, pull the refrigerator forward and safely support it to access the roller
• Remove mounting fasteners, install the new roller, and reuse original hardware
• Confirm level and smooth movement before returning the unit to its location

This compressor damper is a vibration-isolating mount that sits between the sealed-system compressor and the chassis. It cushions the compressor to reduce noise, limit vibration transfer, and help keep refrigerant lines from being stressed.

• Isolates the compressor from the frame to absorb start/stop shock and vibration
• Helps reduce humming, rattling, or buzzing from the back/bottom of the appliance
• Replaces a damper that's cracked, flattened, hardened, or missing
• Can help if the compressor rocks or the unit vibrates excessively

• Disconnect power and pull the unit forward for access; remove rear/service panel if present
• Support the compressor to relieve load on the mounts before removing fasteners
• Match orientation; transfer any sleeves/spacers from the old damper to the new one
• Ensure the compressor sits level and that tubing is not strained before restoring power

This fan guide directs airflow from the blower/fan assembly to improve cooling and airflow routing in the appliance. Replaces a cracked or missing guide to restore proper airflow and reduce noise from misdirected air. What it does:

• Channels air from the fan/blower to the correct vents or components
• Helps maintain even cooling and prevents hot spots near electronics or food compartments
• Reduces vibration-related rattles by securing the fan's airflow path
• Common symptom: airflow is weak, noisy, or misdirected when the guide is damaged or missing

• One fan guide

• High-level replacement — remove access panels and unplug appliance before starting
• Confirm correct orientation and secure mounting tabs/screws; avoid forcing plastic clips
• Use gloves to protect hands from sharp sheet metal edges inside the cabinet
• If airflow or noise persists after installation, inspect fan/blower and motor assembly for damage

This drip tray catches and channels water runoff inside the appliance to help prevent pooling and minor leaks. It's a direct-fit replacement listed by the manufacturer and sold as the single tray used in the unit. What it does

• Collects condensate or defrost water and directs it to the drain area to prevent pooling.
• Helps stop water from dripping onto lower drawers, shelves or the floor.
• Commonly replaces a cracked, warped or missing tray that causes visible leaks or water buildup.
• Fits into the appliance's lower compartment where the original tray sat.

• Unplug the appliance or disconnect power before servicing.
• Remove any obstructing drawers or shelves to access the tray location; handle glass shelves carefully.
• Lift out the old tray and set the new tray into the same position; no special tools typically required.

The Fan Guide Assembly is an OEM component specifically designed for LG refrigerators equipped with rear evaporator fans. This assembly guides proper airflow within the refrigerator compartment.

Symptoms of a bad fan guide assembly include:

• Development of warm or cool spots inside fridge surfaces
• Excessive frost or moisture buildup at specific locations
• Reduced temperature fluctuation stability
• Abnormally loud fan operation sounds

Causes of failure can be damage allowing fan blade strikes, cracks reducing structural integrity over time, or accumulation of dust clogging air passages.

Replace yours today with this genuine OEM LG assembly to maintain optimized cooling throughout storage areas. Smooth, balanced airflow preserves food freshness evenly. This replacement part is compatible with Frigidaire, GE, and Samsung models for factory fit and function. Proper air distribution helps maintain energy efficiency.

This cover assembly protects the machine components and helps keep internal machinery free of debris and accessible for repair. It provides a durable barrier that helps extend component life and maintains safe operation. What it does:

• Shields motors, belts and internal linkages from dust and lint that can cause wear
• Helps contain moving parts to reduce pinch or contact hazards during normal use
• Maintains proper component alignment by providing a stable mounting surface
• Commonly replaced when cracked, warped, missing fasteners, or damaged from impact

• One cover assembly as shown

• Disconnect power before attempting service
• Handle gently to avoid cracking plastic tabs; inspect mounting clips and screws for damage
• Reuse original fasteners only if undamaged; replace any stripped screws or broken clips

This small stopper installs in the refrigerator to limit the travel of a moving component and keep it securely in place. Replacing a broken or missing stopper prevents over-extension and helps maintain smooth, aligned operation.

