Parts for Ge PGS930BEL1TS: Gas & Burner Parts

This LP high-altitude conversion kit adapts select gas cooking appliances for liquid propane use at elevation. It properly meters gas flow so burners light easily and produce clean, stable flames in thin-air conditions.

• Configures the appliance for LP operation in high-altitude installations
• Calibrates fuel delivery to maintain proper flame size and combustion
• Helps address yellow/sooty flames, flame lift, or hard-to-control simmer after conversion
• Promotes reliable ignition and even heat across burners

• Conversion affects gas type and pressure; must be performed per the manufacturer's instructions and local codes
• Shut off gas and power before service; work in a well-ventilated area away from open flames or sparks
• After conversion, leak-test all connections and adjust air shutters per model guidance if applicable
• Intended for LP high-altitude applications only; use the model-specific kit specified by the manufacturer

This LP conversion kit allows a qualified installer to convert a compatible gas range or cooktop from natural gas to liquid propane. It sets up the appliance for proper LP operation with correct flame characteristics and reliable performance.

• Converts the appliance from natural gas to LP (propane) per model-specific instructions
• Provides LP-calibrated components to achieve correct gas flow and burner flame
• Helps restore proper blue flame, heat output, and ignition reliability on LP
• Use when installing on a propane supply or after moving from NG service
• Incorrect fuel setup may show large yellow flames, sooting, or poor simmer control

• Must be installed by a qualified gas technician; follow local codes and the model's instructions
• Disconnect electrical power and shut off the gas supply before starting
• Convert the pressure regulator to LP and adjust air shutters/burner flames as directed
• After conversion, leak-check all connections with a non-corrosive solution and verify proper blue flame

The Range NG High Altitude Kit is an OEM part for GE gas ranges. This high-altitude conversion kit allows the range to operate properly at elevations above 2000 feet.

Causes related to needing this kit are using the range at a high elevation without proper adjustment for decreased air pressure and oxygen levels.

Symptoms of needing this high-altitude kit include:

• Unstable or inconsistent flame during operation
• Excessive cooking times
• Incomplete combustion of gas resulting in carbon monoxide issues

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This small V2 inlet jet directs water flow to the dispenser/ice-making area so the appliance fills and forms properly. It restores correct water routing for consistent filling and helps reduce weak or misshapen ice or slow dispensing. What it does:

• Channels water to the ice maker/dispenser so the correct amount reaches the fill area.
• Helps ensure uniform ice formation and consistent dispenser flow.
• Can resolve symptoms like weak/slow dispensing, underfilled ice trays, or uneven ice cubes.
• Works as the small replacement nozzle where the original inlet jet is worn or blocked.

• One small V2 inlet jet

• Disconnect power and shut off the water supply before beginning work.
• Access may require removing inner panels or the ice maker/dispenser housing; follow your model's service instructions.
• Inspect the seat and surrounding fittings for debris or damage before installing; replace other damaged components as needed.

The Medium surface burner base is an OEM part for GE ranges. It serves as the base for the surface burners, covering and protecting the burner cavities.

Causes of a bad surface burner base include warping or deformation from high heat over time, cracks or breaks from impact damage, or corrosion from liquid spills or grease accumulation.

Symptoms of a bad surface burner base include:

• Burners no longer sitting flush or securely on the cooktop surface
• Excessive air gaps around the burners allowing gas/flames to escape
• Difficulty cleaning due to liquid leaks into the burner cavities
• Visible cracks, breaks, or deformities in the material

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This genuine OEM GE replacement is compatible with additional Hotpoint, RCA and Kenmore gas range models.

This orifice spud meters gas to a burner, controlling flow for a correct, stable flame. Replace a clogged or damaged spud to restore reliable ignition and proper flame characteristics.

• Threads into the orifice holder to regulate gas flow to the burner head
• Helps maintain proper flame height and shape during cooking
• A clogged or damaged spud can cause weak/uneven flames, yellow tipping, or delayed ignition
• Replacing the spud can improve lighting and flame consistency

• Disconnect power and shut off gas; allow the appliance to cool completely
• Remove grates, caps, and burner heads (as applicable) to access the orifice
• Support the orifice holder while loosening/tightening the spud to avoid twisting the gas tube
• After reassembly, restore gas and check for leaks with an approved leak-detection solution; verify proper burner operation

This 1/4-20 screw secures panels, brackets, and other assemblies in your appliance. It restores a tight, reliable hold when an original fastener is missing, stripped, or corroded.

