Parts for Lg LPXS30866D/00: Other Parts

The Water Filter LT800P is an OEM part for LG refrigerators. This filter is designed to remove contaminants from the water supply, ensuring clean and fresh-tasting water and ice.

Causes of a bad water filter can include extended use beyond its recommended lifespan, exposure to high levels of contaminants, or damage to the filter itself.

Symptoms of a bad Water Filter LT800P include:

• Unpleasant taste or odor in the water or ice
• Reduced water flow from the dispenser
• Indicator light signaling the need for replacement
• Visible sediment or particles in the water

This OEM LG part is also compatible with Sears/Kenmore.

This is a replacement drain tube assembly that directs water from the appliance tub to the drain pump or household drain, helping restore proper water removal and reduce leaks. It's a direct-fit service part used in the drainage system. What it does:

• Channels wastewater away from the tub to the drain pump or drain line
• Helps prevent pooling or slow draining caused by a damaged or disconnected tube
• Restores a sealed path to reduce leaks at the tub-to-pump connection
• Suitable when the original drain tube is cracked, split, collapsed, or leaking

• One drain tube assembly as shown

• Disconnect power and water before beginning any repair to avoid shock or flooding
• Inspect and clean mating surfaces and clamps; replace clamps if corroded or damaged
• Ensure correct routing and secure connections to prevent kinks and leaks

This drain tube assembly channels defrost water from the evaporator to the drain pan, preventing leaks and water buildup. Replace a cracked or clogged tube to restore proper drainage and reduce puddles or ice inside your refrigerator.

• Directs defrost water from the drain outlet to the drain pan
• Helps prevent water leaks inside the fresh food or freezer compartment
• Addresses issues from a tube that is cracked, kinked, or obstructed by debris/ice
• Common symptoms: water under crisper drawers, puddles beneath the unit, or ice forming at the freezer bottom

• Unplug the refrigerator before servicing
• Access the drain outlet and remove any ice or debris from the drain path
• Fully seat the tube at both ends to ensure a secure, leak-free fit
• Test by pouring a small amount of warm water into the drain to confirm proper flow to the pan

The Air Cleaner Filter Assembly is an OEM part for LG refrigerators. This part ensures the air within the appliance remains fresh and free of contaminants. This part minimizes odors and filtering out particulates, thereby maintaining the quality of the air circulating through the refrigerator and its contents.

Over time, the effectiveness of the air cleaner filter can diminish due to the accumulation of particles and odors it has trapped. A decrease in air quality within the refrigerator, persistent odors despite cleaning, and an increase in the spoilage rate of food items can all be signs that the filter assembly may need replacement.

Symptoms of a bad Air Cleaner Filter Assembly include:

• Persistent unpleasant odors inside the refrigerator
• Increased spoilage of food items
• Noticeable reduction in air freshness or quality

This OEM LG part is also compatible with some Kenmore models.

This cover assembly is a molded exterior panel that shields and finishes the appliance. Replacing a cracked or missing cover restores proper fit and protection for internal components, and keeps the unit looking the way it should.

• Protects internal components by covering and sealing the opening
• Helps maintain proper alignment with adjacent parts and trim
• Reduces gaps where dust and debris can enter
• Common signs of failure: cracks, broken tabs, loose fit, rattling, or visible damage

• Disconnect power; for appliances with water connections, shut off the water supply
• Note screw locations and take photos before removal for reference
• Transfer any clips, gaskets, badges, or lenses from the original as needed
• Align tabs and mounting holes; snug fasteners without overtightening and confirm clearances before restoring power

The Temperature Sensor is an OEM part for LG refrigerators. It monitors the internal temperature and sends this information to the control board, ensuring that the refrigerator maintains the correct temperature for optimal food preservation.

Over time, temperature sensors can fail due to electrical issues, exposure to moisture, or wear and tear from continuous use.

Symptoms of a bad temperature sensor include:

• Inaccurate temperature readings
• The refrigerator or freezer being too warm or too cold
• The refrigerator running constantly or not running at all
• Error codes displayed on the control panel

This OEM LG part is also compatible with Sears/Kenmore models.

This ferrite magnet is a replacement magnetic element used in compatible appliance assemblies to help secure components and maintain proper alignment. It restores magnetic retention and reduces shifting or misalignment during operation. What it does:

• Provides magnetic retention for panels, assemblies or components that rely on ferrite magnets
• Helps maintain proper alignment and secure closure where magnets are used
• Can reduce noise and vibration related to loose magnetic components
• Useful when a brittle, cracked or weak magnet no longer holds parts in place

• Disconnect power and follow the appliance manufacturer's safety instructions before servicing
• Handle the magnet carefully; ferrite material is brittle and can chip or shatter if dropped or struck
• Keep magnets away from sensitive electronics and credit cards; avoid pinching fingers between strong magnets
• If the original magnet is bonded or embedded, some adhesive or light trim may be needed for proper fit.

This refrigerator door gasket seals the door to the cabinet to keep cold air in and humid air out. Replacing a worn or torn seal restores proper temperatures, reduces frost and condensation, and helps the unit run efficiently.