• Limits the range of motion for a door, bin, or drawer to prevent over-opening or accidental removal
• Helps keep interior components aligned and operating smoothly
• Replace if cracked, missing, or deformed
• Common symptoms: drawer or bin slides out too far, door swings past normal range, or a broken plastic stop is found

• Disconnect power before servicing; remove or support the affected bin/drawer/door
• Note the old stopper's orientation and location before removal
• Transfer and reuse any original screws or clips if applicable
• Snap or fasten the new stopper in place and test for smooth movement

The Drier Assembly is an OEM part for LG refrigerators. This part removes moisture and contaminants from the refrigerant, ensuring the system operates efficiently and effectively. The drier assembly helps maintain the proper function of the compressor and other cooling components, contributing to the longevity and performance of the refrigerator.

Causes of a bad drier assembly can include clogs from debris, wear and tear over time, or contamination from moisture or refrigerant leaks.

Symptoms of a bad drier assembly include:

• The refrigerator not cooling properly
• Frost or ice buildup on the evaporator coils
• Increased noise from the compressor
• Reduced efficiency and higher energy consumption
• You should replace the drier assembly if it becomes faulty or damaged.

This OEM LG part is also compatible with select Sears/Kenmore models.

This holder is a small mounting bracket used to secure internal components in place, helping keep parts aligned and stable for reliable operation. It provides a direct, OEM-compatible replacement to restore proper fit and function. What it does

• Secures and supports nearby components to prevent shifting or vibration.
• Restores proper alignment where a worn or broken holder causes rattling or loose parts.
• Helps maintain normal operation by keeping assemblies seated correctly.
• Works behind panels or inside assemblies where a dedicated bracket is required.

• One holder/mounting bracket as shown.

• Installation generally requires removing the panel or access cover where the holder is located.
• Use proper fasteners shown in your appliance; replace any damaged screws or clips as needed.
• Disconnect power before servicing electrical appliances to reduce shock risk.

The SWITCH, MAGNET is an OEM part for LG refrigerators. It is a switch designed to function in conjunction with the magnetic door seal, indicating to the refrigerator when the door is open or closed. This allows the refrigerator to regulate temperatures properly based on door positioning.

Symptoms of a bad switch, magnet can include:

•  Temperature control issues, with the fridge struggling to maintain proper coolness levels
•  The fridge fails to switch to energy-saving modes when the door is closed
•  Lights not turning on or off correctly when the door is opened or closed

Replace yours today with this genuine OEM LG part to ensure consistent and reliable temperature control. This OEM LG part is also compatible with Sears/Kenmore.

The Dispenser Micro Switch is an OEM part for LG refrigerators. It is a component of the ice and water dispensing system, responsible for activating the dispenser when the lever is pressed.

Causes of a bad Dispenser Micro Switch can include mechanical wear from frequent use, failure due to moisture or debris affecting the switch’s contacts, or electrical faults that prevent proper signaling.

Symptoms of a bad Dispenser Micro Switch include:

• The dispenser not releasing ice or water when the lever is pressed.
• Continuous dispensing or dripping after the lever is released.
• Intermittent or no response from the dispenser controls.

This OEM LG part is also compatible with Sears/Kenmore.

This DC motor drives the refrigerator's circulation fan, moving air across the coils and through the compartments for steady, efficient cooling. Replacing a weak, noisy, or seized motor restores airflow and temperature stability. What it does:

• Converts DC power into rotation to spin the attached fan and promote airflow
• Supports efficient heat exchange for even compartment temperatures
• Common symptoms: fan not running or intermittent, loud humming/squealing/grinding, warm spots or frost buildup, longer run times
• Contributes to reduced ice production or error codes in some models

• 1 DC motor

• Disconnect power and wear cut-resistant gloves; internal panels may have sharp edges
• Access the motor behind the interior panel or rear service panel; note connector orientation and wire routing
• Transfer the fan blade, grommets, and any mounting hardware from the old motor if needed
• Seat the blade fully and verify it spins freely before reassembly and restoring power

The Temperature Sensor is an OEM part for LG refrigerators, designed to monitor and relay the temperature inside the refrigerator to the control board. This component ensures that your refrigerator maintains the correct temperature to keep your food fresh and safe to eat.

Over time, temperature sensors can fail or become less accurate due to wear and tear, environmental factors, or electrical issues. This can lead to problems such as the refrigerator cooling too much or not enough, resulting in food spoilage or excessive energy consumption.

Symptoms of a bad Temperature Sensor include:

• The refrigerator or freezer is too warm or too cold, despite setting adjustments
• Unusual fluctuations in temperature, indicating the sensor is not accurately detecting or communicating the internal temperature
• The refrigerator runs constantly or more frequently than normal, attempting to reach the desired temperature

This OEM LG part is also compatible with some Kenmore models.