• Fastens components that require a 1/4-20 threaded screw
• Helps keep panels and assemblies aligned and rattle-free
• Direct replacement for worn, rusted, or lost hardware
• Common symptoms: loose or vibrating parts, misaligned brackets, missing fastener

• Disconnect power; turn off gas supply before servicing
• Allow the appliance to cool; wear gloves and eye protection
• Start threads by hand to avoid cross-threading; use the correct driver/tool
• Tighten snugly—do not overtighten to prevent stripping or damage

This bake burner is the oven's primary bake flame assembly, restoring proper heat for even baking and roasting. Replace a damaged or corroded burner to regain reliable oven temperatures. What it does:

• Provides the main bake flame that heats the oven cavity for baking and roasting.
• Works with the range's ignition system to light the burner; a failed burner can prevent the oven from lighting.
• Common symptoms: oven won't reach temperature, burner won't light, weak or uneven flame, or uneven/slow cooking.
• Designed to fit the oven floor area and direct heat across the bake cavity for consistent results.

• Turn off both the gas supply and electrical power to the appliance before servicing.
• Allow the oven to cool completely and use basic hand tools; keep track of mounting hardware.
• Inspect the ignition electrode and burner ports for debris during replacement; do not bend or damage the electrode.
• After installation, check connections and test for proper ignition and a steady flame; if you smell gas or see a faulty flame, shut off gas.

This main dual valve tube routes gas between the oven/range valve assemblies to ensure proper fuel delivery for burner operation. Replaces a damaged or corroded primary gas tube to restore consistent ignition and burner performance. What it does:

• Connects the main dual valve to the manifold and burners for controlled gas flow
• Supports reliable ignition and even flame distribution when properly sealed
• Commonly needed when the tube is bent, cracked, or shows gas leakage
• Used during repairs addressing weak flames, intermittent lighting, or visible damage to the gas tubing

• One main dual valve tube

• Turn off gas supply and electrical power before starting any service
• Inspect fittings and seals; use manufacturer-specified gaskets and thread sealant where required
• After installation, perform a certified leak test and verify correct burner ignition and flame patterns

The Igniter Mounting Screw is an OEM replacement part for GE ovens and ranges. This screw secures the igniter to the burner assembly, ensuring it remains firmly in place for consistent and reliable ignition. Its precise fit and durable design help maintain the stability and functionality of the igniter.

Over time, mounting screws can become corroded, stripped, or lost during repairs or maintenance. A missing or damaged screw may result in a loose igniter, affecting the appliance's ability to ignite properly.

Symptoms of a bad or missing igniter mounting screw include:

• The igniter becoming loose or misaligned

• Difficulty securing the igniter during installation or repair
• The burner fails to ignite reliably or consistently
• Increased noise or movement of the igniter during operation

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This 90° elbow assembly connects a refrigerator's water line to the fill/ice system, routing water where the appliance needs it and helping maintain a secure, leak-resistant connection. Designed to replace a damaged or worn elbow to restore proper water flow. What it does

• Redirects water flow at a 90° angle for tight installations and proper tubing routing
• Provides a sealed connection between water tubing and the appliance inlet to prevent leaks
• Commonly used where a bent, cracked, or blocked elbow causes reduced or no water to the ice maker or dispenser
• Helps stop intermittent leaking caused by a split or damaged elbow fitting

• One 90° elbow assembly

• Shut off water supply and unplug the appliance before beginning work
• Inspect tubing and seals; replace any worn tubing or O-rings to ensure a proper seal
• Hand-start fittings to avoid cross-threading, then snug per manufacturer guidance

This tubular broil burner delivers the concentrated heat used for broiling in gas ovens, restoring high-heat cooking performance for crisping and browning. Replace a damaged or worn broil tube to recover even broil results. What it does

• Provides the primary heat source for the oven's broil function
• Replaces a cracked, warped or visibly damaged broil tube
• Restores consistent top-heat for browning and finishing foods
• Addresses symptoms such as weak or no broil heat and uneven broiling

• Disconnect power and shut off gas supply before beginning service
• Handle the tube carefully to avoid bending or damaging terminals
• Verify proper fit and orientation against the oven's broil bracket and igniter