• Creates an airtight seal between the door and cabinet perimeter
• Helps maintain internal temperature stability and energy efficiency
• Reduces frost/ice buildup and moisture around the door opening
• Common symptoms: visible tears or warping, gaps, door not sealing, warm spots, frost or condensation near the door

• Unplug the appliance before servicing
• Let the new gasket relax flat at room temperature, or gently warm it to make it more pliable
• Clean the sealing surfaces; seat corners first, then work evenly along the sides
• Close the door and check for uniform contact all around; adjust as needed for a consistent seal

This refrigerator door gasket assembly restores a tight, even seal around the door. A proper seal keeps cold air in and moisture out, helping maintain temperature, reduce frost and condensation, and prevent warm spots around the perimeter.

• Forms a continuous seal between the door and cabinet to prevent air leaks
• Helps maintain stable internal temperature and humidity
• Reduces frost/ice and condensation near the door area
• Replace if the gasket is torn, cracked, deformed, or won't sit flat
• Symptoms include gaps around the door, moisture on the gasket, frost buildup, or a door that won't close/seal properly

• Unplug the refrigerator before servicing
• Let the new gasket relax; use warm water or low heat to remove shipping creases
• Insert the gasket lip fully into the door's channel, starting at the corners, then work along the sides
• After installation, close the door and check for uniform contact all around; adjust the gasket as needed

This rubber door stopper cushions and limits appliance door movement to prevent hard closing, reduce noise, and protect the cabinet and door edge from damage. Designed as a direct-fit replacement for the original factory bumper. What it does:

• Absorbs impact when the door closes to reduce slamming and rattling
• Keeps the door aligned and prevents metal-on-metal contact or chipping
• Helps maintain door seal integrity by stabilizing closing position
• Commonly replaced when worn, torn, or missing and causing noise or misalignment

• One rubber door stopper

• Basic push-fit replacement—remove the old bumper and press the new stopper into the mounting hole
• Inspect the mounting boss for damage; replace the housing if the mounting area is broken
• Disconnect power or ensure appliance is off and stable before working on doors for safety
• No special tools typically required; use a flat tool for leverage if the old bumper is stuck

This door stopper cushions and limits a refrigerator or appliance door's movement to reduce slamming and protect the cabinet and hinge. It restores smooth, quiet door closing and helps keep the door aligned. What it does

• Absorbs impact when the door is opened or closed to prevent slamming and wear.
• Limits door travel to protect hinges and adjacent cabinet surfaces.
• Helps maintain proper door alignment for a better seal and quieter operation.
• Commonly replaced when the stopper is worn, cracked, or missing.

• One door stopper

• Disconnect power to the appliance or follow manufacturer safety guidance before servicing.
• Typically attaches at the door or frame with a screw or snap fit; remove trim or access panels if needed.
• Inspect surrounding mounting area and replace any worn fasteners or brackets.

This refrigerator door basket assembly replaces a cracked or missing door bin to restore secure storage for bottles, jars, and condiments. It mounts to the door liner to keep items organized and easy to reach. What it does:

• Attaches to the door liner to provide shelf-style storage
• Restores lost capacity and organization when a bin is broken or missing
• Helps keep beverages and condiments stable during door movement
• Common symptoms: cracked plastic, broken locking tabs, bin won't stay seated, items falling, door interference

• 1 door basket assembly

• Unplug the refrigerator and remove items from the affected bin area
• Lift the old bin straight up to disengage the tabs, then pull it out
• Align the new bin with the door liner mounts and press down until fully seated
• Verify the door closes freely and avoid overloading the new bin

The Ice Door Handle Roller is an OEM replacement part for LG and some Kenmore refrigerators. Each handle contains two rollers and they help the handle move smoothly and prevent any unnecessary wear and tear. Please note, this is for one (1) door handle roller. It is recommended to replace both at the same time.

Symptoms of a bad Ice Door Handle Roller include:

• Difficulty in dispensing ice, with the chute door sticking or not opening properly.
• Noises such as squeaking or grinding when the ice door is activated.
• Increased effort needed to operate the ice dispenser handle.
• Visible wear or damage to the roller, affecting its movement.

Causes of a bad ice door handle roller can include mechanical wear from regular use, debris accumulation that impedes the roller’s movement, or damage from excessive force used on the dispenser handle.

This OEM LG part is also compatible with Sears/Kenmore models.

This door stopper cushions and limits the appliance door's movement to help prevent slamming, misalignment, and wear. A small replacement part that restores smoother, quieter door operation. What it does:

• Absorbs impact when the door closes to reduce noise and shock
• Keeps the door from over-travel that can cause misalignment or rubbing
• Helps the door latch and seal properly by stabilizing movement
• Stops rattling or binding caused by a worn or broken stopper

• Disconnect power to the appliance before starting any repair
• Access may require opening or removing the door or a trim panel; use basic hand tools
• Remove the old stopper and install the replacement in the same position and orientation

This Door Stopper is the hinge-mounted stop that limits your refrigerator door's swing. Replacing a worn or broken stopper restores smooth, controlled movement and helps protect hinges and nearby cabinetry from overextension. What it does:

• Controls the door opening angle on the hinge to prevent overextending
• Helps maintain door alignment for a reliable seal and smooth closing
• Reduces clunking or clicking at the hinge caused by a worn stop
• Replace if the door swings too far, binds, won't close smoothly, or the stopper is cracked/missing

• 1 door stopper

• Disconnect power and support the door to relieve hinge load before service
• Remove hinge cover/fasteners as needed and note the old stopper's orientation
• Install the new stopper on the hinge/bracket, reassemble, and check door travel
• Verify the door seals fully and opens within the normal range

The Spanner Wrench is an OEM replacement part for LG refrigerators. This tool allows you to adjust the door hinges to ensure the doors are level and aligned properly. A well-aligned door is crucial for maintaining the internal temperature and efficiency of the refrigerator, preventing energy loss and ensuring food is stored under optimal conditions.

Symptoms that you might need to adjust the door hinges and potentially need this wrench include:

• Doors not closing properly or sealing tightly
• Visible gaps between the door and the main body of the refrigerator
• The refrigerator tilting or not sitting level

This spanner wrench is also compatible with some Sears/Kenmore refrigerators.

This lever holder is the replacement mounting bracket that secures the door lever so the microwave door operates smoothly and reliably. It restores proper lever alignment to help the door latch and release as intended. What it does:

• Secures the door lever assembly so the door can latch and release properly
• Keeps the lever aligned to prevent binding, sticking, or loose movement
• Helps restore normal door operation and user access to the oven cavity
• Common symptom: door feels loose, lever moves freely, or door will not latch

• Disconnect power before beginning any repair to avoid shock or injury
• Remove the outer cabinet or door trim only as needed to access the lever area
• Handle door components and glass carefully to avoid damage or injury

NOTE: This part also requires software update kit CJT30000002. DO NOT INSTALL WITHOUT UPDATING SOFTWARE. Call for more information.

The Compressor is an OEM part for LG refrigerators. As the primary component that circulates refrigerant to chill the refrigerator and freezer compartments, it is crucial for proper cooling operation. The compressor works with the condenser fan and evaporator coil to regulate temperatures inside the refrigerator.

Causes of a faulty compressor can include gradual breakdown of motor windings, loss of refrigerant pressure over time, or failure of electrical components vital to operation.

Symptoms of a bad compressor are:

• Elevated fridge/freezer temperatures unable to be maintained
• Frost patterns indicating poor or insufficient cooling
• Abnormal vibrations or sounds upon compressor cycling
• Error codes displayed regarding cooling performance

It is also compatible with Sears/Kenmore refrigerator models.


The Thermistor Assembly is an OEM part for LG refrigerators. It serves a crucial function in monitoring and regulating the temperature within the appliance. By sensing temperature changes, the thermistor sends information to the refrigerator’s control board, ensuring the system adjusts cooling to maintain the desired temperature settings.

Symptoms of a failing thermistor assembly include:

• Inconsistent temperatures in the refrigerator or freezer
• Refrigerator running longer than usual or not cooling efficiently
• Frequent fluctuations in temperature readings

Causes of thermistor assembly failure typically involve electrical faults, damage from moisture or frost, or simple wear over time, which can impact its ability to accurately measure and report temperatures.

This OEM LG part is also compatible with Sears/Kenmore.

The Overload Compressor is an OEM part for LG refrigerators. This part protects the refrigerator's compressor from overheating and potential damage by acting as a safety device. It works by monitoring the compressor's electrical current and temperature. If the compressor operates under conditions that could lead to overheating or overcurrent, the overload protector will cut off the power to the compressor, allowing it to cool down before potentially restarting.

Causes of damage to the Overload Compressor can include power surges, electrical faults within the refrigerator, or a malfunctioning compressor that requires more current than usual to operate.

Symptoms of a bad Overload Compressor include:

• The refrigerator not cooling properly or not cooling at all
• The compressor failing to start, indicated by a clicking sound coming from the back of the refrigerator where the compressor is located.
• The refrigerator or freezer section warming up

This OEM LG part is also compatible with some Kenmore models.

This PTC cover is the protective housing that shields a PTC sensor/assembly from debris and physical damage, helping maintain reliable sensor performance and prolong component life in the appliance. What it does:

• Protects the PTC sensor or PTC assembly from dust, impact, and accidental contact
• Helps prevent shorting or intermittent sensor signals caused by contaminants
• Supports proper positioning and mounting of the PTC component
• Can help address symptoms such as visible sensor damage, exposed wiring, or intermittent operation related to a compromised sensor housing

• Disconnect power to the appliance before starting any repair
• Remove the outer panel(s) as needed to access the PTC location; handle surrounding wiring and components carefully
• Replace only with the correct OEM cover to ensure proper fit and protection

This compressor damper is a vibration-isolating mount that sits between the sealed-system compressor and the chassis. It cushions the compressor to reduce noise, limit vibration transfer, and help keep refrigerant lines from being stressed.