The Ice Dispenser Door Motor is an OEM part for LG refrigerators. This motor is responsible for the operation of the ice dispenser door, controlling its opening and closing mechanism to allow ice to be dispensed without letting warm air into the freezer.

Symptoms of a bad Ice Dispenser Door Motor include:

• The dispenser door not opening or closing properly,
• Ice not being dispensed when activated,
• Unusual noises coming from the dispenser mechanism.

Causes of ice dispenser door motor failure can include electrical issues such as shorts or wiring problems, mechanical wear over time, or blockages that strain the motor.

This OEM LG part is also compatible with Sears/Kenmore.

This LED assembly restores backlight illumination for compatible LG displays, improving screen brightness and uniformity so images look clearer and easier to see. It replaces a worn or failed backlight strip. What it does:

• Provides the backlight illumination that lights the LCD panel
• Restores overall brightness and reduces dark or dim areas
• Can stop flickering or intermittent light if LEDs are failing
• Helps eliminate uneven lighting or bright/dark bands across the screen

• One LED assembly (single backlight strip) as shown

• Disconnect power and allow capacitors to discharge before starting
• Handle the LED strip and circuit board by the edges; avoid touching LED surfaces and PCB traces
• Keep track of screws and clips; test the display before fully reassembling

This Main PCB Power Control Board Assembly replaces the appliance's primary control board to restore proper power distribution and control of functions. It's the central electronic module that manages user inputs and system operations. What it does:

• Distributes power and coordinates operation of the appliance's components
• Interprets user commands from the control panel and routes signals to subsystems
• Helps prevent erratic operation caused by a failed or damaged control board
• Common symptoms: no power or intermittent power, unresponsive controls, or error codes related to main control faults

• Always disconnect power to the appliance before starting service
• Handle the board carefully; avoid static discharge and damage to connectors or components
• Inspect connectors and wiring for damage; replace or repair any faulty harnesses before installing

This PCB power control board assembly controls power and electronic functions for the appliance's control module, restoring reliable control signals and power distribution when the original board fails. What it does:

• Regulates and routes low-voltage power to the appliance control circuitry
• Provides the electronic interface for user controls and display functions
• Can stop erratic operation or unresponsive controls when the board is faulty
• When the appliance shows blank/partial display, fails to start, or throws control-related errors

• One PCB power control board assembly

• Disconnect power before inspecting or replacing the board to avoid shock or equipment damage
• Handle the PCB by its edges and avoid touching components to prevent static or oil damage
• Verify connector orientation and seating; do not force connectors or bend pins

This sub PCB assembly is an electronic control board that processes inputs and switches components, coordinating specific appliance functions. Replacing a failed board can restore normal operation and resolve dead controls, error codes, or intermittent, unpredictable behavior. What it does:

• Distributes and regulates control power and switches loads via onboard relays/triacs
• Interprets signals from sensors and the user interface to execute commands
• Coordinates timing and operation of related components per the appliance's program logic
• Failure may present as no power, won't start, unresponsive or flickering display, random beeps, or recurring error codes

• 1 sub PCB assembly

• Disconnect power to the appliance before servicing; verify no voltage is present
• Use ESD protection and handle the board by the edges
• Photograph wiring; transfer connectors one at a time and ensure they are fully seated
• Secure the board with existing fasteners/standoffs; perform any required reset or diagnostic per your model's service info

This foam gasket is a flexible seal strip that restores an airtight seal around the refrigerator/freezer cabinet, helping prevent air leaks and reduce frost buildup. It replaces worn or compressed foam seals for improved temperature control. What it does

• Seals gaps between cabinet surfaces to help keep cold air in and warm air out.
• Helps reduce frost or ice build-up caused by air infiltration.
• Can improve cooling efficiency and help maintain consistent temperatures.
• Common symptom: visible gaps, compressed foam, or recurring frost near the seal area.
• Common symptom: higher-than-normal run times or uneven cooling near the door/frame.

• One foam gasket (seal strip) as shown.

• Disconnect power to the appliance before starting any repair.
• Remove any trim or liners required to access the old gasket; handle foam carefully to avoid tearing.
• Install by aligning the gasket in the seal channel and pressing evenly into place; secure per manufacturer guidance.
• If adhesive or fasteners are used, use only manufacturer-recommended materials and follow safety instructions.