This cover ignitor protects the oven or range ignitor assembly and helps keep the ignitor clear of drips and debris for reliable ignition. It's a simple replacement that restores the ignitor's protective shield. What it does

• Protects the ignitor element from spills, grease, and debris that can interfere with ignition
• Helps maintain consistent ignition by shielding the ignitor from direct contact
• Commonly used when the original cover is cracked, warped, or missing
• Can resolve ignition issues caused by physical damage or buildup on the ignitor area

• One cover ignitor

• Disconnect power (and gas supply on gas appliances) before starting any repair
• Handle the ignitor assembly carefully; avoid touching the ceramic or ignitor tip
• Use basic hand tools; ensure the cover seats properly without forcing or cracking it
• After installation, restore power/gas and test the burner or oven according to the appliance manual

The Valve and Burner Assembly is an OEM part for GE gas ranges. As the primary mechanism for fuel ignition and burner operation, it works to deliver gas to each burner safely and control flame intensity precisely.

Symptoms of a bad valve and burner assembly include:

• Inability to light one or more burners
• Unstable, excessively large or small flames
• Burners that will not maintain the desired heat setting
• Gas leaks around the burner area

Causes can be normal damage over time from heat exposure, cracks developing in valve components, blockages in gas ports, or loose connections. Installing this OEM replacement ensures your range's burners operate efficiently.

This GE part is also compatible with some Hotpoint, RCA, and Kenmore ranges and restores reliable stove-top cooking performance. Replace yours today before minor problems worsen.


The Valve Burner is an OEM component for GE gas ranges. Located below the grates atop each cooktop burner, it precisely mixes gas and air to provide controllable flames. A valve adjusts gas flow while perforated metal distributes the flame evenly.

Symptoms of a faulty valve burner include:

• Difficulty obtaining or maintaining set flame levels
• Unstable or intermittent burner operation
• Yellow fire or flame that produces excessive soot
• No ignition or fire when the knob is turned

Causes can be wear of internal valve components, debris, or clogs in gas ports restricting flow over time. Damage from spills or dropped objects may also crack the burner.

This OEM GE burner is also compatible with models from Hotpoint and RCA.

This range burner valve controls gas flow to a single stovetop burner to restore reliable ignition and consistent flame control. Use it to replace a worn or leaky valve and help return safe, stable burner operation. What it does:

• Regulates gas delivery to one burner for proper ignition and flame adjustment
• Stops or reduces gas flow when the control is turned off to prevent leaks
• Helps resolve symptoms such as burners that won't light, weak or uneven flames, or persistent gas smell near a burner
• Works as the valve assembly that connects the cooktop knob to the burner gas line

• Turn off gas supply and electrical power to the appliance before beginning service
• Use appropriate tools and pipe sealant rated for gas if re-connecting gas lines
• After installation, test all connections for leaks with a soap solution or approved leak detector

The BURNER VALVE is an OEM part for GE gas ranges. It regulates gas flow to individual cooktop burners, controlling flame size and heat output based on valve position.

Symptoms of a bad burner valve include:

• Inability to adjust or maintain desired flame levels
• Gas odor or clicking/hissing noises from the burner area
• Burners that remain constantly on without response to controls

Gas valves can weaken or crack over many heating/cooling cycles. Mineral buildup may also restrict precise flow regulation. Replacing the faulty valve with this genuine GE part restores the burners' heat-adjustable functionality for custom cooking power.

This OEM GE replacement burner valve is also compatible with some Kenmore and RCA gas range models. Reliable control over burners maximizes versatility and safety.


This rotary switch is the user-control selector that lets you choose settings on your appliance and restores responsive, consistent control when the original switch is worn or malfunctioning. It provides a direct replacement that matches OEM fit and function. What it does:

• Selects the appliance control position (temperature/speed/setting) as you turn the knob
• Restores reliable electrical contact when the original switch has intermittent operation or unresponsive detents
• Stops erratic or non-functioning controls caused by worn contacts or broken selector mechanism
• Re-establishes safe, repeatable control positions for normal appliance operation

• One rotary switch

• Disconnect power to the appliance before starting any repair
• Access may require removing the control panel or console; handle panel clips and trim carefully
• Take care with terminals and wiring; note original connections or photograph before disconnecting