• Isolates the compressor from the frame to absorb start/stop shock and vibration
• Helps reduce humming, rattling, or buzzing from the back/bottom of the appliance
• Replaces a damper that's cracked, flattened, hardened, or missing
• Can help if the compressor rocks or the unit vibrates excessively

• Disconnect power and pull the unit forward for access; remove rear/service panel if present
• Support the compressor to relieve load on the mounts before removing fasteners
• Match orientation; transfer any sleeves/spacers from the old damper to the new one
• Ensure the compressor sits level and that tubing is not strained before restoring power

This drip tray catches and channels water runoff inside the appliance to help prevent pooling and minor leaks. It's a direct-fit replacement listed by the manufacturer and sold as the single tray used in the unit. What it does

• Collects condensate or defrost water and directs it to the drain area to prevent pooling.
• Helps stop water from dripping onto lower drawers, shelves or the floor.
• Commonly replaces a cracked, warped or missing tray that causes visible leaks or water buildup.
• Fits into the appliance's lower compartment where the original tray sat.

• Unplug the appliance or disconnect power before servicing.
• Remove any obstructing drawers or shelves to access the tray location; handle glass shelves carefully.
• Lift out the old tray and set the new tray into the same position; no special tools typically required.

Replacement fan guide that directs airflow from the refrigerator fan to improve cooling distribution and help keep the fan blade clear of nearby components. Restores proper airflow and can reduce rubbing or scraping noises. What it does:

• Channels airflow from the fan to promote even temperatures throughout the compartment.
• Keeps the fan blade aligned and away from cabinet walls and other components.
• Commonly replaced when cracked, warped, or broken parts cause rubbing or unusual fan noise.
• Helps maintain efficient cooling by restoring the intended airflow path.

• Disconnect power (unplug or shut off breaker) before servicing the appliance.
• Access typically requires removing the interior cover or rear evaporator cover.
• Handle the plastic guide carefully to avoid cracking; align mounting tabs and secure using the original fasteners.
• Inspect the fan blade and motor for damage while replacing the guide; replace any damaged components to avoid repeat issues.

This small stopper installs in the refrigerator to limit the travel of a moving component and keep it securely in place. Replacing a broken or missing stopper prevents over-extension and helps maintain smooth, aligned operation.

• Limits the range of motion for a door, bin, or drawer to prevent over-opening or accidental removal
• Helps keep interior components aligned and operating smoothly
• Replace if cracked, missing, or deformed
• Common symptoms: drawer or bin slides out too far, door swings past normal range, or a broken plastic stop is found

• Disconnect power before servicing; remove or support the affected bin/drawer/door
• Note the old stopper's orientation and location before removal
• Transfer and reuse any original screws or clips if applicable
• Snap or fasten the new stopper in place and test for smooth movement

A small retaining pin used to secure moving parts and keep components aligned for smooth operation. Replacing a worn or broken common pin can stop rattling and restore proper fit between linked parts. What it does:

• Holds or aligns two parts together so they move correctly and stay in position
• Helps prevent rattling, looseness, or parts slipping out of place
• Works as a simple mechanical fastener—no electronics involved

• One common pin

• Disconnect power to the appliance before beginning any service
• Keep track of small parts; lay out components in order to aid reassembly
• May require removal of trim or a hinge/retainer to access the pin—use basic hand tools
• If the pin is difficult to seat, do not force; inspect mating parts for damage

This cabinet roller supports the refrigerator and lets the unit roll in and out of place for cleaning or service. Replace a worn or broken roller to restore smooth movement and help keep the appliance properly positioned.

• Supports the base of the refrigerator and enables rolling movement
• Helps with safe positioning and service access without dragging
• Common failure signs: appliance is hard to move, scraping or rolling noises, a flat-spotted/cracked wheel, or a wheel that won't turn
• Replace when the roller is damaged, seized, or missing

• Disconnect power and shut off water supply; protect flooring before moving the appliance
• With help, pull the refrigerator forward and safely support it to access the roller
• Remove mounting fasteners, install the new roller, and reuse original hardware
• Confirm level and smooth movement before returning the unit to its location

The Drier Assembly is an OEM part for LG refrigerators. This part is responsible for removing moisture and contaminants from the refrigerant. This ensures that the refrigerant circulates effectively and efficiently, preventing damage to other components and maintaining the refrigerator's cooling performance.

Causes of a bad Drier Assembly can include contamination from moisture entering the refrigerant lines, blockages from debris or particulates, and general wear and tear over time that reduces its effectiveness.

Symptoms of a bad Drier Assembly include:

• Reduced cooling efficiency or warm refrigerator temperatures
• Unusual noises from the refrigeration system
• The compressor running continuously or cycling frequently
• Frost buildup on the evaporator coils due to improper refrigerant flow

This OEM LG part is also compatible with Sears/Kenmore models.

This holder is a small mounting bracket used to secure internal components in place, helping keep parts aligned and stable for reliable operation. It provides a direct, OEM-compatible replacement to restore proper fit and function. What it does

• Secures and supports nearby components to prevent shifting or vibration.
• Restores proper alignment where a worn or broken holder causes rattling or loose parts.
• Helps maintain normal operation by keeping assemblies seated correctly.
• Works behind panels or inside assemblies where a dedicated bracket is required.

