Parts for Ge PGS960BEL1TS: Gas & Burner Parts

This LP conversion kit lets a compatible gas range be converted to run on liquid propane (LP), restoring correct burner performance and safe operation when natural gas is not available. Use the kit to convert appliances designed for a factory NG/LP changeover. What it does

• Supplies the necessary components to change burner fuel jets and settings from natural gas to LP.
• Restores proper flame size and heat output after conversion to prevent weak or uneven flames.
• Prevents ignition issues and poor burner performance caused by mismatched fuel orifices.
• Helps ensure the appliance operates as designed on LP when installed per manufacturer instructions.

• One LP conversion kit (components vary by model; see manufacturer instructions for exact contents)

• Turn off the gas supply and electrical power before beginning work. Follow the included instructions.
• Conversion should be performed per the appliance manufacturer's conversion procedure and local codes.
• Recommended for experienced DIYers comfortable with gas appliance work.
• After conversion, check all connections for leaks with a soap solution or approved leak detector and test burner operation.

This LP high-altitude conversion kit adapts select gas cooking appliances for liquid propane use at elevation. It properly meters gas flow so burners light easily and produce clean, stable flames in thin-air conditions.

• Configures the appliance for LP operation in high-altitude installations
• Calibrates fuel delivery to maintain proper flame size and combustion
• Helps address yellow/sooty flames, flame lift, or hard-to-control simmer after conversion
• Promotes reliable ignition and even heat across burners

• Conversion affects gas type and pressure; must be performed per the manufacturer's instructions and local codes
• Shut off gas and power before service; work in a well-ventilated area away from open flames or sparks
• After conversion, leak-test all connections and adjust air shutters per model guidance if applicable
• Intended for LP high-altitude applications only; use the model-specific kit specified by the manufacturer

The Range NG High Altitude Kit is an OEM part for GE gas ranges. This high-altitude conversion kit allows the range to operate properly at elevations above 2000 feet.

Causes related to needing this kit are using the range at a high elevation without proper adjustment for decreased air pressure and oxygen levels.

Symptoms of needing this high-altitude kit include:

• Unstable or inconsistent flame during operation
• Excessive cooking times
• Incomplete combustion of gas resulting in carbon monoxide issues

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Medium surface burner base is an OEM part for GE ranges. It serves as the base for the surface burners, covering and protecting the burner cavities.

Causes of a bad surface burner base include warping or deformation from high heat over time, cracks or breaks from impact damage, or corrosion from liquid spills or grease accumulation.

Symptoms of a bad surface burner base include:

• Burners no longer sitting flush or securely on the cooktop surface
• Excessive air gaps around the burners allowing gas/flames to escape
• Difficulty cleaning due to liquid leaks into the burner cavities
• Visible cracks, breaks, or deformities in the material

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This genuine OEM GE replacement is compatible with additional Hotpoint, RCA and Kenmore gas range models.

This 1/4-20 screw secures panels, brackets, and other assemblies in your appliance. It restores a tight, reliable hold when an original fastener is missing, stripped, or corroded.

• Fastens components that require a 1/4-20 threaded screw
• Helps keep panels and assemblies aligned and rattle-free
• Direct replacement for worn, rusted, or lost hardware
• Common symptoms: loose or vibrating parts, misaligned brackets, missing fastener

• Disconnect power; turn off gas supply before servicing
• Allow the appliance to cool; wear gloves and eye protection
• Start threads by hand to avoid cross-threading; use the correct driver/tool
• Tighten snugly—do not overtighten to prevent stripping or damage

This main dual valve tube routes gas between the oven/range valve assemblies to ensure proper fuel delivery for burner operation. Replaces a damaged or corroded primary gas tube to restore consistent ignition and burner performance. What it does:

• Connects the main dual valve to the manifold and burners for controlled gas flow
• Supports reliable ignition and even flame distribution when properly sealed
• Commonly needed when the tube is bent, cracked, or shows gas leakage
• Used during repairs addressing weak flames, intermittent lighting, or visible damage to the gas tubing

• One main dual valve tube

• Turn off gas supply and electrical power before starting any service
• Inspect fittings and seals; use manufacturer-specified gaskets and thread sealant where required
• After installation, perform a certified leak test and verify correct burner ignition and flame patterns

The Igniter Mounting Screw is an OEM replacement part for GE ovens and ranges. This screw secures the igniter to the burner assembly, ensuring it remains firmly in place for consistent and reliable ignition. Its precise fit and durable design help maintain the stability and functionality of the igniter.