This AC motor powers the appliance's fan or blower to move air through the system. Replacing a worn motor restores proper airflow to support cooling/ventilation and protect internal components from overheating. What it does:

• Rotates the fan/blower to circulate air through the appliance
• Helps maintain proper temperatures and component cooling
• Common failure signs: fan won't start, starts then stalls, weak airflow, loud humming/grinding, overheating or safety shutoffs
• Often required when motor bearings seize or windings fail

• 1 AC motor

• Disconnect power and allow hot components to cool before servicing
• Note wire positions; transfer any brackets, grommets, or the fan blade from the original motor if reused
• Clear debris and restore power and verify smooth, quiet airflow

The Ice Maker Assembly Kit is an OEM part for LG refrigerators. It is responsible for producing and storing ice within the freezer compartment. The kit includes all necessary components to create ice, ensuring a steady supply for household needs.

Over time, the ice maker can become faulty due to various reasons. Causes of a bad ice maker assembly can include mineral build-up from hard water, wear and tear of moving parts, or electrical component failures. These issues can impair the ice maker's functionality, leading to inconsistent or no ice production.

Symptoms of a bad ice maker assembly include:

• The ice maker not producing ice
• Leaking water around the ice maker
• Ice cubes that are misshapen or smaller than usual
• Unusual noises coming from the ice maker

This OEM LG part is also compatible with Sears/Kenmore.

This small retaining clip secures its mating component within the refrigerator assembly, keeping parts properly seated and reducing vibration. Replacing a damaged or missing clip helps restore a snug fit and reliable operation of the attached piece.

• Holds the designated part firmly in place within the assembly
• Maintains proper alignment to prevent movement or rattling
• Helps ensure panels, ducts, or lines stay secured during use
• Symptoms can include loose or sagging parts, vibration noises, or components that won't stay attached

• Disconnect power; if working near the water system, also shut off the water supply
• Note the original orientation and placement before removal
• Fully seat the mating component, then press the new clip into place without forcing
• Check operation before reassembly

The Ice Dispenser Auger Motor is an OEM part for LG refrigerators. This part is designed to drive the auger that moves ice from the ice bin into the dispenser chute. This motor ensures that ice is available on demand through the door dispenser.

Causes of a bad Ice Dispenser Auger Motor can include electrical issues such as a burnt-out motor, wear and tear on the motor's components over time, or damage from moisture or ice buildup that can affect the motor's functionality.

Symptoms of a bad Ice Dispenser Auger Motor include:

• The ice dispenser not dispensing ice, even though the ice bin is full.
• A humming or buzzing sound from the motor area without any ice being dispensed, indicating the motor is receiving power but failing to turn the auger.
• Intermittent or inconsistent dispensing of ice, which can suggest a failing motor.

This OEM LG part is also compatible with Sears/Kenmore.

This sensor PCB assembly detects and relays sensor signals to the appliance control system, restoring accurate sensor feedback and communication when the original sensor board fails or malfunctions. Designed as a direct replacement board. What it does:

• Reads sensor inputs and converts them to signals the main control board can interpret.
• Replaces a failed or intermittent sensor board that causes incorrect readings or sensor-related error codes.
• Can resolve symptoms such as unexpected sensor faults, control errors, or appliances not responding to sensor changes.
• Matches the OEM board function; verify model compatibility before ordering.

• Always disconnect power before servicing to avoid shock or shorting the board.
• Use ESD precautions and handle the PCB by its edges to prevent static damage.
• Ensure all connectors are fully seated and the board is mounted in the original orientation.

This assembly stores ice and delivers it from the ice maker to the dispenser. Replace it when the bin is cracked, warped, or its drive components are damaged, causing weak dispensing, jams, or being stuck on one ice type.

• Stores ice and interfaces with the dispenser system to deliver cubes or crushed ice
• Resolves no or weak ice dispensing
• Corrects grinding/clicking noises or auger jamming from a damaged bin
• Addresses visible cracks, broken tabs, or a bucket that won't seat securely

• Disconnect power to the refrigerator before servicing
• Open the door and pull the old bucket straight out; depress any release tab if equipped
• Align and seat the new assembly fully so the drive coupling engages—do not force it
• Restore power and test the dispenser (cube and crush selections)

This AC motor powers the appliance's fan or blower to move air through the system. Replacing a worn motor restores proper airflow to support cooling/ventilation and protect internal components from overheating. What it does:

• Rotates the fan/blower to circulate air through the appliance
• Helps maintain proper temperatures and component cooling
• Common failure signs: fan won't start, starts then stalls, weak airflow, loud humming/grinding, overheating or safety shutoffs
• Often required when motor bearings seize or windings fail