• One holder/mounting bracket as shown.

• Installation generally requires removing the panel or access cover where the holder is located.
• Use proper fasteners shown in your appliance; replace any damaged screws or clips as needed.
• Disconnect power before servicing electrical appliances to reduce shock risk.

Door switch magnet for reed switch

The Dispenser Micro Switch is an OEM part for LG refrigerators. It is a component of the ice and water dispensing system, responsible for activating the dispenser when the lever is pressed.

Causes of a bad Dispenser Micro Switch can include mechanical wear from frequent use, failure due to moisture or debris affecting the switch’s contacts, or electrical faults that prevent proper signaling.

Symptoms of a bad Dispenser Micro Switch include:

• The dispenser not releasing ice or water when the lever is pressed.
• Continuous dispensing or dripping after the lever is released.
• Intermittent or no response from the dispenser controls.

This OEM LG part is also compatible with Sears/Kenmore.

The Temperature Sensor is an OEM part for LG refrigerators, designed to monitor and relay the temperature inside the refrigerator to the control board. This component ensures that your refrigerator maintains the correct temperature to keep your food fresh and safe to eat.

Over time, temperature sensors can fail or become less accurate due to wear and tear, environmental factors, or electrical issues. This can lead to problems such as the refrigerator cooling too much or not enough, resulting in food spoilage or excessive energy consumption.

Symptoms of a bad Temperature Sensor include:

• The refrigerator or freezer is too warm or too cold, despite setting adjustments
• Unusual fluctuations in temperature, indicating the sensor is not accurately detecting or communicating the internal temperature
• The refrigerator runs constantly or more frequently than normal, attempting to reach the desired temperature

This OEM LG part is also compatible with some Kenmore models.

This DC motor powers the washer's drum rotation, restoring normal spin and agitation so loads wash and rinse effectively. Designed to replace a worn or failed drive motor for reliable drum movement and consistent cycle performance. What it does:

• Spins the drum and controls agitation for wash and rinse cycles
• Restores normal spinning when the washer won't agitate or spin
• Helps reduce noisy, uneven, or intermittent drum rotation when the motor is the cause
• Works with the washer's electronic controls to regulate motor speed and direction

• One DC drive motor

• Disconnect power before starting and follow the washer manufacturer's service manual
• Basic disassembly of the cabinet and drum support is typically required; keep fasteners organized
• Verify wiring connectors and mounting orientation match the removed motor before final assembly
• Check control board and wiring for faults

This power cord assembly connects your appliance to household power and replaces a damaged or worn cable to restore safe electrical connection. It provides a direct-fit replacement using the original cord routing and plug style. What it does

• Supplies line voltage to the appliance so it can power on and operate
• Replaces frayed, cut, melted, or otherwise damaged cords that cause intermittent power or no power
• Helps stop arcing or sparking at the cord connection when the cord or plug is compromised
• Restores a secure plug connection when the original cord no longer seats properly

• One power cord assembly

• Always unplug the appliance or shut off power at the breaker before replacing the cord
• Route the cord following the original path and secure strain-relief fasteners if present
• Do not modify the cord or plug; use the exact replacement for safe fit and grounding

Door switch magnet for reed switch

The Door Bracket is an OEM part for LG refrigerators. This bracket supports the refrigerator door by providing stability and ensuring proper alignment during opening and closing. It plays a crucial role in maintaining the door’s secure fit, which is essential for maintaining the internal temperature and efficiency of the appliance.

Common causes of a bad door bracket include wear and tear from frequent use, impact damage, or corrosion due to moisture.

Symptoms of a bad door bracket include:

• The refrigerator door not closing properly
• The door sagging or being misaligned
• Unusual noises when opening or closing the door
• Gaps in the door seal leading to temperature inconsistencies

This OEM LG part is also compatible with Sears/Kenmore.

This LED assembly restores backlight illumination for compatible LG displays, improving screen brightness and uniformity so images look clearer and easier to see. It replaces a worn or failed backlight strip. What it does:

• Provides the backlight illumination that lights the LCD panel
• Restores overall brightness and reduces dark or dim areas
• Can stop flickering or intermittent light if LEDs are failing
• Helps eliminate uneven lighting or bright/dark bands across the screen

• One LED assembly (single backlight strip) as shown

• Disconnect power and allow capacitors to discharge before starting
• Handle the LED strip and circuit board by the edges; avoid touching LED surfaces and PCB traces
• Keep track of screws and clips; test the display before fully reassembling

This PCB power control board assembly controls power and electronic functions for the appliance's control module, restoring reliable control signals and power distribution when the original board fails. What it does:

• Regulates and routes low-voltage power to the appliance control circuitry
• Provides the electronic interface for user controls and display functions
• Can stop erratic operation or unresponsive controls when the board is faulty
• When the appliance shows blank/partial display, fails to start, or throws control-related errors

• One PCB power control board assembly

• Disconnect power before inspecting or replacing the board to avoid shock or equipment damage
• Handle the PCB by its edges and avoid touching components to prevent static or oil damage
• Verify connector orientation and seating; do not force connectors or bend pins