Over time, mounting screws can become corroded, stripped, or lost during repairs or maintenance. A missing or damaged screw may result in a loose igniter, affecting the appliance's ability to ignite properly.

Symptoms of a bad or missing igniter mounting screw include:

• The igniter becoming loose or misaligned

• Difficulty securing the igniter during installation or repair
• The burner fails to ignite reliably or consistently
• Increased noise or movement of the igniter during operation

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This tubular broil burner delivers the concentrated heat used for broiling in gas ovens, restoring high-heat cooking performance for crisping and browning. Replace a damaged or worn broil tube to recover even broil results. What it does

• Provides the primary heat source for the oven's broil function
• Replaces a cracked, warped or visibly damaged broil tube
• Restores consistent top-heat for browning and finishing foods
• Addresses symptoms such as weak or no broil heat and uneven broiling

• Disconnect power and shut off gas supply before beginning service
• Handle the tube carefully to avoid bending or damaging terminals
• Verify proper fit and orientation against the oven's broil bracket and igniter

The Valve and Burner Assembly is an OEM part for GE gas ranges. As the primary mechanism for fuel ignition and burner operation, it works to deliver gas to each burner safely and control flame intensity precisely.

Symptoms of a bad valve and burner assembly include:

• Inability to light one or more burners
• Unstable, excessively large or small flames
• Burners that will not maintain the desired heat setting
• Gas leaks around the burner area

Causes can be normal damage over time from heat exposure, cracks developing in valve components, blockages in gas ports, or loose connections. Installing this OEM replacement ensures your range's burners operate efficiently.

This GE part is also compatible with some Hotpoint, RCA, and Kenmore ranges and restores reliable stove-top cooking performance. Replace yours today before minor problems worsen.


The Valve Burner is an OEM component for GE gas ranges. Located below the grates atop each cooktop burner, it precisely mixes gas and air to provide controllable flames. A valve adjusts gas flow while perforated metal distributes the flame evenly.

Symptoms of a faulty valve burner include:

• Difficulty obtaining or maintaining set flame levels
• Unstable or intermittent burner operation
• Yellow fire or flame that produces excessive soot
• No ignition or fire when the knob is turned

Causes can be wear of internal valve components, debris, or clogs in gas ports restricting flow over time. Damage from spills or dropped objects may also crack the burner.

This OEM GE burner is also compatible with models from Hotpoint and RCA.

This range burner valve controls gas flow to a single stovetop burner to restore reliable ignition and consistent flame control. Use it to replace a worn or leaky valve and help return safe, stable burner operation. What it does:

• Regulates gas delivery to one burner for proper ignition and flame adjustment
• Stops or reduces gas flow when the control is turned off to prevent leaks
• Helps resolve symptoms such as burners that won't light, weak or uneven flames, or persistent gas smell near a burner
• Works as the valve assembly that connects the cooktop knob to the burner gas line

• Turn off gas supply and electrical power to the appliance before beginning service
• Use appropriate tools and pipe sealant rated for gas if re-connecting gas lines
• After installation, test all connections for leaks with a soap solution or approved leak detector

The BURNER VALVE is an OEM part for GE gas ranges. It regulates gas flow to individual cooktop burners, controlling flame size and heat output based on valve position.

Symptoms of a bad burner valve include:

• Inability to adjust or maintain desired flame levels
• Gas odor or clicking/hissing noises from the burner area
• Burners that remain constantly on without response to controls

Gas valves can weaken or crack over many heating/cooling cycles. Mineral buildup may also restrict precise flow regulation. Replacing the faulty valve with this genuine GE part restores the burners' heat-adjustable functionality for custom cooking power.

This OEM GE replacement burner valve is also compatible with some Kenmore and RCA gas range models. Reliable control over burners maximizes versatility and safety.