This Injet MRHOB assembly is a replacement component designed to restore the original part function in compatible appliances. It replaces a worn or damaged MRHOB assembly to help return the unit to normal operation. What it does:

• Serves as the direct replacement assembly for the appliance's Injet MRHOB component
• Restores mechanical/electrical connection where the original MRHOB has failed
• Can address symptoms such as intermittent operation, loss of function, or component-related error codes when the MRHOB is faulty
• Used when inspection shows the existing MRHOB is cracked, corroded, or otherwise damaged

• One Injet MRHOB assembly

• Install only after disconnecting power to the appliance to avoid shock or injury
• Refer to the OEM installation instructions for correct placement and wiring
• Use proper tools and replacement practices

This inject burner assembly replaces a damaged or worn hob injector to restore proper gas flow to a cooktop burner. It provides the correct metered fuel delivery for consistent ignition and stable flame control. What it does:

• Directs and meters gas from the manifold into the burner for predictable burning
• Helps burners light promptly and maintain an even flame
• Can resolve weak flames, uneven heating, or failure to light when caused by the injector
• Works with the burner head and cap to form the complete burner flame assembly

• Turn off the gas supply and unplug the appliance before starting any work
• Inspect gaskets and fittings for leaks; replace or tighten per manufacturer guidance
• Use proper tools and follow OEM diagram orientation for correct installation

This tube burner supply is the replacement gas tube that delivers fuel from the range/oven valve to the burner, restoring proper gas flow for reliable ignition and consistent flame performance. What it does:

• Directs gas from the appliance valve to the burner for normal operation
• Replaces cracked, corroded, or clogged burner tubing that can cause fuel flow disruption
• Helps correct symptoms such as burners that won't light, weak or uneven flames, or intermittent ignition
• Restores a sealed path for gas to reduce leakage risk when installed and tightened correctly

• Turn off gas supply and electrical power to the appliance before beginning work
• Verify proper fit and orientation to the valve and burner; use the OEM clamp/hardware if provided
• After installation, check all connections for leaks (soap-and-water test) and restore power per the appliance manual

The High Voltage Electrode and Harness Assembly is an OEM part for GE dual fuel ranges. It carries electrical current to spark gas pilots and oven/broiler ignitors.

Symptoms of a faulty HV electrode and harness include:

• Pilot lights extinguishing or failing to light
• Inconsistent ignition of gas burners and heating elements
• Arcing sounds emanating from the range top or oven areas

Causes involve cracks in porcelain insulators from thermal stress, worn electrodes after prolonged sparking, or wire insulation degraded by ambient heat over time.

This OEM part is also compatible with Hotpoint and RCA dual fuel range models.

The Valve Control Assembly is an OEM part for GE gas ranges. This assembly governs the gas valves that deliver fuel to each burner on the cooktop for precise flame control. Programmed settings adjust gas flow based on temperature and cooking requirements.

Causes of a bad Valve Control Assembly can include worn valve components, clogged gas ports, or failure of electronic controls from heat exposure over time.

Symptoms of a bad gas range Valve Control Assembly include:

• Inconsistent or abnormal burner flames
• Inability to regulate flame sizes as desired
• One or more burners not functioning properly
• Improper gas pressure levels reaching the burners

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This hot surface oven igniter heats up and lights the gas at the burner. Replacing a weak, cracked, or non-glowing igniter often restores reliable ignition when a gas oven won't heat or preheats very slowly.

• Heats to ignite gas at the oven or broiler burner
• Draws the correct current to open the safety gas valve
• Common symptoms: no heat, intermittent heat, glows but no flame, very slow preheat, no glow at all
• Helps restore consistent burner ignition and temperature recovery

• Disconnect power and shut off gas; allow the appliance to cool completely
• Handle by the base/bracket only—the ceramic element is very fragile
• Reuse original mounting screws; route wires away from the flame path
• After install, verify a steady bright glow followed by burner ignition

This glow-bar oven igniter lights the gas burner. When energized, it heats and draws current through the safety valve so the bake or broil flame ignites reliably and the oven reaches the set temperature. What it does:

• Heats and ignites the oven's bake or broil burner
• Draws the correct current to open the gas safety valve
• Can address no-heat or no-ignition conditions
• Helps resolve very slow preheat or inconsistent oven temperatures
• Useful when the igniter glows but the burner never lights