This sub PCB assembly is an electronic control board that processes inputs and switches components, coordinating specific appliance functions. Replacing a failed board can restore normal operation and resolve dead controls, error codes, or intermittent, unpredictable behavior. What it does:

• Distributes and regulates control power and switches loads via onboard relays/triacs
• Interprets signals from sensors and the user interface to execute commands
• Coordinates timing and operation of related components per the appliance's program logic
• Failure may present as no power, won't start, unresponsive or flickering display, random beeps, or recurring error codes

• 1 sub PCB assembly

• Disconnect power to the appliance before servicing; verify no voltage is present
• Use ESD protection and handle the board by the edges
• Photograph wiring; transfer connectors one at a time and ensure they are fully seated
• Secure the board with existing fasteners/standoffs; perform any required reset or diagnostic per your model's service info

The Ice Maker Assembly Kit is an OEM part for LG refrigerators. It is responsible for producing and storing ice within the freezer compartment. The kit includes all necessary components to create ice, ensuring a steady supply for household needs.

Over time, the ice maker can become faulty due to various reasons. Causes of a bad ice maker assembly can include mineral build-up from hard water, wear and tear of moving parts, or electrical component failures. These issues can impair the ice maker's functionality, leading to inconsistent or no ice production.

Symptoms of a bad ice maker assembly include:

• The ice maker not producing ice
• Leaking water around the ice maker
• Ice cubes that are misshapen or smaller than usual
• Unusual noises coming from the ice maker

This OEM LG part is also compatible with Sears/Kenmore.

This small retaining clip secures its mating component within the refrigerator assembly, keeping parts properly seated and reducing vibration. Replacing a damaged or missing clip helps restore a snug fit and reliable operation of the attached piece.

• Holds the designated part firmly in place within the assembly
• Maintains proper alignment to prevent movement or rattling
• Helps ensure panels, ducts, or lines stay secured during use
• Symptoms can include loose or sagging parts, vibration noises, or components that won't stay attached

• Disconnect power; if working near the water system, also shut off the water supply
• Note the original orientation and placement before removal
• Fully seat the mating component, then press the new clip into place without forcing
• Check operation before reassembly

The Ice Dispenser Auger Motor is an OEM part for LG refrigerators. This part is designed to drive the auger that moves ice from the ice bin into the dispenser chute. This motor ensures that ice is available on demand through the door dispenser.

Causes of a bad Ice Dispenser Auger Motor can include electrical issues such as a burnt-out motor, wear and tear on the motor's components over time, or damage from moisture or ice buildup that can affect the motor's functionality.

Symptoms of a bad Ice Dispenser Auger Motor include:

• The ice dispenser not dispensing ice, even though the ice bin is full.
• A humming or buzzing sound from the motor area without any ice being dispensed, indicating the motor is receiving power but failing to turn the auger.
• Intermittent or inconsistent dispensing of ice, which can suggest a failing motor.

This OEM LG part is also compatible with Sears/Kenmore.

This holder assembly is a structural mounting piece that supports and secures an internal component in your appliance. Replacing a cracked or worn bracket helps restore proper alignment and keeps parts stable during everyday use.

• Provides a rigid mounting point for the attached component
• Keeps parts aligned to reduce movement and vibration
• Helps prevent rattling or noise from loose mounts
• Common signs of failure: visible cracks/broken tabs, looseness, or parts that won't stay seated

• Disconnect power and, if applicable, turn off the water supply before service
• Note the orientation of the original part to match fitment
• Reuse existing mounting screws or hardware unless the manufacturer specifies otherwise
• Do not overtighten fasteners; the secured component is fully seated and stable

This sensor PCB assembly detects and relays sensor signals to the appliance control system, restoring accurate sensor feedback and communication when the original sensor board fails or malfunctions. Designed as a direct replacement board. What it does:

• Reads sensor inputs and converts them to signals the main control board can interpret.
• Replaces a failed or intermittent sensor board that causes incorrect readings or sensor-related error codes.
• Can resolve symptoms such as unexpected sensor faults, control errors, or appliances not responding to sensor changes.
• Matches the OEM board function; verify model compatibility before ordering.

• Always disconnect power before servicing to avoid shock or shorting the board.
• Use ESD precautions and handle the PCB by its edges to prevent static damage.
• Ensure all connectors are fully seated and the board is mounted in the original orientation.

This assembly stores ice and delivers it from the ice maker to the dispenser. Replace it when the bin is cracked, warped, or its drive components are damaged, causing weak dispensing, jams, or being stuck on one ice type.