This rotary switch is the user-control selector that lets you choose settings on your appliance and restores responsive, consistent control when the original switch is worn or malfunctioning. It provides a direct replacement that matches OEM fit and function. What it does:

• Selects the appliance control position (temperature/speed/setting) as you turn the knob
• Restores reliable electrical contact when the original switch has intermittent operation or unresponsive detents
• Stops erratic or non-functioning controls caused by worn contacts or broken selector mechanism
• Re-establishes safe, repeatable control positions for normal appliance operation

• One rotary switch

• Disconnect power to the appliance before starting any repair
• Access may require removing the control panel or console; handle panel clips and trim carefully
• Take care with terminals and wiring; note original connections or photograph before disconnecting

This inject burner assembly replaces a damaged or worn hob injector to restore proper gas flow to a cooktop burner. It provides the correct metered fuel delivery for consistent ignition and stable flame control. What it does:

• Directs and meters gas from the manifold into the burner for predictable burning
• Helps burners light promptly and maintain an even flame
• Can resolve weak flames, uneven heating, or failure to light when caused by the injector
• Works with the burner head and cap to form the complete burner flame assembly

• Turn off the gas supply and unplug the appliance before starting any work
• Inspect gaskets and fittings for leaks; replace or tighten per manufacturer guidance
• Use proper tools and follow OEM diagram orientation for correct installation

A 90° elbow assembly that redirects a fluid or discharge line at a right angle to restore proper routing and a secure connection. Simple replacement for worn, cracked, or damaged elbow fittings. What it does

• Redirects flow between two hoses or fittings at a 90° angle to enable correct line routing
• Provides a sealed connection to help prevent leaks where a straight connection won't fit
• Restores proper flow path to eliminate kinks or pressure loss caused by a damaged elbow
• Common symptom: visible leak, moisture or pooling near the elbow fitting
• Common symptom: poor or restricted flow where the line changes direction

• One 90° elbow assembly

• Turn off power and shut off the appliance water supply before starting any repair
• Inspect mating hoses and seals; replace worn clamps or gaskets for a reliable seal
• Hand-tighten then snug fittings; avoid over-tightening plastic fittings to prevent cracking
• After installation, restore water/power and check thoroughly for leaks during a test run

This 90° elbow assembly directs exhaust airflow in the oven/range vent path to ensure proper ventilation and heat flow. It replaces a damaged or cracked elbow to restore correct venting and maintain cooking performance. What it does:

• Routes exhaust and ventilation air through a 90° turn in the oven/range vent system
• Helps prevent heat or smoke from leaking into the cabinet area
• Commonly replaced when the original elbow is cracked, warped, or separated at the joint
• Supports consistent oven temperatures by keeping the vent path intact

• Disconnect power to the appliance before beginning any repair
• Access may require removing the oven back panel, rear trim, or adjacent components
• Use proper fasteners and gaskets where applicable; confirm orientation before fastening

The Cooling Fan Sensor is an OEM replacement part for GE ovens and ranges. It is a critical component that monitors and regulates the operation of the cooling fan, ensuring proper ventilation and temperature control within the appliance.

Symptoms of a bad cooling fan sensor:

• Overheating issues, with the oven or range becoming excessively hot
• Failure of the cooling fan to turn on or operate correctly
• Error codes or warning lights related to temperature or ventilation problems
• Potential safety hazards due to inadequate cooling and heat buildup

Causes of a faulty cooling fan sensor can include exposure to high temperatures over time, electrical malfunctions, or physical damage to the sensor or its wiring.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore ovens and ranges.

The High Voltage Electrode and Harness Assembly is an OEM part for GE dual fuel ranges. It carries electrical current to spark gas pilots and oven/broiler ignitors.

Symptoms of a faulty HV electrode and harness include:

• Pilot lights extinguishing or failing to light
• Inconsistent ignition of gas burners and heating elements
• Arcing sounds emanating from the range top or oven areas

Causes involve cracks in porcelain insulators from thermal stress, worn electrodes after prolonged sparking, or wire insulation degraded by ambient heat over time.

This OEM part is also compatible with Hotpoint and RCA dual fuel range models.

The IGNITER GLOWBAR is an OEM component specifically designed for GE gas ranges. It functions as the direct source of ignition to light the oven.

Causes of a bad igniter glowbar include decreased performance over time from frequent usage. Mineral deposits can accumulate, reducing its ability to generate sufficient spark.

Symptoms of a bad igniter glowbar involve:

• Delayed ignition where gas must build up before lighting
• Unreliable or intermittent ignition requiring multiple attempts
• Complete failure of one or more burners to ignite at all

Replacing the glowbar with this genuine GE part helps ensure dependable, easy burner ignition. Consistent glowbar performance is critical for safe range operation.

