Parts for Ge GLDT690D00BB: 04 - Motor-Pump Mechanism Parts

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

The Spray Arm Connector Assembly is an OEM replacement part for GE dishwashers. This assembly connects the upper and lower spray arms to the water inlet valve, allowing water to flow through the spray arms during the wash cycle.

Symptoms of a bad spray arm connector assembly include:

• Uneven or inconsistent water coverage on dishes
• Clogged or kinked spray arm assemblies
• Leaks at the tub connections
• Reduced water pressure impact

Causes of a bad spray arm connector assembly can be mineral buildup affecting water flow, cracked or damaged connectors, or wear over time.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Upper Spray Assembly is an OEM part for GE dishwashers. It is a part located at the top of the dishwasher, designed to distribute water evenly over the dishes during a wash cycle. This part ensures that water reaches all items in the dishwasher, regardless of their placement, facilitating thorough cleaning and rinsing.

Causes of a bad part can include wear and tear from regular use, hard water mineral buildup leading to clogging, or direct damage to the assembly or its outlets.

Symptoms of a bad Upper Spray Assembly include:

• Dishes in the upper rack not being cleaned properly.
• Water not spraying evenly or forcefully from the upper spray arms.
• Noise or rattling sounds from a damaged or obstructed spray arm during a cycle.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This sump clamping nut secures the washer/dishwasher sump seal and housing, helping keep the sump assembly sealed and stable during operation. It's a small but essential fastener for preventing leaks and maintaining proper drainage. What it does:

• Holds the sump/tub seal and sump housing tightly in place to maintain a watertight connection
• Prevents the sump assembly from loosening during spin or wash cycles
• Helps reduce leaks and related water damage when installed correctly
• Works with the factory sump and seal components as the retaining nut

• Replace only with the matching part number; verify orientation before tightening
• Hand-start threads to avoid cross-threading, then tighten to factory spec (do not overtighten)
• Disconnect power and water to the appliance before servicing

This sump gasket seals the dishwasher's sump to the tub to keep wash water contained. Replacing a worn or flattened gasket helps stop leaks and maintain proper wash and circulation performance.

• Creates a watertight seal between the sump/pump assembly and the tub bottom
• Helps prevent leaks onto the floor or into the base pan
• Maintains wash pressure and circulation by preventing air intrusion
• Replace if torn, cracked, deformed, or if water is leaking from the center/bottom of the unit

• Disconnect power and water before servicing; use gloves to protect from sharp edges
• Access the sump from inside the tub or underside (model dependent); remove spray arm/filter as needed and release the retaining ring or tabs
• Clean mating surfaces; install the new gasket evenly without twists and ensure proper orientation
• Reassemble and run a brief fill/wash to check for leaks before fully reinstalling

NOTE: The clamps no longer come with the connector hose. The part number for the clamp is WD01X10322.

This pump hose and clamps create a sealed connection between the dishwasher's pump and internal plumbing. Replace when the hose is cracked or clamps are corroded/loose to stop leaks and restore a secure, watertight fit. What it does:

• Creates a sealed connection between the pump and internal plumbing
• Helps contain water flow during wash and drain operation
• Replace if the hose is cracked, brittle, swollen, or deformed
• Symptoms include water leaking under the dishwasher or loose/corroded clamps

• Disconnect power and water; pull the dishwasher forward as needed for access
• Expect residual water—protect flooring and have a towel or pan ready
• Remove old clamps and hose; fully seat the new hose on fittings, then position and secure clamps at the bead/ridge
• Run a brief cycle and check for leaks before reinstalling

This dishwasher drain pump removes wastewater from the tub at the end of cycles, helping prevent standing water and ensuring proper draining performance. Replacing a failing pump restores efficient water removal and helps avoid wet dishes and odors.

• Pumps water out of the dishwasher to the household drain
• Common symptoms: won't drain or leaves water in the bottom, unusual humming/buzzing during drain, intermittent or slow draining
• Also helps if the pump is seized or electrically failed

• Disconnect power and turn off water before servicing
• Protect the floor from residual water; have towels or a shallow pan ready
• Access is typically from the bottom/front; transfer wiring and hose clamps to the new pump
• Ensure a clear, unkinked drain hose and a clear air gap or disposal inlet after installation

This replacement pressure switch hose routes air/suction from the wash tub to the pressure/water-level switch so the machine can detect fill level and run correctly. It restores reliable pressure signal transfer when the original hose is cracked, split, or blocked. What it does:

• Transfers air pressure from the tub to the pressure/water-level switch so the control senses water level
• Helps prevent overfilling or incorrect fill-level detection caused by leaks or clogs in the hose
• Can resolve symptoms like inconsistent fills, washer not completing cycles, or erratic water-level sensing
• Replaces brittle, collapsed, or hardened tubing that no longer seals

• Disconnect power and water before starting any repair; follow all safety guidance for your appliance
• Inspect hose routing and orientation, then slip new hose onto the same fittings with a secure, snug fit
• Replace any damaged clamps or connectors and avoid kinked or pinched hose routing

Pressure switch that monitors water level and signals the washer control board when to start or stop filling. Replacing a failing pressure switch can help restore correct fill levels and normal cycle operation. What it does:

• Senses air pressure from the tub and tells the control when the correct water level is reached
• Stops the fill valve once the desired level is detected to prevent overfilling
• Can cause underfilling, overfilling, or failure to advance cycles when faulty
• Works with the washer's control system to ensure proper fill and cycle progression

• Disconnect power to the appliance before starting any repair
• Shut off water supply and relieve any trapped water before accessing components
• Carefully disconnect wiring harness and air tube; note routing for reassembly

The Water Valve is an OEM replacement part for GE dishwashers. Located inside the valve body, this electronically-controlled component precisely regulates water inlet and flow during each cycle of the wash sequence. The water valve utilizes sensors and timer modules to open and close water lines at the correct times based on cycle selections.