• Stores ice and interfaces with the dispenser system to deliver cubes or crushed ice
• Resolves no or weak ice dispensing
• Corrects grinding/clicking noises or auger jamming from a damaged bin
• Addresses visible cracks, broken tabs, or a bucket that won't seat securely

• Disconnect power to the refrigerator before servicing
• Open the door and pull the old bucket straight out; depress any release tab if equipped
• Align and seat the new assembly fully so the drive coupling engages—do not force it
• Restore power and test the dispenser (cube and crush selections)

This AC motor powers the appliance's fan or blower to move air through the system. Replacing a worn motor restores proper airflow to support cooling/ventilation and protect internal components from overheating. What it does:

• Rotates the fan/blower to circulate air through the appliance
• Helps maintain proper temperatures and component cooling
• Common failure signs: fan won't start, starts then stalls, weak airflow, loud humming/grinding, overheating or safety shutoffs
• Often required when motor bearings seize or windings fail

• 1 AC motor

• Disconnect power and allow hot components to cool before servicing
• Note wire positions; transfer any brackets, grommets, or the fan blade from the original motor if reused
• Clear debris and restore power and verify smooth, quiet airflow

The Connector (Mech), Tube is an OEM part for LG refrigerators. It is used to securely connect water tubing within the refrigerator, ensuring a reliable flow of water to components such as the ice maker and water dispenser.

Causes of a bad connector can include wear and tear over time, physical damage from improper installation or handling, or degradation due to exposure to varying temperatures and water pressure.

Symptoms of a bad connector include:

• Leaks or drips around the connector area
• Reduced water flow to the ice maker or water dispenser
• Water pooling inside or around the refrigerator
• The ice maker or water dispenser not functioning properly

This OEM LG part is also compatible with Sears/Kenmore models.

The Reservoir Water Supply Line is an OEM part for LG refrigerators. This component is essential for delivering water from the reservoir to the dispenser and ice maker, ensuring a steady and reliable flow.

Symptoms of a bad Reservoir Water Supply Line include:

• Leakage of water at connection points or along the line.
• Reduced water flow to the dispenser or ice maker.
• Unusual tastes or odors in the dispensed water.
• Visible signs of wear, such as kinks or brittleness.

Causes of a bad water supply line can include physical damage from bending or pinching, chemical degradation from exposure to contaminants, or blockages due to sediment or scale buildup.

This OEM LG part is also compatible with Sears/Kenmore.

This gas valve assembly controls and shuts off the flow of gas to your appliance's burner system, enabling safe ignition and steady heat. Replacing a sticking or failing valve restores reliable heating performance and consistent flame control.

• Regulates gas flow to the burner(s) as commanded by the control/thermostat
• Works with the igniter to light the flame
• Helps maintain stable gas supply for consistent heating
• Failure symptoms include no ignition, igniter glowing with no flame, intermittent heat, or a weak/uneven flame

• Disconnect power and shut off the gas supply before servicing
• Allow the appliance to cool and work in a well-ventilated area
• Transfer any fittings or brackets from the original valve if required
• After installation, restore gas and check all connections for leaks with a soapy-water solution

This refrigerator water filter assembly conditions the water supplied to the dispenser and ice maker, helping deliver cleaner, better-tasting water and ice while maintaining proper flow. Replace regularly to keep your fridge's water system performing as designed. What it does:

• Filters incoming water for the dispenser and ice maker
• Helps improve taste and clarity of water and ice
• Supports proper dispenser flow and consistent ice production
• Replace when the filter indicator turns on or water/ice quality declines

• Dispense water to relieve line pressure; place a towel to catch any drips
• Remove the old filter and seat/lock the new cartridge fully—do not overtighten
• Flush water until it runs clear, and reset the filter indicator

The Water Inlet Valve Assembly is an OEM part for LG refrigerators. This part controls the flow of water into the refrigerator's ice maker and water dispenser. By opening and closing at specific times, it ensures the proper amount of water is supplied for making ice or dispensing water.

Causes of a bad water inlet valve include clogs from sediment, failure of the solenoids, or cracks in the valve body.

Symptoms of a bad Water Inlet Valve Assembly include:

• No water being dispensed
• Slow or irregular water flow from the dispenser
• Leaks occurring at the back of the refrigerator where the valve is located
• The ice maker not producing ice or producing very small ice cubes

This OEM LG part is also compatible with some Kenmore models.

This cover cap is a small plastic trim piece that protects exposed fasteners and improves the appliance's appearance. It snaps into place to hide mounting posts and help prevent snags or debris buildup. What it does:

• Covers and protects exposed screws, posts, or fasteners for a finished look
• Prevents lint, dust, and debris from collecting around the mounting point
• Reduces the chance of fabric snags or contact with sharp edges
• Restores worn or missing trim for improved cosmetics

• Disconnect power to the appliance before starting any service that exposes electrical components
• Usually installs by snapping over the post or press-fitting into the trim opening — no special tools required
• If needed, remove adjacent trim pieces to gain access, then reinstall trim in reverse order
• Inspect surrounding mounting hardware for damage and replace if necessary

Replacement filter assembly head that holds and seals the refrigerator water filter cartridge and routes water to the dispenser and ice maker. Replaces damaged or worn filter heads to restore proper filter seating and help prevent leaks. What it does:

• Secures and aligns the water filter cartridge so the filter can seat and seal correctly.
• Channels water from the filter to the dispenser and ice maker.
• Stops leaks and drips caused by cracked, warped, or damaged filter head components.
• Restores proper water flow where a broken filter head was causing reduced or no water dispense.

• One filter assembly head.

• Turn off the refrigerator water supply and dispense water to relieve pressure before replacing.
• Remove the old filter and head per your owner's manual; install the new head and re-seat the filter until it locks.
• Check all connections for leaks after turning the water back on; hand-tighten only and avoid over-torquing.