• 1 AC motor

• Disconnect power and allow hot components to cool before servicing
• Note wire positions; transfer any brackets, grommets, or the fan blade from the original motor if reused
• Clear debris and restore power and verify smooth, quiet airflow

This replacement water tank assembly restores the refrigerator's internal water reservoir. It stores and chills water for the dispenser, helping maintain steady flow and addressing leaks caused by a cracked or brittle tank. What it does:

• Holds and chills dispenser water inside the fresh food compartment for consistent flow.
• Replaces a cracked or leaking reservoir that can leave puddles inside the refrigerator.
• Helps address low/no water or sputtering at the dispenser caused by an air-leaking or deformed tank.

• 1 water tank assembly

• Unplug the refrigerator and turn off the water supply before servicing.
• Remove shelves/panels as needed; note tube routing and avoid kinking lines during transfer.
• Fully seat water-line fittings and perform a gentle pull test; restore water and check all joints for leaks.
• Dispense several glasses of water to purge air until flow is steady; recheck for leaks after the first hour of operation.

The Connector (Mech), Tube is an OEM part for LG refrigerators. It is used to securely connect water tubing within the refrigerator, ensuring a reliable flow of water to components such as the ice maker and water dispenser.

Causes of a bad connector can include wear and tear over time, physical damage from improper installation or handling, or degradation due to exposure to varying temperatures and water pressure.

Symptoms of a bad connector include:

• Leaks or drips around the connector area
• Reduced water flow to the ice maker or water dispenser
• Water pooling inside or around the refrigerator
• The ice maker or water dispenser not functioning properly

This OEM LG part is also compatible with Sears/Kenmore models.

The Water Line is an OEM part for LG refrigerators, designed to supply water to the ice maker and water dispenser. Made from durable materials to withstand water pressure and prevent leaks, this water line is essential for access to clean, filtered water at all times. Note: color of the water tube may be different from original. Tube is 5/16" diameter

Symptoms of a bad Water Line include:

• Leaking of water at the connection points or along the tubing.
• A noticeable decrease in water flow to the dispenser or ice maker.
• A bad taste or odor of the water and ice

Causes of failure can range from physical damage, such as kinks or punctures, to wear and tear over time leading to brittleness or weakening of the material. These issues can compromise the integrity of the water supply, affecting both the quality and safety of the water and ice provided by your refrigerator.

This OEM LG part can also be used on Kenmore/Sears appliances.

This refrigerator water filter assembly conditions the water supplied to the dispenser and ice maker, helping deliver cleaner, better-tasting water and ice while maintaining proper flow. Replace regularly to keep your fridge's water system performing as designed. What it does:

• Filters incoming water for the dispenser and ice maker
• Helps improve taste and clarity of water and ice
• Supports proper dispenser flow and consistent ice production
• Replace when the filter indicator turns on or water/ice quality declines

• Dispense water to relieve line pressure; place a towel to catch any drips
• Remove the old filter and seat/lock the new cartridge fully—do not overtighten
• Flush water until it runs clear, and reset the filter indicator

The Water Inlet Valve is an OEM replacement part for LG refrigerators. It is a solenoid valve that controls the flow of water to the ice maker and water dispenser. The water inlet valve is typically located behind the refrigerator, near the water line connection.

Clogging or debris buildup in the valve can prevent the valve from opening or closing properly. Wear and tear over timeof the valve may simply wear out over time and need to be replaced.

Symptoms of a bad water inlet valve include:

• No water to the ice maker or water dispenser.
• Leaking from the water inlet valve area.
• Noisy water inlet valve.
• Ice maker not producing ice.

This OEM LG part is also compatible with Sears/Kenmore refrigerators.

The Water Inlet Valve Assembly is an OEM part for LG refrigerators. This part controls the flow of water into the refrigerator's ice maker and water dispenser. By opening and closing at specific times, it ensures the proper amount of water is supplied for making ice or dispensing water.

Causes of a bad water inlet valve include clogs from sediment, failure of the solenoids, or cracks in the valve body.

Symptoms of a bad Water Inlet Valve Assembly include:

• No water being dispensed
• Slow or irregular water flow from the dispenser
• Leaks occurring at the back of the refrigerator where the valve is located
• The ice maker not producing ice or producing very small ice cubes

This OEM LG part is also compatible with some Kenmore models.