This OEM GE replacement glowbar is also compatible with various Kenmore, Hotpoint, and RCA gas range/cooktop models.


This dual safety valve controls water flow to two separate appliance water lines, restoring proper fill and preventing unwanted water flow. It's a direct-replacement valve used in appliances that require two independent water outlets. What it does:

• Directs and stops water flow to two separate water circuits when activated
• Prevents continuous or unintended filling if the valve fails
• Commonly linked to no-water-to-dispenser or no-water-to-ice-maker symptoms
• Can cause leaking or intermittent water flow when worn or damaged

• One dual safety valve

• Shut off power and water supply before starting any work
• Drain water lines and place a towel to catch residual water when disconnecting hoses
• Tighten fittings to OEM torque; check carefully for leaks after restoring water

The Igniter Glowbar is an OEM replacement part for GE ovens and ranges. This glowbar generates the pilot flame and ignites the main burner while cooking.

Causes of a bad glowbar can be prolonged or heavy use over time leading to degradation of the element, or damage from impact or mishandling during cleaning.

Symptoms of a bad glowbar include:

• Inability to ignite or light the oven burners
• Pilot light that repeatedly goes out
• Errors codes related to ignition issues
• Burned smell coming from the oven cavity

This GE OEM replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This is the hot surface igniter that glows to light the gas burner. A strong, reliable glow restores consistent oven ignition so preheats start promptly and baking temps stay steady.

• Heats up to ignite the bake or broil burner, allowing gas to light safely
• Weak, cracked, or open igniter can cause no-heat, delayed ignition, or oven not reaching temperature
• Intermittent oven heating or frequent burner cycling can also indicate a failing igniter

• Disconnect power and shut off gas before service; allow oven to cool
• Handle the ceramic igniter carefully—avoid touching the element; it is fragile
• Verify bracket orientation and wire connection style matches your original before install
• After installation, restore gas/electric and check for prompt ignition and normal flame

The Blower Tangential is an OEM component designed specifically for GE ranges. Located near the top of the oven cavity, this tangential blower circulates exhaust air out of the oven and above the cooktop during and after cooking cycles.

Symptoms of a faulty blower include:

• Excessive heat buildup inside the oven and around the cooktop surfaces
• Steam or smoke failing to properly vent outdoors from the oven
• Abnormal noises coming from the blower motor

Causes usually involve failures of the electric motor from years of sustained usage. Physical obstructions blocking the fan housing could also lead to issues.

This genuine GE part is compatible with Hotpoint, RCA, and select Kenmore models as well.

The Pressure Regulator is an OEM component designed specifically for GE gas ranges. Located outside the range near the supply line, this regulator controls incoming gas pressure to safe operation levels.

Symptoms of a faulty regulator include:

• Unstable burner flame heights
• Delayed or inconsistent ignition between burners
• Abnormal operating noises coming from the regulator

Causes usually involve wear of internal springs or diaphragms from years of sustained usage. Exposure to excessive pressure surges could also potentially damage regulator components over time.

This genuine GE regulator is compatible with select Hotpoint and RCA models as well.

This single safety valve controls gas flow to a single burner or heating circuit, restoring safe operation and preventing unintended gas flow. It's a direct replacement part used when the valve is faulty or leaks. What it does

• Regulates and stops gas flow to the appliance when required to maintain safe operation.
• Common symptom: burner or oven won't light or stay lit.
• Common symptom: detectable gas smell near the appliance or valve area.
• Restores normal ignition response when the original valve is worn or fails.

• One safety valve (single) as pictured.

• Turn off gas supply and electrical power before starting any service.
• After installation, check all connections for leaks using an approved leak test solution and restore gas pressure per manufacturer guidance.

This air deviator routes and directs cold airflow inside the refrigerator to balance temperatures between compartments and improve cooling performance. It restores proper air distribution when the original piece is cracked or misaligned. What it does:

• Redirects chilled air from the evaporator to the correct compartment to help maintain even temperatures
• Helps prevent warm spots caused by blocked or misdirected airflow
• Works with the fridge's air circulation path to support normal cooling cycles
• Common symptom: uneven cooling or air bypass near the evaporator cover

• One air deviator

• Inspect and replace only when the existing deviator is broken, warped, or missing
• Handle plastic parts gently to avoid cracking; align tabs before snapping into place
• Always unplug the appliance before accessing internal panels or components
• No special tools typically required;