Symptoms of a defective water valve include:

• Failure to fill or improper filling
• Inability to switch between cycles
• Water leaks from the valve body area
• Erratic or inconsistent water usage amounts

Causes of malfunction often stem from worn internal seals, mineral buildup obstructing valve ports over time, or issues with the electronic control board. Replace yours today with this genuine GE water valve for reliable water control, sensor functions, and trouble-free dishwasher cycles.

This GE replacement part is compatible with Hotpoint, RCA, and Kenmore models.

This fill hose delivers water from the washer inlet valve to the tub, restoring proper water flow and preventing leaks. Replace a cracked, split, or leaking hose to stop water damage and restore normal fill operation. What it does:

• Carries incoming water from the inlet valve to the washer tub during fill cycles
• Stops leaks and water spraying when the original hose is cracked, swollen, or split
• Helps restore normal water fill levels and cycle performance when the hose is failing
• Fits where a direct OEM replacement hose is required for proper seal and routing

• One fill hose

• Turn off water supply and unplug the appliance before starting work
• Inspect inlet valve fittings and hose ends; replace clamps or fittings if worn
• Hand-tighten fittings, then snug with tools—do not overtighten to avoid damage
• Check for leaks after restoring water and power; recheck fittings after a test cycle

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

This sprinkler nozzle directs wash water into a focused spray inside the dishwasher for effective coverage. Replacing a clogged or damaged nozzle restores proper spray pattern and helps improve cleaning results, especially on the upper rack.

• Channels water through the sprinkler assembly for targeted spray coverage
• Maintains the correct spray pattern and pressure for thorough washing
• Replace if clogged with mineral deposits, cracked, loose, or missing
• Symptoms can include poor cleaning, weak/uneven spray, or the upper rack not getting clean

• Disconnect power and water supply before servicing; allow the tub to cool
• Pull out the rack to access the sprinkler area; remove the old nozzle (snap or twist fit varies by model)
• Clean mating surfaces and install the new nozzle securely, ensuring proper alignment
• Run a short test cycle to verify normal spray operation

This small rubber cushion provides a soft stopping surface to reduce noise, vibration and wear where moving parts contact the cabinet or tub. It helps keep components aligned and running quietly for longer. What it does

• Acts as a bumper between moving parts and the cabinet to reduce rattling and impact noise
• Dampens vibration to prevent premature wear on adjacent parts
• Helps maintain proper spacing and alignment for doors, panels or internal assemblies
• Commonly used where a soft, durable contact point is required

• One cushion as shown

• Disconnect power to the appliance before inspecting or replacing the cushion
• Typically installs by pressing into a slot or onto a mounting post; check exact position before removal
• Replace any worn or torn cushions to restore quiet operation and prevent damage

Cylindrical filter that helps trap sediment and debris to protect your appliance's internal components and maintain water flow. Replacing a worn filter restores filtration and helps prevent clogging-related performance issues. What it does:

• Captures sediment and particulates to reduce debris reaching valves, pumps, and dispensers.
• Helps maintain consistent water flow by preventing buildup in flow paths.
• Reduces risk of clogs that can cause noisy operation or degraded performance.
• Common symptom: reduced water flow or visible particles in water/dispensed liquids.

• Turn off power to the appliance and shut off the water supply before starting.
• Relieve pressure and drain water from the lines where applicable to avoid spills.
• Inspect and replace any worn O-rings or seals; ensure the filter seats properly.
• After installation, restore power/water and run a short cycle or check for leaks.

A small self-tapping ST4 x 15.5 screw used to secure appliance panels and components. Replaces lost or damaged mounting hardware to keep parts firmly attached and reduce rattling or movement. What it does

• Secures trim, panels, brackets, or small components to sheet metal or plastic substrates
• Common fix for loose or missing fasteners that cause panel vibration or misalignment
• Helps restore proper fit and prevent parts from shifting during operation

• Disconnect power and/or unplug the appliance before working on it
• Use the correct driver (Phillips) sized for ST4 screws to avoid cam-out or head damage
• Install by hand-starting the screw, then tighten until snug; avoid overtightening to prevent stripping or cracking
• Wear safety glasses and handle sharp sheet metal carefully

This spray arm support block secures the dishwasher's lower spray arm to the tub so the arm can rotate freely and spray dishes evenly. Replaces a worn or broken support to restore proper spray-arm positioning and rotation. What it does:

• Holds the lower spray arm in place and allows smooth rotation during cycles
• Prevents wobbling, binding, or misalignment of the spray arm that can reduce cleaning performance
• Helps stop spray-arm contact with the tub that can cause noise or uneven spray pattern
• Durable plastic piece designed to withstand normal dishwasher conditions

• One spray arm support block

• Disconnect power and turn off water supply before starting any repair
• Remove the bottom rack and lower spray arm to access the support block
• Snap the new block into the tub mounting point, reinstall the spray arm, and confirm it spins freely
• If the spray arm or mounting post is damaged, inspect and replace additional parts as needed