• 1 glow-bar igniter

• Disconnect power and shut off gas supply before servicing
• Access from the oven cavity; remove racks, oven bottom, and flame spreader as needed
• Handle the igniter carefully—element is fragile; avoid touching the carbide/ceramic tip
• Secure connections and route wires away from flames and high-heat areas; test operation after reassembly

This lower heat shield is a stamped metal shield that protects the oven's lower cabinet area and surrounding components from excessive heat. It helps maintain safe operation and reduces heat transfer to nearby parts. What it does:

• Shields the oven's lower cavity and insulation from direct heat
• Prevents heat-related damage to the range cabinet and nearby components
• Can reduce hotspots that cause smoking or burning odors
• Restores proper airflow and clearance under the oven when damaged or missing

• One lower heat shield

• Disconnect power (and gas, if applicable) before servicing the appliance
• Remove oven drawer and access panels to reach and replace the shield
• Use gloves to protect hands from sharp metal edges during installation
• Tighten fasteners securely but do not overtighten—replace any damaged mounting hardware

The Cooling Fan Sensor is an OEM replacement part for GE ovens and ranges. It is a critical component that monitors and regulates the operation of the cooling fan, ensuring proper ventilation and temperature control within the appliance.

Symptoms of a bad cooling fan sensor:

• Overheating issues, with the oven or range becoming excessively hot
• Failure of the cooling fan to turn on or operate correctly
• Error codes or warning lights related to temperature or ventilation problems
• Potential safety hazards due to inadequate cooling and heat buildup

Causes of a faulty cooling fan sensor can include exposure to high temperatures over time, electrical malfunctions, or physical damage to the sensor or its wiring.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore ovens and ranges.

The Blower Tangential is an OEM component designed specifically for GE ranges. Located near the top of the oven cavity, this tangential blower circulates exhaust air out of the oven and above the cooktop during and after cooking cycles.

Symptoms of a faulty blower include:

• Excessive heat buildup inside the oven and around the cooktop surfaces
• Steam or smoke failing to properly vent outdoors from the oven
• Abnormal noises coming from the blower motor

Causes usually involve failures of the electric motor from years of sustained usage. Physical obstructions blocking the fan housing could also lead to issues.

This genuine GE part is compatible with Hotpoint, RCA, and select Kenmore models as well.

This cover latch secures the appliance's top access cover so it stays closed during use and lets you open the cover for service or maintenance. It restores a positive, smooth-closing latch action for safe access. What it does:

• Holds the top/access cover closed to prevent accidental opening during operation
• Provides a solid engagement point for the cover to snap or latch into place
• Replaces a broken, worn or loose latch that causes rattling or an unsecured cover
• Helps ensure proper alignment of the cover for safe servicing and operation

• Disconnect power (unplug or shut off breaker) before beginning any service
• Typically installs with simple snap-in or screw fasteners; keep fasteners from the original part

This tube burner box is a replacement gas tube assembly that routes gas from the manifold to the range burner ports. Restores proper gas flow to the burner area for reliable ignition and stable flames. What it does:

• Channels gas from the manifold to the burner tube so the burner can light and operate
• Replaces damaged, bent or corroded supply tubing that can cause poor or uneven flames
• Supports proper positioning of the burner tube for consistent ignition
• Helps eliminate common symptoms like burners that won't light or burn unevenly

• Turn off the gas supply and unplug the appliance before starting work
• Use basic hand tools; follow factory torque and alignment when reconnecting gas fittings
• After installation, check all gas connections for leaks with a soap solution or approved leak detector

This air deviator routes and directs cold airflow inside the refrigerator to balance temperatures between compartments and improve cooling performance. It restores proper air distribution when the original piece is cracked or misaligned. What it does:

• Redirects chilled air from the evaporator to the correct compartment to help maintain even temperatures
• Helps prevent warm spots caused by blocked or misdirected airflow
• Works with the fridge's air circulation path to support normal cooling cycles
• Common symptom: uneven cooling or air bypass near the evaporator cover

• One air deviator

• Inspect and replace only when the existing deviator is broken, warped, or missing
• Handle plastic parts gently to avoid cracking; align tabs before snapping into place
• Always unplug the appliance before accessing internal panels or components
• No special tools typically required;