The Water Filter LT800P is an OEM part for LG refrigerators. This filter is designed to remove contaminants from the water supply, ensuring clean and fresh-tasting water and ice.

Causes of a bad water filter can include extended use beyond its recommended lifespan, exposure to high levels of contaminants, or damage to the filter itself.

Symptoms of a bad Water Filter LT800P include:

• Unpleasant taste or odor in the water or ice
• Reduced water flow from the dispenser
• Indicator light signaling the need for replacement
• Visible sediment or particles in the water

This OEM LG part is also compatible with Sears/Kenmore.

This lower hinge assembly secures and supports the refrigerator door pivot, restoring proper door alignment and smooth opening/closing. Replace a worn or damaged lower hinge to stop sagging, help seal performance, and reduce rubbing or binding. What it does:

• Provides a stable pivot point for the lower side of the refrigerator door.
• Corrects door sagging or misalignment that can cause poor sealing or uneven gaps.
• Reduces rubbing, scraping, or binding when opening and closing the door.
• Restores proper door operation after impact damage or worn hinge components.

• One lower hinge assembly

• Disconnect power and remove food from the door area before starting; support the door to prevent dropping during removal.
• Keep all original fasteners if they are undamaged; some models may reuse screws or pins.
• Use appropriate tools and take care not to damage the door finish or gasket; wear gloves to protect hands.

This is the Home Bar cover — the molded door shelf cover that protects and conceals the refrigerator's door-in-door/home bar compartment for organized storage and a finished appearance. It restores a secure, clean barrier for items stored in the home bar. What it does:

• Replaces a cracked, chipped or missing home-bar/door-in-door shelf cover
• Keeps small bottles and items contained when the home bar is opened and closed
• Restores the proper fit and appearance of the door-in-door/home bar area
• Helps prevent items from falling out of the home bar compartment

• One Home Bar cover

• High-level replacement: usually removes and snaps into the door-in-door shelf housing; some models may require removing the inner door panel or a few fasteners
• Use basic hand tools; keep track of small screws and clips during reassembly
• Inspect surrounding clips and supports; replace any damaged fasteners for a secure fit
• For safety, close the door fully and check smooth opening/closing after install

The Lever Cover is an OEM part for LG refrigerators. This cover fits neatly over the freezer door lock mechanism, protecting its internal lever and hardware.

Causes of a bad lever cover can include damage from regular opening and closing of the freezer door over time. Accidental impacts or heavy impacts from moving the refrigerator could also crack or weaken the plastic material.

Symptoms of a bad lever cover include:

• Exposure of the lock mechanism that allows dust and debris to enter
• Improper shielding of lock parts leading to potential jamming issues
• Cracking or breakage of the plastic allowing outside contaminants inside

This OEM LG part is also compatible with some Kenmore models.

The Ice Door Handle is an OEM replacement part for LG refrigerators. It allows users to easily access ice and water from the external ice/water dispenser. Handles experience substantial daily use as people frequently obtain water/ice. Over the years, plastic hinges can degrade from repeated opening/closing stresses.

Causes include fatigue cracks along hinge points from perpetual flexing. General wear and tear as well as occasional impacts also deteriorate structure.

Symptoms of a bad ice door handle include:

• Loose, wobbly, or dysfunctional opening/closing capability
• Cracks around mounting brackets compromise integrity
• Detached handle pieces preventing access to ice/water dispenser
• Excessive opening force required or inability to fully open/close

This OEM LG replacement is also compatible with select Sears/Kenmore refrigerators.

The Ice Door Handle Roller is an OEM replacement part for LG and some Kenmore refrigerators. Each handle contains two rollers and they help the handle move smoothly and prevent any unnecessary wear and tear. Please note, this is for one (1) door handle roller. It is recommended to replace both at the same time.

Symptoms of a bad Ice Door Handle Roller include:

• Difficulty in dispensing ice, with the chute door sticking or not opening properly.
• Noises such as squeaking or grinding when the ice door is activated.
• Increased effort needed to operate the ice dispenser handle.
• Visible wear or damage to the roller, affecting its movement.

Causes of a bad ice door handle roller can include mechanical wear from regular use, debris accumulation that impedes the roller’s movement, or damage from excessive force used on the dispenser handle.

This OEM LG part is also compatible with Sears/Kenmore models.

The Ice Bank Door Gasket is an OEM part for LG refrigerators. This gasket is designed to seal the ice bank door, ensuring a tight closure to maintain optimal temperatures inside the ice compartment. By preventing warm air from entering, it helps preserve the quality and quantity of ice produced by the icemaker.

Causes of a bad gasket can include wear and tear from frequent opening and closing of the door, physical damage from cleaning or mishandling, or degradation over time due to exposure to temperature changes.

Symptoms of a bad Ice Bank Door Gasket include:

• Ice melting or clumping in the ice compartment
• Frost buildup around the ice bank door
• Increased energy consumption
• The gasket appearing cracked, brittle, or deformed

This OEM LG part is also compatible with Sears/Kenmore.