This cover cap is a small plastic trim piece that protects exposed fasteners and improves the appliance's appearance. It snaps into place to hide mounting posts and help prevent snags or debris buildup. What it does:

• Covers and protects exposed screws, posts, or fasteners for a finished look
• Prevents lint, dust, and debris from collecting around the mounting point
• Reduces the chance of fabric snags or contact with sharp edges
• Restores worn or missing trim for improved cosmetics

• Disconnect power to the appliance before starting any service that exposes electrical components
• Usually installs by snapping over the post or press-fitting into the trim opening — no special tools required
• If needed, remove adjacent trim pieces to gain access, then reinstall trim in reverse order
• Inspect surrounding mounting hardware for damage and replace if necessary

This connector tube routes water from the refrigerator's supply to the ice maker or dispenser, restoring normal water flow and ice production when the original tube is cracked or clogged. It's a direct-fit replacement designed for quick restoration. What it does:

• Replaces damaged or cracked water line routing to the ice maker or dispenser
• Restores proper water flow to prevent low ice production or slow dispensing
• Helps stop leaks caused by split or brittle tubing at connector points
• Matches OEM routing and fit to maintain reliable connection and pressure

• Disconnect the refrigerator from power and shut off the water supply before beginning.
• Drain remaining water from lines and wear gloves; connections may drip when removed.
• Inspect fittings and seals; replace O-rings or clamps if they are worn or damaged.
• Tighten connections to a snug, leak-free fit; test by turning water back on and checking for leaks.

Replacement filter assembly head that holds and seals the refrigerator water filter cartridge and routes water to the dispenser and ice maker. Replaces damaged or worn filter heads to restore proper filter seating and help prevent leaks. What it does:

• Secures and aligns the water filter cartridge so the filter can seat and seal correctly.
• Channels water from the filter to the dispenser and ice maker.
• Stops leaks and drips caused by cracked, warped, or damaged filter head components.
• Restores proper water flow where a broken filter head was causing reduced or no water dispense.

• One filter assembly head.

• Turn off the refrigerator water supply and dispense water to relieve pressure before replacing.
• Remove the old filter and head per your owner's manual; install the new head and re-seat the filter until it locks.
• Check all connections for leaks after turning the water back on; hand-tighten only and avoid over-torquing.

The Water Filter LT800P is an OEM part for LG refrigerators. This filter is designed to remove contaminants from the water supply, ensuring clean and fresh-tasting water and ice.

Causes of a bad water filter can include extended use beyond its recommended lifespan, exposure to high levels of contaminants, or damage to the filter itself.

Symptoms of a bad Water Filter LT800P include:

• Unpleasant taste or odor in the water or ice
• Reduced water flow from the dispenser
• Indicator light signaling the need for replacement
• Visible sediment or particles in the water

This OEM LG part is also compatible with Sears/Kenmore.

This is the Home Bar cover — the molded door shelf cover that protects and conceals the refrigerator's door-in-door/home bar compartment for organized storage and a finished appearance. It restores a secure, clean barrier for items stored in the home bar. What it does:

• Replaces a cracked, chipped or missing home-bar/door-in-door shelf cover
• Keeps small bottles and items contained when the home bar is opened and closed
• Restores the proper fit and appearance of the door-in-door/home bar area
• Helps prevent items from falling out of the home bar compartment

• One Home Bar cover

• High-level replacement: usually removes and snaps into the door-in-door shelf housing; some models may require removing the inner door panel or a few fasteners
• Use basic hand tools; keep track of small screws and clips during reassembly
• Inspect surrounding clips and supports; replace any damaged fasteners for a secure fit
• For safety, close the door fully and check smooth opening/closing after install

This lower hinge assembly secures and supports the refrigerator door pivot, restoring proper door alignment and smooth opening/closing. Replace a worn or damaged lower hinge to stop sagging, help seal performance, and reduce rubbing or binding. What it does:

• Provides a stable pivot point for the lower side of the refrigerator door.
• Corrects door sagging or misalignment that can cause poor sealing or uneven gaps.
• Reduces rubbing, scraping, or binding when opening and closing the door.
• Restores proper door operation after impact damage or worn hinge components.

• One lower hinge assembly

• Disconnect power and remove food from the door area before starting; support the door to prevent dropping during removal.
• Keep all original fasteners if they are undamaged; some models may reuse screws or pins.
• Use appropriate tools and take care not to damage the door finish or gasket; wear gloves to protect hands.
